6E1–283 RODEO X22SE 2.2L ENGINE DRIVEABILITY AND EMISSION f Diagnostic Trouble Code P0502 can be cleared by Diagnostic Aids f Poor connection at PCM: Inspect harness connectors locks, improperly formed or damaged terminals, and f Damaged harness: Inspect the wiring harness to the DTC P0502 – VSS Circuit Low Input
Step Action Value(s) Yes No 1 Was the ”On–Board Diagnostic (OBD) System Check” — Go to Step 2 Go to OBD System Check 2 1. Ignition OFF. ground wire. Did the light illuminate? — Go to Step 4 Go to Step 3 3 Repair the open in the sensor ground circuit. — Verify repair — 4 1. Ignition ON, sensor disconnected. VSS connector between ground and voltage Was the measurement near the specified value? Battery Go to Step 6 Go to Step 5 5 Repair the open or short to ground in the VSS sensor — Verify repair — 6 1. Ignition OFF. connector and the PCM for the following conditions: f An open circuit f A short to ground Was the faulty condition located? — Verify repair Go to Step 9 7 Using a DVM, measure the resistance between the Is the resistance above the specified value? 10 K W Verify repair Go to Step 9 8 1. Remove the VSS from the transmission case. Does the VSS appear to be OK? — Verify repair — 9 Replace the VSS. — Verify repair — 10 Replace the PCM. IMPORTANT: The replacement PCM must be And also refer to latest Service Bulletin. Is the action complete? — Verify repair — |
