ELECTRICAL-BODY AND CHASSIS 8-177 Installation Follow the removal procedure in the reverse order to install the Connector Be absolutely sure that the spot light connector is securely Bulb Be absolutely sure that the spot light bulb is correctly installed. WARNING BUZZER (For Gulf only) Removal 1. Dash Side Panel 2. Warning Buzzer • Disconnect the connector. Installation Follow the removal procedure in the reverse order to install the Connector Be absolutely sure that the warning buzzer connector is |
