5C–49 POWER–ASSISTED BRAKE SYSTEM 10. Remove clip. Installation 1. Install clip (4). 306RW010 2. Apply special grease (approximately 0.2 g) to both contacting surfaces of the inner shims (5). Wipe off 306RW011 Legend (5) Inner Shim 3. Install support bracket and tighten the bolt (7) to the specified torque. Torque: 103 N·m (76 lb ft) 306RW012 4. Install caliper assembly. to the specified torque. Torque: 44 N·m (32 lb ft) 306RW013 6. Install brake flexible hose, always use new gaskets and be sure to put the hooked edge of the flexible Torque: 35 N·m (26 lb ft) |
