Infiniti G35 (2008 year). Manual

Removing the console lid (Coupe

model with manual transmission)

To remove the console lid:
1. Remove the hinge mask

using a screw-

driver wrapped with a cloth.

2. Loosen four screws, and remove the lid.
3. Tighten the two outside screws

4. Install the removed hinge mask

to the

original position.

REAR ARMREST POCKET (Sedan)

The pocket can store a first aid kit or other small

items.

Coupe — Manual transmission model

SIC3468

SIC1850

2-46

Instruments and controls

—

07/05/07—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CARD HOLDER
Type A

Insert a card

in the holder.

Type B and C

Pull the sun visor down

and slide a card

in the card holder.

Type A

SIC3263

Type B

SIC2154A

Type C

SIC3463

Instruments and controls

2-47

—

07/05/07—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

COAT HOOKS
Sedan

The coat hooks are equipped beside the rear

personal lights.

CAUTION

Do not place items which are more than 2 lb (1

kg) on the hook.

Coupe

To use the coat hook, push the hook

release.

CAUTION

Avoid hanging heavy goods on the hook.

STOWING GOLF BAGS (Coupe)

Normally, two standard golf bags can be stowed

in the trunk. Insert the top of the golf bag into

left side of the trunk room

then put the bag

forward

. Insert the top of the 2nd golf bag

into right side of the trunk room

and pull it

in all the way

In some cases, you may not be able to stow two

golf bags in your vehicle, depending on their

sizes or types.

Sedan

SIC3248

Coupe

SIC3544

SIC3467

2-48

Instruments and controls

—

07/05/07—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CARGO NET

The cargo net helps keep packages in the cargo

area from moving around while your vehicle is

driven.
To install the cargo net, attach the hooks to the

retainers

CAUTION

Avoid keeping heavy objects in the net.

TRUNK NET FOR EXTRA WINDOW

WASHER FLUID (Canada only; if so

equipped)

The trunk net is provided for holding a tank of

extra window washer fluid.
To install the net, place a commercially avail-

able tank in the right corner of the trunk and

then attach the hooks to the restrainers

POWER WINDOWS

WARNING

● Make sure that all passengers have their

hands, etc. inside the vehicle while it is in

motion and before closing the windows. Use

the window lock switch to prevent unex-

pected use of the power windows.

● Do not leave children unattended inside the

vehicle. They could unknowingly activate

switches or controls and become trapped in

the window. Unattended children could be-

come involved in serious accidents.

The power windows operate when the ignition

switch is in the ON position or for about 45

seconds after the ignition switch is pushed to

the OFF position. If the driver’s or front passen-

ger’s door is opened during this period of about

45 seconds, power to the windows is canceled.

SIC3320

SIC3317

WINDOWS

Instruments and controls

2-49

—

07/05/07—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Main power window switch (driver’s

side)

1. Driver side window
2. Front passenger side window
3. Rear left passenger side window (Sedan

only)

4. Rear right passenger side window (Sedan

only)

5. Window lock button

To open or close the window, push down

pull up

the switch and hold it. The main

switch (driver side switches) will open or close

all the windows.

Locking passengers’ windows

When the lock button

is pushed in, only the

driver side window can be opened or closed.

Push it in again to cancel.

Passenger side power window switch

The passenger side switch will open or close

only the corresponding window. To open or

close the window, push down or pull up the

switch and hold it.

Sedan

SIC3279

Coupe

SIC3286A

SIC3241

2-50

Instruments and controls

—

07/05/07—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Automatic operation (for front door

windows or all door windows)

To fully open or close the window, completely

push down or pull up the switch and release it;

it need not be held. The window will automati-

cally open or close all the way. To stop the

window, just push or lift the switch in the

opposite direction.
A light push or pull on the switch will cause the

window to open or close until the switch is

released.

