6E2–463 RODEO 6VD1 3.2L ENGINE DRIVEABILITY AND EMISSIONS f Inspect the IAC valve O-ring for cuts, cracks, or f In order to install a new IAC valve, measure the NOTE: Do not push or pull on the IAC valve pintle on IAC IMPORTANT: Use an identical replacement part in order to replace a valve. IAC valve pintle shape and TS23746 Installation Procedure 1. Install the IAC valve on the throttle body with the bolts. Tighten f Tighten the bolts to 1 N·m (9 lb in.). TS23745 2. Connect the IAC valve electrical connector. Common Chamber Removal and Installation Prodedure Refer to Common Chamber in Engine Mechanical. Accelerator Cable Assembly Removal Procedure 1. Remove the engine cover. mounting on the common chamber. 101RW005 3. Remove the accelerator control cable (on the throttle valve end). 101RW006 |
