CAB 10-5 Important Operation - Removal 6. Windshield Glass material. 2) Secure one end of a piece of steel piano wire (0.02 inches in diameter) to a piece of wood that can serve as a handle. 3) Use a pair of needle nose pliers to insert the other end of the piano wire through the adhesive caulking material at the edge of the windshield glass. 4) Secure the other end of the piano wire to another piece of wood. 5) With the aid of an assistant, carefully move the piano wire with a sawing motion to cut through the adhesive caulking material around the entire circumferance of the windshield glass. 6) Lift the windshield from the body. 7) Clean any remaining adhesive caulking material from the area of the body which holds the windshield. 8) Use a soft rag and unleaded gasoline to wipe off any adhesive remaining on the windshield glass. Important Operations - Installation 7. Engine Hood Rear Seal 1 : Seal 2 : Clip 3 : Rear (windshield glass side) 4 : Front 6. Windshield Glass 1) Clean the windshield glass bonding surface. 2) Use a soft rag and unleaded gasoline to wipe off any adhesive remaining on the body. 3) Mount the body window glass as shown in the illustration. Attach spacers at seven (7) locations. |