Auto reverse function

WARNING

There are some small distances immediately

before the closed position which cannot be de-

tected. Make sure that all passengers have

their hands, etc., inside the vehicle before clos-

ing the window.

If the control unit detects something caught in

the window as it is closing, the window will be

immediately lowered.
The auto reverse function can be activated when

the window is closed by automatic operation

when the ignition switch is in the ON position or

for 45 seconds after the ignition switch is

pushed to the OFF position.
Depending on the environment or driving condi-

tions, the auto reverse function may be activated

if an impact or load similar to something being

caught in the window occurs.

Sedan — Type A

SIC3289

Sedan — Type B

SIC3285

Coupe

SIC3288

Instruments and controls

2-51

—

07/05/07—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Automatic adjusting function (Coupe)

CAUTION

When the battery cable is removed from the

battery terminal, do not close either of the front

doors. The automatic window adjusting func-

tion will not work and the side roof panel may

be damaged.

The power window has an automatic adjusting

function. When the door is being opened, the

window is automatically lowered slightly to

avoid contact between the window and the side

roof panel. When the door is closed, the window

is automatically raised slightly.
While the automatic adjusting function does not

work, the window will be controlled as follows:
● When the door is opened, the window lowers

for approximately 2 seconds.

● While the door is open, the window cannot

be raised.

If the windows do not close

automatically

If the power window automatic function (closing

only) does not operate properly, perform the

following procedure to initialize the power win-

dow system.

1. Push the ignition switch to the ON posi-

tion.

2. Close the door.
3. Open the window more than halfway by

operating the power window switch.

4. Pull the power window switch and hold it

to close the window, and then hold the

switch more than 3 seconds after the

window is closed completely.

5. Release the power window switch. Oper-

ate the window by the automatic function

to confirm the initialization is complete.

6. Perform steps 2 through 5 above for other

windows.

If the power window automatic function does

not operate properly after performing the pro-

cedure above, have your vehicle checked by an

INFINITI dealer.

WARNING

● In an accident you could be thrown from the

vehicle through an open moonroof. Always

use seat belts and child restraints.

● Do not allow anyone to stand up or extend

any portion of their body out of the moonroof

opening while the vehicle is in motion or

while the moonroof is closing.

CAUTION

● Remove water drops, snow, ice or sand from

the moonroof before opening.

● Do not place any heavy object on the moon-

roof or surrounding area.

AUTOMATIC MOONROOF

The moonroof only operates when the ignition

switch is in the ON position.
The automatic moonroof is operational for

about 45 seconds, even if the ignition switch is

pushed to the OFF position. If the driver’s door

or the passenger’s door is opened during this

period of about 45 seconds, power to the

moonroof is canceled.

MOONROOF (if so equipped)

2-52

Instruments and controls

—

07/14/07—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Sunshade

The sunshade will open automatically when the

moonroof is opened. However, it must be

closed manually.

Tilting the moonroof

To tilt up, first close the moonroof, then push

the UP

side of the moonroof switch and

release it; it need not be held. To tilt down the

moonroof, push the DOWN

side.

Sliding the moonroof

To fully open or close the moonroof, push the

or OPEN

side of the moonroof

switch and release it; it need not be held. The

roof will automatically open or close all the way.

To stop the roof, push the switch once more

while it is opening or closing.

Auto reverse function

WARNING

There are some small distances immediately

before the closed position which cannot be de-

tected. Make sure that all passengers have

their hands, etc., inside the vehicle before clos-

ing the moonroof.

If the control unit detects something caught in

the moonroof when it is closing, the moonroof

will be immediately opened.
The auto reverse function can be activated when

the moonroof is closed by automatic operation

when the ignition switch is in the ON position or

for about 45 seconds after the ignition switch is

pushed to the OFF position.
If the moonroof cannot be closed automatically

when the auto reverse function activates due to

a malfunction, push and hold the CLOSE

side of the moonroof switch.
Depending on the environment or driving condi-

tions, the auto reverse function may be activated

if an impact or load similar to something being

caught in the moonroof occurs.

