4C–44 DRIVE SHAFT SYSTEM Rear Propeller Shaft General Description Since the propeller shaft is balanced carefully, welding or Alignment marks should be applied to each propeller 401RW003 Rear Propeller Shaft and Associated Parts 401RW059 Legend (1) Bolt, Nut and Washer (2) Rear Propeller Shaft Removal 1. Jack up the vehicle and support it on the chassis stands. 2. Gear shift lever should be placed in neutral position and parking brake released. NOTE: Apply alignment marks on the flange at the rear |
