Isuzu Trooper (2000 year). Manual - part 219





6E–5

TROOPER 6VE1 3.5L ENGINE DRIVEABILITY AND EMISSIONS

Mass Air Flow (MAF) Sensor

6E–565

. . . . . . . . . . . .

Manifold Absolute Pressure (MAP) Sensor

6E–565

Powertrain Control Module (PCM)

6E–566

. . . . . . .

PCM Function

6E–566

. . . . . . . . . . . . . . . . . . . . . . . . .

PCM Components

6E–566

. . . . . . . . . . . . . . . . . . . . .

PCM Voltage Description

6E–566

. . . . . . . . . . . . . . .

PCM Input/Outputs

6E–567

. . . . . . . . . . . . . . . . . . . .

PCM Service Precautions

6E–567

. . . . . . . . . . . . . .

Reprogramming The PCM

6E–567

. . . . . . . . . . . . . .

Throttle Position (TP) Sensor

6E–567

. . . . . . . . . . .

Transmission Fluid Temperature
 (TFT) Sensor

6E–567

. . . . . . . . . . . . . . . . . . . . . . . . .

Transmission Range Switch

6E–567

. . . . . . . . . . . . .

Vehicle Speed Sensor (VSS)

6E–568

. . . . . . . . . . . .

Use of Circuit Testing Tools

6E–568

. . . . . . . . . . . . .

Aftermarket Electrical and Vacuum
 Equipment

6E–568

. . . . . . . . . . . . . . . . . . . . . . . . . . .

Electrostatic Discharge Damage

6E–568

. . . . . . . . .

Upshift Lamp

6E–568

. . . . . . . . . . . . . . . . . . . . . . . . .

General Description (Air Induction)

6E–568

. . . . . . . .

Air Induction System

6E–568

. . . . . . . . . . . . . . . . . . .

General Description (Fuel Metering)

6E–569

. . . . . . .

Acceleration Mode

6E–569

. . . . . . . . . . . . . . . . . . . . .

Battery Voltage Correction Mode

6E–569

. . . . . . . .

CMP Signal

6E–569

. . . . . . . . . . . . . . . . . . . . . . . . . . .

Clear Flood Mode

6E–569

. . . . . . . . . . . . . . . . . . . . .

Deceleration Mode

6E–569

. . . . . . . . . . . . . . . . . . . .

Engine Speed/Vehicle Speed/Fuel
 Disable Mode

6E–569

. . . . . . . . . . . . . . . . . . . . . . . .

Fuel Cutoff Mode

6E–569

. . . . . . . . . . . . . . . . . . . . . .

Fuel Injector

6E–569

. . . . . . . . . . . . . . . . . . . . . . . . . .

Fuel Metering System Components

6E–569

. . . . . .

Fuel Metering System Purpose

6E–570

. . . . . . . . . .

Fuel Pressure Regulator

6E–570

. . . . . . . . . . . . . . . .

Fuel Pump Electrical Circuit

6E–570

. . . . . . . . . . . . .

Fuel Rail

6E–570

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Run Mode

6E–571

. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Starting Mode

6E–571

. . . . . . . . . . . . . . . . . . . . . . . . .

Throttle Body Unit

6E–571

. . . . . . . . . . . . . . . . . . . . .

General Description
 (Electronic Ignition System)

6E–571

. . . . . . . . . . . . . .

Camshaft Position (CMP) Sensor

6E–571

. . . . . . . .

Crankshaft Position (CKP) Sensor

6E–571

. . . . . . .

Electronic Ignition

6E–572

. . . . . . . . . . . . . . . . . . . . .

Ignition Coils

6E–572

. . . . . . . . . . . . . . . . . . . . . . . . . .

Ignition Control

6E–572

. . . . . . . . . . . . . . . . . . . . . . . .

Ignition Control PCM Output

6E–573

. . . . . . . . . . . .

Powertrain Control Module (PCM)

6E–573

. . . . . . .

Spark Plug

6E–574

. . . . . . . . . . . . . . . . . . . . . . . . . . . .

A/C Clutch Diagnosis

6E–575

. . . . . . . . . . . . . . . . . . . .

A/C Clutch Circuit Operation

6E–575

. . . . . . . . . . . .

A/C Clutch Circuit Purpose

6E–575

. . . . . . . . . . . . .

A/C Request Signal

6E–575

. . . . . . . . . . . . . . . . . . . .

General Description (Evaporative (EVAP)
 Emission System)

6E–576

. . . . . . . . . . . . . . . . . . . . . .

EVAP Emission Control System Purpose

6E–576

EVAP Emission Control System Operation

6E–576

Enhanced Evaporative Emission Control
 System

6E–576

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

General Description (Exhaust Gas
 Recirculation (EGR) System)

6E–579

. . . . . . . . . . . . .

EGR Purpose

6E–579

. . . . . . . . . . . . . . . . . . . . . . . . .

Linear EGR Valve

6E–580

. . . . . . . . . . . . . . . . . . . . .

Linear EGR Control

6E–580

. . . . . . . . . . . . . . . . . . . .

Linear EGR Valve Operation and Results
 of Incorrect Operation

6E–580

. . . . . . . . . . . . . . . . .

EGR Pintle Position Sensor

6E–580

. . . . . . . . . . . . .

General Description (Positive Crankcase
 Ventilation (PCV) System)

6E–580

. . . . . . . . . . . . . . .

Crankcase Ventilation System Purpose

6E–580

. . .

Crankcase Ventilation System Operation

6E–580

Special Tools

6E–582

. . . . . . . . . . . . . . . . . . . . . . . . . . .

6E–6

TROOPER 6VE1 3.5L ENGINE DRIVEABILITY AND EMISSIONS

Specifications

Tightening Specifications

Application

N·m

Lb Ft.

Lb In.

Camshaft Position Sensor Retaining Screw

9

78

Crankshaft Position Sensor Mounting Bolt

9

78

EGR Bolt

25

18

Engine Coolant Temperature Sensor

30

22

Fuel Drain Plug

20

14

Fuel Pressure Regulator Attaching Screw

3

26

Fuel Rail Bolts

25

18

Fuel Tank Undercover Retaining Bolts

36

27

Heated Oxygen Sensor

55

40

Lower Intake Manifold to Engine Block Bolts

25

18

Lower Intake Manifold to Engine Block Nuts

25

18

Spark Plugs

18

13

Throttle Body Mounting Bolts

10

87

Common Chamber to Lower Intake Manifold Bolts

25

18

VSS Retaining Bolt

16

12

6E–7

TROOPER 6VE1 3.5L ENGINE DRIVEABILITY AND EMISSIONS

Diagrams and Schematics

PCM Wiring Diagram (1 of 7)

D06RY00156

6E–8

TROOPER 6VE1 3.5L ENGINE DRIVEABILITY AND EMISSIONS

PCM Wiring Diagram (2 of 7)

D06RY00150