If the moonroof does not operate

If the moonroof does not operate properly,

perform the following procedure to initialize the

moonroof operation system.
1. If the moonroof is open, close it fully by

repeatedly pushing the CLOSE

side of

the moonroof switch.

2. Push and hold the CLOSE

side of the

moonroof switch to tilt the moonroof up.

3. Release the moonroof switch after the

moonroof moves slightly up and down.

4. Push and hold the OPEN

side of the

moonroof switch to fully tilt the moonroof

down.

5. Check if the moonroof switch operates

normally.

If the moonroof does not operate properly after

performing the procedure above, have your

vehicle checked by an INFINITI dealer.

SIC3243

Instruments and controls

2-53

—

07/05/07—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MAP LIGHTS

Push the button as illustrated to turn the light

on or off.

PERSONAL LIGHTS (Sedan)
Rear

Push the button as illustrated to turn the light

on or off.

INTERIOR LIGHT CONTROL SWITCH

The interior light control switch has three posi-

tions: ON, DOOR and OFF.

ON position

When the switch is in the ON position

the

map lights and rear personal lights will illumi-

nate.

DOOR position

When the switch is in the DOOR position

, the

map lights and rear personal lights will illumi-

nate under the following conditions:

SIC3249

SIC3250

SIC3251

INTERIOR LIGHTS

2-54

Instruments and controls

—

07/05/07—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

● ignition switch is switched to the LOCK

position

– remain on for about 15 seconds.

● doors are unlocked by pushing the UNLOCK

button on the Intelligent Key or door handle

request switch with the ignition switch in the

LOCK position

– remain on for about 15 seconds.

● any door is opened and then closed with the

ignition switch in the LOCK position

– remain on for about 15 seconds.

● any door is opened with the ignition switch

in the ACC or ON position

– remain on while the door is opened.

When the door is closed, the lights go

off.

The lights will also turn off after 30 minutes

when the lights remain illuminated after the ig-

nition switch has been pushed to the OFF or

LOCK position to prevent the battery from be-

coming discharged.

When the auto interior illumination is set to the

OFF position (see “VEHICLE INFORMATION AND

SETTINGS” in the “4. Monitor, climate, audio,

phone and voice recognition systems” section),

the lights will illuminate under the following

condition:
● any door is opened with the ignition switch

in any position

– remain on while the door is opened.

When the door is closed, the lights go

off.

OFF position

When the switch is in the OFF position

, the

lights will not illuminate, regardless of the

condition.

CAUTION

Do not use for extended periods of time with

the engine stopped. This could result in a dis-

charged battery.

Type A

SIC2064

Type B

SIC2555A

VANITY MIRROR LIGHTS

Instruments and controls

2-55

—

07/14/07—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The light on the vanity mirror will turn on when

the cover on the vanity mirror is opened.
When the cover is closed, the light will turn off.
The lights will also turn off after 30 minutes

when the lights remain illuminated to prevent

the battery from becoming discharged.

The light illuminates when the trunk lid is

opened. When the trunk lid is closed, the light

will turn off.
The light will also turn off after 30 minutes when

the light remains illuminated after the ignition

switch has been pushed to the OFF or LOCK po-

sition to prevent the battery from becoming dis-

charged.

HomeLink

T Universal Transceiver provides a

convenient way to consolidate the functions of

up to three individual hand-held transmitters

into one built-in device.
HomeLink

T Universal Transceiver:

● Will operate most Radio Frequency (RF) de-

vices such as garage doors, gates, home and

office lighting, entry door locks and security

systems.

● Is powered by your vehicle’s battery. No

separate batteries are required. If the vehi-

cle’s battery is discharged or is discon-

nected, HomeLink

T will retain all program-

ming.

