Engine Mechanical – V6 Page 6A1–287
Page 6A1–287 3 Measure the crankshaft thrust wall width (1) for wear 5 Specifications . 4 Measure the crankshaft thrust wall surface (2) for 5 Specifications . 5 If the crankshaft journals are damaged or worn
Figure 6A1 – 512 6 Inspect the crankshaft main journals (1) for undersize,
Figure 6A1 – 513 7 Inspect the crankpins (1) for undersize using an 8 Compare your measurements with those listed in the 5 Specifications . If the crankpin journals are worn beyond the specifications,
Figure 6A1 – 514 |
