8J–4 EXTERIOR/INTERIOR TRIM Consoles Consoles and Associated Parts 745RX001 Legend (1) Shift Knob (M/T) / Transfer Knob (A/T) (4) Center Console Assembly Removal 1. Disconnect the battery ground cable. only). 3. Remove the front console assembly. D Remove four fixing screws and disconnect the 4. Remove the front seat assembly(RH). D Refer to Front Seat Assembly in Seats section. 5. Remove the assist grip. D Remove three bolts. 6. Remove the fuel filler lid opener. D Remove the fuel filter lid opener(1) and disconnect 686RS001 |
