7C–8 CLUTCH 4. Mark the flywheel, clutch cover and pressure plate lug for alignment when installing. 5. Remove the release bearing (3) from the transmission case . 6. Remove the shift fork snap pin. front cover. 8. Remove the front cover bolts. case. 220RW088 10. Remove flywheel assembly and crankshaft bearing, do not remove except for replacement. 11. Use the remover J–5822 and sliding hammer J–23907 to remove the crankshaft bearing. 015RW050 Inspection and Repair Make necessary correction or parts replacement if wear, Pressure Plate Assembly 201RS002 1. Visually check the pressure plate friction surface for excessive wear and heat cracks. 2. If excessive wear or deep heat cracks are present, the pressure plate must be replaced. Pressure Plate Warpage 201RS003 |
