Isuzu KB P190. Manual - part 1343





8A-434  ELECTRICAL-BODY AND CHASSIS

  INSPECTION AND REPAIR















B8

RTW78ASH002901




Power Window Relay

Check continuity between the relay terminals.

2

1

........................ No continuity

(When battery voltage is applied between

3

 and

4

2

1

........................ Continuity














Harness side

D20

D5






Driver’s Side Power Window & Door Lock
Switch

1.  Harness Side Connector Circuit

  Disconnect the switch connector, and check voltage and

continuity between the harness side connector terminals as

shown in the following table.





Terminal

No.

Wire

color

Connecting to

Check item

Connectin

g terminal

Check condition

Standard

6 G/R

Power window

relay

Voltage

6-Ground

Starter SW “ON”

Approx.

12V

7 BR/R

Power window









8 BR/W

motor









3 B

Ground  Continuity

3-Ground

-  Continuity












Harness side

D10






Front Passenger’s Power Window Switch

1.  Harness Side Connector Circuit

  Disconnect the switch connector, and check voltage and

continuity between the harness side connector terminals as

shown in the following table.





Continuity

7-8

Continuity

ELECTRICAL-BODY AND CHASSIS  8A-435

Terminal

No.

Wire

color

Connecting to

Check item

Connectin

g terminal

Check condition

Standard

6 G/R

Power window

relay

Voltage

6-Ground

Starter SW “ON”

Approx.

12V

8 BR/R

7 BR/W

Power window

motor

Continuity 8-7

Continuity

1,3 B

Ground  Continuity

1,3-Ground

Continuity












Harness side

D12

D16






Rear Power Window Switch-LH & RH

1.  Harness Side Connector Circuit

  Disconnect the switch connector, and check voltage and

continuity between the harness side connector terminals as

shown in the following tables.







D12

 (RR-LH)

Terminal

No.

Wire

color

Connecting to

Check item

Connectin

g terminal

Check condition

Standard

6 G/R

Power window

relay

Voltage

6-Ground

Starter SW “ON”

Approx.

12V

8 BR/R

7 BR/W

Power window
motor

Continuity 8-7

Continuity

3 B

4 B

Ground Continuity

3,4-Ground  -  Continuity



D16

 (RR-RH)

Terminal

No.

Wire

color

Connecting to

Check item

Connectin

g terminal

Check condition

Standard

6 G/R

Power window

relay

Voltage

6-Ground

Starter SW “ON”

Approx.

12V

8 BR/R

7 BR/W

Power window
motor

Continuity 8-7

Continuity

3 B

Ground  Continuity

3-Ground

-  Continuity



8A-436  ELECTRICAL-BODY AND CHASSIS









Harness side

D5





Driver’s Side Power Window Motor

1. Driver’s Side Power Window & Door Lock Switch

Connector Circuit



Disconnect the switch connector, apply the battery voltage

(12V) to the harness side connector terminals and check

operation.


Connecting terminals

Operation

7 (BR/R)

8 (BR/W)

direction

-



+

 DOWN

+



-

 UP









D1






2.  Driver’s Side Power Window Motor Connector Circuit



Disconnect the switch connector, apply the battery voltage

(12V) to the motor side connector terminals and check

operation.


Connecting terminals

Operation

1 2

direction

+



-

 DOWN

-



+

 UP



ELECTRICAL-BODY AND CHASSIS  8A-437









Harness side

D10





Front Passenger’s Power Window Motor

1. Front Passenger’s Power Window Switch Connector

Circuit



Disconnect the motor connector, apply the battery voltage

(12V) to the harness side connector terminals and check

operation.


Connecting terminals

Operation

8 (BR/R)

7 (BR/W)

direction

-



+

 DOWN

+



-

 UP







D6






2. Front Passenger’s Power Window Motor Connector

Circuit



Disconnect the switch connector, apply the battery voltage

(12V) to the motor side connector terminals and check

operation.


Connecting terminals

Operation

1 2

direction

+



-

 DOWN

-



+

 UP
