6E1–103 RODEO X22SE 2.2L ENGINE DRIVEABILITY AND EMISSION Evaporative (EVAP) Emissions Canister Purge Valve Solenoid Check
Step Action Value(s) Yes No 1 1. Ignition OFF. to the pump solenoid. 4. Using a hand vacuum pump with an attached vacuum gauge J 23738–A, apply vacuum (10” Hg or Does the solenoid hold vacuum? — Go to Step 3 Go to Step 2 2 1. Disconnect the solenoid electrical connector. solenoid. Does the solenoid hold vacuum? — Go to Step 4 Go to Step 7 3 1. At the throttle body, put a cap over the vacuum port where the hose was disconnected for testing. This 2. Ignition OFF. vacuum pump. 5. Start the engine, run at 2500 RPM. Did the vacuum drop when the purge was turned on? — Go to Step 8 Go to Step 9 4 Check for a short to ground or open in the wire between Is there a problem? — Go to Step 5 Go to Step 6 5 Repair the faulty wire. Is the action complete? — Verify repair — 6 Replace the PCM. IMPORTANT: The replacement PCM must be and also refer to latest service bulletin. Is the action complete? — Verify repair — 7 Replace the faulty purge solenoid. Is the action complete? — Verify repair — |
