HSA (HILL START AID) 5A5-55 HSA Valve Removal 1. Remove the undercover. Legend 1. Undercover 2. Disconnect the HSA valve connector. Legend 1. Hose 3. Remove the radiator grille. the hose. Legend 1. HSA valve 5. Disconnect the pipe. Installation 1. Install the two installing bolts of HSA valve. Tighten: Bolts to 21 N ⋅m (2.1 kg⋅m/15.5 lb⋅ft) 2. Install the brake pipe. Tighten: Brake pipe to 16 N ⋅m (1.6 kg⋅m/11.8 lb⋅ft) 3. Connect the connector. Caution: • Make sure there is no dust or foreign materials in and around the pipe connection. • Be careful to correctly connect the pipe. • After installation, bleed air from the brake system completely. • Be sure to use fresh specified brake fluid. N5A3038E N5A3039E N5A3040E |
