ELECTRICAL-BODY AND CHASSIS 8-85
REMOVAL AND INSTALLATION ECM (ENGINE CONTROL MODULE) Removal 1. Remove the ECM. Refer to the "ENGINE" Section of this Manual. 2. Loosen the three screws. 3. Pull out the ECM. 4. Disconnect both red and tan connectors. Installation Follow the removal procedure in the reverse order to install the Connector Be absolutely sure that ECM is securely connected. |
