7B–100 MANUAL TRANSMISSION
Main Data and Specifications
General Specifications
(MUA)
4X2
4X4
Transmission type
Fully synchronized forward and reverse gears
Transfer case
—
Synchronized type gears
shifting between the 2– and
4–wheel drive mode.
Constant mesh type gears
between “low” and “high”
Control method
Remote control with the gear shift lever on the floor.
Gear ratio: Transmission
1st
3.767
2nd
2.248
3rd
1.404
4th
1.000
5th
0.809
Rev.
3.873
Gear ratio: Transfer
High
—
1.000
Low
—
2.050
Transmission oil capacity
2.95 lit. (3.12 US qt)
Transfer oil capacity
—
1.45 lit. (1.53 US qt)
Type of lubricant
Engine oil: Refer to the chart in “SECTION 0”
(TREMEC T5R)
Transmission type
Fully synchronized 5–forward gears with sliding selective
type reverse gear.
Control method
Remote control with the gear shift level on the floor.
Gear ratio:
1st
3.76
2nd
2.18
3rd
1.42
4th
1.00
5th
0.81
Rev.
3.76
Speedometer gear ratio
7/22
Oil capacity
2.13 lit. (2.3 US qt)
Type of lubricant
DEXRON
–III Automatic Transmission Fluid
