ELECTRICAL-BODY AND CHASSIS 8-145 WARNING AND INCIDATOR LIGHT 1. When the parking brake lever is pulled, the indicator light does not light up Checkpoint Trouble Cause Countermeasure Replace or reinstall the bulb Bulb burned out or loose contact NG Adjust or replace the parking brake SW. Parking brake SW. installation position and function Incorrect SW. adjustment or poor SW. point contact Repair open circuit or connector contact Continuity between the C-39 (4 ×4: 1 R-4 ) and 12 B-23 Open circuit or poor connector contact NG NG OK OK Brake indicator light bulb continuity Replace the parking brake SW. Continuity between the C-39 (4 ×4: 1 R-4 ) and the ground when the parking Parking brake SW. malfunction NG OK |
