6E–557 TROOPER 6VE1 3.5L ENGINE DRIVEABILITY AND EMISSIONS Installation Procedure 1. Install the gasket on the common chamber. Torque: 25 N·m (18 Ib ft) NOTE: It is possible to install the EGR valve rotated 180 ° from the correct position. Make sure that the base of the 014RW098 4. Connect the electrical connector at the EGR valve. 014RW139 5. Connect the negative battery cable. Positive Crankcase Ventilation (PCV) Valve Removal Procedure 1. Remove the vacuum hose at the PCV valve. D Slide the clamp back to release the hose. 2. Pull the PCV valve from the rubber grommet in the right valve cover. 014RW097 Inspection Procedure Before inspecting the PCV valve, make sure that the PCV Valve 1. Run the engine at normal operating temperature. RESULT: A hissing noise should be heard from the 3. Remove the PCV valve from the engine. a. Blow air into the rocker cover side of the valve. 4. Re-install the PCV valve and remove the oil filler cap. RESULT: A small vacuum should be felt at the oil filler |