Once HomeLinkT Universal Transceiver is pro-

grammed, retain the original transmitter for fu-

ture programming procedures (Example: new ve-

hicle purchases). Upon sale of the vehicle, the

programmed HomeLinkT Universal Transceiver

buttons should be erased for security purposes.

For additional information, see “PROGRAMMING

HomeLinkT” later in this section.

TRUNK LIGHT

HOMELINKT UNIVERSAL TRANSCEIVER

2-56

Instruments and controls

—

07/14/07—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING

● Do not use HomeLinkT Universal Transceiver

with any garage door opener that lacks

safety stop and reverse features as required

by federal safety standards. (These stan-

dards became effective for opener models

manufactured after April 1, 1982.) A garage

door opener which cannot detect an object in

the path of a closing garage door and then

automatically stop and reverse, does not

meet current federal safety standards. Using

a garage door opener without these features

increases the risk of serious injury or death.

● During programming procedure, your garage

door or security gate may open or close.

Make sure that people and objects are clear

of the garage door, gate, etc. that you are

programming.

● Your vehicle’s engine should be turned off

while programming HomeLinkT Universal

Transceiver.

PROGRAMMING HOMELINK

To program your HomeLink

T Transceiver to op-

erate a garage door, gate, or entry door opener,

home or office lighting, you need to be at the

same location as the device. Note: Garage door

openers (manufactured after 1996) have “rolling

code protection”. To program a garage door

opener equipped with “rolling code protection”;

you will need to use a ladder to get up to the

garage door opener motor to be able to access

the “smart or learn” program button.

1. To begin, push and hold the 2 outer

HomeLink

T buttons (to clear the memory)

until the indicator light

blinks (after 20

seconds). Release both buttons.

2. Position the end of the hand-held trans-

mitter

1-3

inches

away

from

the

HomeLink

T surface.

SIC3182

Instruments and controls

2-57

—

07/05/07—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3. Using both hands, simultaneously push

and hold both the HomeLink

T button you

want to program and the hand-held trans-

mitter button.

DO NOT release the buttons until step 4

has been completed.

4. Hold down both buttons until the indica-

tor light on HomeLink

T flashes, changing

from a “slow blink” to a “rapid blink”.

This could take up to 90 seconds. When

the indicator light blinks rapidly, both

buttons may be released. The rapidly

flashing light indicates successful pro-

gramming. To activate the garage door or

other programmed device, push and hold

the programmed HomeLink

T button - re-

leasing when the device begins to acti-

vate.

5. If the indicator light on HomeLink

T blinks

rapidly for two seconds and then turns

solid, HomeLink

T has picked up a “rolling

code” garage door opener signal. You will

need to proceed with the next steps to

train HomeLink

T, completing the pro-

gramming may require a ladder and an-

other person for convenience.

6. Push and release the program button

located on the garage door opener’s mo-

tor to activate the “training mode”. This

button is usually located near the an-

tenna wire that hangs down from the

motor. If the wire originates from under a

light lens, you will need to remove the

lens to access the training button.

NOTE:
Once you have pushed and released the training

button on the garage door opener’s motor and

the “training light” is lit, you have 30 seconds in

which to perform step 7. For convenience, use

the help of a second person to assist when per-

forming this step.
7. Quickly (within 30 seconds of pushing

and releasing the garage door opener

training button) and firmly push and re-

lease the HomeLink

T button you’ve just

programmed. Push and release the

HomeLink

T button up to three times to

complete the training.

8. Your HomeLink

T button should now be

programmed. To program the remaining

HomeLink

T buttons for additional door or

gate openers, follow steps 2 through 8

only.

NOTE:
Do not repeat step 1 unless you want to “clear”

all previously programmed HomeLinkT buttons.
If you have any questions or are having diffi-

culty programming your HomeLink

T buttons,

please refer to the HomeLink

T web site at:

www.homelink.com or call 1-800-355-3515.

