6E–190 ENGINE DRIVEABILITY AND EMISSIONS 8 Using the DVM and check the ignition coil module 1. Ignition “On”, engine “Off”. 2. Disconnect the ignition coil module connector. 3. Check the circuit for open circuit. Was the DVM indicated specified value? 10 - 14.5V Go to Step 10 Go to Step 9 9 Repair the open or short to ground circuit between the — Verify repair — 10 Replace the ignition coil module. — Verify repair Go to Step 11 11 Is the ECM programmed with the latest software — Verify repair Go to Step 12 12 Replace the ECM. — Verify repair — Step Action Value(s) Yes No V E-18 2 |
