MANUAL TRANSMISSION 7B–29 8. Remove the reverse gear from clutch hub No.1. 9. Remove the 3 inserts and 3 compression springs. D When removing the inserts, push the insert 226RW075 10. Remove the snap ring. NOTE: Don’t damage the bearing surface. 226RW076 11. Using a press, remove following parts. 1. Clutch hub No.2 assembly (1). 2. 3rd block ring (2). 3. 3rd gear (3). 4. 3rd gear needle roller bearing (4). 226RW091 12. Using screwdriver, remove the 2 insert springs, hub sleeve No.2, clutch hub No.2 and 3 inserts. 226RW090 |
