6E-18 Engine Control System (4JH1) Component Locator Engine Controls Component Views
3 4 1 2 6 4 5
Legend 1. Mass Air Flow (MAF) & Intake Air Temperature (IAT) Sensor Assembly 2. Throttle Cable 3. Air Cleaner Case
4. Battery 5. Relay & Fuse Box 6. EGR Cooler (Euro3) / EGR Pipe (Except Euro3)
|
