Engine Mechanical – V6 Page 6A1–253
6 Drill the crankshaft main bolt hole until the mark (1)
N O T E During the drilling process, repeatedly remove Figure 6A1 – 485 N O T E All swarf must be removed from the drilled hole
Safety glasses must be worn when using 7 Using compressed air, clean out any swarf. Figure 6A1 – 486 N O T E • During the tapping process, repeatedly remove the tap and clean the swarf from the • Ensure the tap has created full threads at least to the depth equal to the insert length. CAUTION
Do not remove the fixture plate during the 8 Using a suitable tapping wrench, tap the threads of Figure 6A1 – 487 |
