Engine Mechanical – V6 Page 6A1–117
17 Install the left-hand secondary timing chain guide (1). 18 Install the secondary timing chain guide bolts (2) and
Secondary timing chain guide Figure 6A1 – 155 19 Ensure the left-hand secondary timing chain shoe is
CAUTION
The left-hand secondary timing chain shoe Figure 6A1 – 156 20 Install the left-hand secondary timing chain shoe (1). Figure 6A1 – 157 |
