Technical and consumer information
axle. Be sure to leave enough slack in the
chains to permit turning corners.
STI0745
Trailer lights
Your vehicle is equipped with a towing
package, which also includes the 7-pin
trailer harness connector located under the
trailer hitch cover on the rear bumper.
CAUTION
.
When splicing into the vehicle electrical
system, a commercially available power-
type module/converter must be used to
provide power for all trailer lighting. This
unit uses the vehicle battery as a direct
power source for all trailer lights while
using the vehicle tail light, stoplight and
turn signal circuits as a signal source.
The module/converter must draw no
more than 15 milliamps from the stop
and tail lamp circuits. Using a module/
converter that exceeds these power
requirements may damage the vehicle’s
electrical system. See a reputable trailer
retailer to obtain the proper equipment
and to have it installed.
.
Do not connect electrical devices that
draw more than 40 amps to the vehicle.
The fusible link may melt.
Trailer lights should comply with federal
and/or local regulations. For assistance in
hooking up trailer lights, contact an
INFINITI retailer or reputable trailer retailer.
Trailer brakes
When towing a trailer load of 3,500 lbs.
(1,587 kg) or more, trailers with a brake
system MUST be used. However, most
states require a separate braking system
on trailers with a loaded weight above a
specific amount. Make sure the trailer
meets the local regulations and the regula-
tions where you plan to tow.
Several types of braking systems are
