Transmission Control System (Smoother) 7A-15
Ground Distributions
0.5 BLK
2 BLK
0.3 BLK
PT
O Switch (B-417-3)
Smoother Emergency Relay (X-14-2)
Smoother Emergency Relay (X-14-5)
PT
O Switch
DLC (B-79-4)
Change Lever Unit
Power
Distribution
Battery
B-7
0.5 BLK
Shift Position Indicator Back Lamp
15
1.25
BLK
0.3 BLK
3
BLK
P-5
0.5 BLK
Headlight Bracket
2
BLK
3
BLK
Emergency Shift Switch
0.5 BLK
0.5 BLK
0.5 BLK
B-1
Frame
2 BLK
DLC (B-79-5)
TCM (B-426-8)
TCM (B-426-17)
TCM (B-426-12)
TCM (B-426-4)
0.5 BLK
0.5 BLK
1.25 BLK
1.25 BLK
0.5 BLK
0.5 BLK
TCM (B-428-15)
0.5 BLK
Starter Cut Relay
2
BLK
2
BLK
J-9
Frame
TCM (B-425-2)
TCM (B-425-7)
1-3-5 Shift Solenoid
2-4-6-R Shift Solenoid
Select Solenoid
1.25 BLK
1.25 BLK
1.25 BLK
2 BLK
2 BLK
2 BLK
13
1
1
6
7
8
TCM (B-428-7)
1.25 BLK
TCM (B-425-6)
1.25 BLK
TCM (B-425-1)
1.25 BLK
1.25 BLK
1.25 BLK
1.25 BLK
1.25 BLK
1.25 BLK
H-1
19
H-1
19
H-1
18
H-17
H-17
H-17
7
1
W/S-B
J/C-D
W/S-E
W/S-D
W/S-C
2
BLK
USW
JOINT1
USW JOINT2
0.5 BLK
Heater Relay
Heater &
A/C Relay
Key On Relay
B-7
0.5 BLK
Engine W
arm up Switch (B-31-1)
0.5 BLK
0.5 BLK
Headlight Bracket
2
BLK
3
BLK
V
ehicle Speed Sensor (VSS)
Meter (B-55-7)
0.5 BLK
0.5 BLK
0.5 BLK
ECM (J-191-4)
HBB Level Switch
0.3 YEL/RED
Meter (B-55-10)
0.3
YEL/
RED
0.5 BLK
ECM (J-191-3)
ECM (J-191-1)
ECM (J-191-62)
ECM (J-191-43)
ECM (J-191-81)
1.25 BLK
1.25 BLK
1.25 BLK
0.75 BLK
0.75 BLK
0.5 BLK
0.5 BLK
ECM Main Relay
Condenser Fan Relay
0.85 BLK
2
BLK
Marker Light Relay
0.5 BLK
2
BLK
Fuel
T
ank
Unit
0.3
YEL/
RED
H-5
19
PT
O Switch
Engine W
arm up Switch (B-31-5)
3
BLK
3
BLK
3
BLK
2
BLK
0.85
BLK
0.5 BLK
6
1
USW JOINT3
W/S-F
W/S-E
J/C-D
N7A2114E
