Isuzu Rodeo UE. Manual - part 160





6E1–11

RODEO X22SE 2.2L ENGINE DRIVEABILITY AND EMISSION

PCM WIRING DIAGRAM (5 of 10)

D06RX028

6E1–12

RODEO X22SE 2.2L ENGINE DRIVEABILITY AND EMISSION

PCM WIRING DIAGRAM (6 of 10)

D06RX032

6E1–13

RODEO X22SE 2.2L ENGINE DRIVEABILITY AND EMISSION

PCM WIRING DIAGRAM (7 of 10)

D06RX031

6E1–14

RODEO X22SE 2.2L ENGINE DRIVEABILITY AND EMISSION

PCM WIRING DIAGRAM (8 of 10)

D06RX033
