6E1–247 RODEO X22SE 2.2L ENGINE DRIVEABILITY AND EMISSION DTC P0406 EGR Sensor Circuit High (Cont'd) Step No Yes Value(s) Action 9 1. Ignition ON, Engine OFF. on the 5 volt Reference signal circuit at the Linear Does the DVM read the following value? about 5 volts Go to Step 11 Go to Step 10 10 Check the 5 volt Reference signal circuit, between the f An open circuit f A short to ground f A short to voltage Was the problem found? — Verify repair Go to Step 11 11 1. Ignition OFF. circuit and the 5 volt signal return (ground) circuit at 3. Ignition ON, Engine OFF. Does the DVM read the following value? about 5 volts Go to Step 13 Go to Step 12 12 Check the 5 volt signal return (ground) circuit, between f An open circuit f A short to ground f A short to voltage Was the problem found? — Verify repair Go to Step 15 13 1. Ignition OFF. Reference signal circuit and the EGR valve position 3. Ignition ON, Engine OFF. Does the Tech 2 display the following value(s)? 5 volts 100% Go to Step 14 Go to Step 15 14 Replace the Linear Exhaust Gas Recirculation (EGR) — — — 15 Replace the PCM. IMPORTANT: The replacement PCM must be And also refer to latest Service Bulletin. Verify repair. — — — |
