0B–7
MAINTENANCE AND LUBRICATION
crank. The starter should crank only when the clutch
pedal is fully depressed.
Accelerator Linkage Lubrication
Lubricate the accelerator pedal fulcrum pin with chassis
grease.
Steering and Suspension Inspection
Inspect the front and rear suspension and steering
system for damaged, loose or missing parts or signs of
wear. Inspect power steering lines and hoses for proper
hookup, binding, leaks, cracks, chafing, etc.
Body and Chassis Lubrication
Lubricate the key lock cylinders, the hood latch, the hood
and door hinges, the door check link, the parking cable
guides, the underbody contact points, and the linkage.
Propeller Shaft Inspection and Lubrication
Check the propeller shaft flange–to–pinion bolts for
proper torque to 63 N
•
m (46 lb ft) for front and rear
propeller shaft.
Automatic Transmission Fluid
Replacement
Under harsh operating conditions, such as constant
driving in heavy city traffic during hot weather, or in hilly or
mountainous terrain, change the transmission fluid and
service the sump filter after every 20,000 miles (32,000
km) of operation.
More over, the remaining life percentage of ATF can be
estimated by using TECH–II as an auxiliary tool to judge
the right time for ATF replacement.
The remaining life percentage is calculated from ATF’S
heat history. When it is close to 0%, ATF replacement is
recommended.
Auto Cruise Control Inspection
Check to see if the clearance between cruise link and
accelerator link is normal. Also check that the connected
properly.
Clutch Lines and Hoses Inspection
Check lines and hoses for proper attachment, binding,
leaks, cracks, chafing, deterioration, etc. Any
questionable parts should be replaced or repaired at
once. When abrasion or wear is evident on lines or hoses,
the cause must be corrected.
Clutch Control Lubrication
Lubricate the clutch pedal bushing, the clevis pin, and
pedal spring every 15,000 miles (24,000 km) or 6 months.
If a squeaking noise arises from around the bushing or the
clevis pin at the clutch pedal arm when the clutch pedal is
depressed, lubricate them.
Clutch Pedal Free Play Inspection
Note the clutch pedal free play. It should be 5 – 15 mm (0.2
– 0.6 in). Adjust clutch control when there is little or no free
play.
Accelerator Linkage Inspection
Inspect for interference, binding, and damaged or
missing parts. Check accelerator pedal for smooth
operation and even pedal effort. Replace parts as
needed.
