MANUAL TRANSMISSION 7B-73
17. Apply engine oil 5W-30 sufficiently to the reverse
block ring (4), and then align the phase of the block
ring groove to the 1st-reverse clutch hub assembly
and sleeve, and install.
18. Apply engine oil 5W-30 to the needle bearing, the
reverse gear thrust surface and the synchro cone
taper. Turning the dog gear downward, align the
phase of the synchro cone phase of the reverse
gear to the nail of the outer ring, and insert the re-
verse gear (3), needle bearing (2), and collar (1)
with a press using the installer 5-8840-2345-0.
19. Install the spacer (2).
20. Insert the bearing (1) with a press using the install-
er 5-8840-2345-0, turning the stamped surface (4)
upward and the stamped surface (3) downward.
1
2
3
4
5
6
N7A0391E
N7A0392E
