HEATING AND VENTILATION 1A – 13 REMOVAL Preparation: • Disconnect the battery ground cable • Drain engine coolant 1. Heater Unit Refer to “HEATER UNIT” removal procedure in this 2. Case (Temperature Control) Remove the case (Temperature control) from the 3. Rod 4. Sub-Lever 5. Door Lever Pull out the door lever while raising up the catch of 6. Clip INSTALLATION To install, follow the removal steps in the reverse order, 1. Apply grease to sub-lever and to the abrasive surface of the heater unit. 2. After installing the link unit, check to see if the link unit operates correctly. |
