Engine Mechanical – V6 Page 6A1–57
3.3 Oil Filter Adaptor Remove
Disconnection of the battery affects certain
WARNING, CAUTION and NOTES before 1 Disconnect the battery negative terminal. 2 Disconnect the wiring harness connector from the oil pressure sender.
3 Remove the oil filter adaptor attaching bolts (2), four 4 Remove the oil filter adaptor and discard the gasket 5 Clean the surfaces of the adaptor and cylinder block.
• Do not use a screwdriver or similar to prise the oil filter adapter from the engine • If required, use a rubber mallet to tap the oil filter adapter to loosen the Figure 6A1 – 27 Reinstall Reinstallation of the oil filter adaptor is the reverse of the removal procedure, noting the following: 1 A new gasket must be used. 2 Loosely install the oil filter adaptor attaching bolts, then tighten all fasteners to the correct torque specification. Oil filter adaptor attaching bolt |
