7B–60 MANUAL TRANSMISSION 226RS048 226RS049 7. Install clutch hub snap ring(19) by performing the following steps: f Select the snap ring which will provide the minimum 226RS050 There are three snap ring sizes available. 226RS021 Clutch Hub and Snap Ring Clearance Standard: 0 – 0.1 mm (0 – 0.004 in) Snap Ring Availability Thickness Color Coding 1.80 mm (0.071 in) White 1.85 mm (0.073 in) Yellow 1.90 mm (0.075 in) Blue f Use a pair of snap ring pliers to install the snap ring |