SIC3183

2-58

Instruments and controls

—

07/14/07—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

PROGRAMMING HOMELINK

T FOR

CANADIAN CUSTOMERS

Prior to 1992, D.O.C. regulations required hand-

held transmitters to stop transmitting after 2

seconds. To program your hand-held transmit-

ter to HomeLink

T, continue to push and hold

the HomeLink

T button (note steps 2 through 4

under “Programming HomeLink

T”) while you

push and re-push (“cycle”) your hand-held

transmitter every 2 seconds until the indicator

light flashes rapidly (indicating successful

programming).

NOTE:
If programming a garage door opener, etc., it is

advised to unplug the device during the “cy-

cling” process to prevent possible damage to

the garage door opener components.

OPERATING THE HOMELINK

UNIVERSAL TRANSCEIVER

HomeLink

T Universal Transceiver (once pro-

grammed) may now be used to activate the

garage door, etc. To operate, simply push the

appropriate programmed HomeLink

T Universal

Transceiver button. The red indicator light will

illuminate while the signal is being transmitted.

PROGRAMMING TROUBLE-DIAGNOSIS

If HomeLink

T does not quickly learn the hand-

held transmitter information:
● replace the hand-held transmitter batteries

with new batteries.

● position the hand-held transmitter with its

battery

area

facing

away

from

the

HomeLink

T surface.

● push and hold both the HomeLinkT and

hand-held transmitter buttons without inter-

ruption.

● position the hand-held transmitter 2 to 5 in

(50 to 127 mm) away from the HomeLink

surface. Hold the transmitter in that position

for up to 15 seconds. If HomeLink

T is not

programmed within that time, try holding

the transmitter in another position - keeping

the indicator light in view at all times.

If you continue to have programming difficul-

ties, please contact the INFINITI Consumer Af-

fairs Department. The phone numbers are lo-

cated in the Foreword of this Owner’s Manual.

CLEARING THE PROGRAMMED

INFORMATION

Individual buttons cannot be cleared, however

to clear all programming, push and hold the two

outside buttons and release when the indicator

light begins to flash (in approximately 20 sec-

onds).

REPROGRAMMING A SINGLE

HOMELINK

T BUTTON

To reprogram a HomeLink

T Universal Trans-

ceiver button, complete the following.
1. Push and hold the desired HomeLink

button.

Do not release the button until

step 4 has been completed.

2. When the indicator light begins to flash

slowly (after 20 seconds), position the

hand-held transmitter 2 to 5 in (50 to 127

mm) away from the HomeLink

T surface.

3. Push and hold the hand-held transmitter

button.

4. The HomeLink

T indicator light will flash,

first slowly and then rapidly. When the

indicator light begins to flash rapidly,

release both buttons.

Instruments and controls

2-59

—

07/14/07—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The HomeLink

T Universal Transceiver button

has now been reprogrammed. The new device

can be activated by pushing the HomeLink

button that was just programmed. This proce-

dure will not affect any other programmed

HomeLink

T buttons.

IF YOUR VEHICLE IS STOLEN

If your vehicle is stolen, you should change the

codes of any non-rolling code device that has

been programmed into HomeLink

T. Consult the

Owner’s Manual of each device or call the

manufacturer or dealer of those devices for

additional information.

When your vehicle is recovered, you will need to

reprogram the HomeLinkT Universal Transceiver

with your new transmitter information.
FCC Notice:
This device complies with FCC rules part 15. Op-

eration is subject to the following two condi-

tions: (1) This device may not cause harmful in-

terference and (2) This device must accept any

interference that may be received, including in-

terference that may cause undesired operation.
The transmitter has been tested and complies

with FCC and DOC/MDC rules. Changes or modi-

fications not expressly approved by the party

responsible for compliance could void the user’s

authority to operate the device.
DOC: ISTC 1763K1313
FCC I.D.: CB2V67690

2-60

Instruments and controls

—

07/05/07—pattie

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Infiniti G35 (2008 year). Manual - part 8
