Infiniti QX56 (Z62). Manual - part 9

DRIVER SEAT CONTROL UNIT

ADP-29

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

K

L

M

A

B

ADP

N

O

P

19

(B/R)

Ground

Lifting sensor (front)
signal

Input

Seat lifting (front)

Operate

Other than the
above

0 or 5

20

(B/L)

Ground

Lifting sensor (rear)
signal

Input

Seat lifting (rear)

Operate

Other than the
above

0 or 5

21

(W/B)

Ground

Tilt sensor signal

Input

Steering tilt

Operate

Other than the
above

0 or 5

22

(W/L)

Ground

Memory switch 1 sig-
nal

Input

Memory switch 1

Press

0

Other than the
above

5

23

(W/R)

Ground

Memory indicator 1
signal

Output

Memory indicator
1

Illuminate

1

Other than the
above

12

24

(V/W)

Ground

Sliding switch forward
signal

Input

Sliding switch

Operate
(forward)

0

Other than the
above

12

25

(Y/B)

Ground

Reclining switch for-
ward signal

Input

Reclining switch

Operate
(forward)

0

Other than the
above

12

26

(Y/R)

Ground

Lifting switch (front) up
signal

Input

Lifting switch
(front)

Operate
(up)

0

Other than the
above

12

27

(Y/L)

Ground

Lifting switch (rear) up
signal

Input

Lifting switch
(rear)

Operate
(up)

0

Other than the
above

12

28

(G)

Ground

Set switch signal

Input

Set switch

Press

0

Other than the
above

5

JMJIA0119ZZ

JMJIA0119ZZ

JMJIA0119ZZ

ADP-30

< ECU DIAGNOSIS INFORMATION >

DRIVER SEAT CONTROL UNIT

Fail Safe

INFOID:0000000006248318

The fail-safe mode may be activated if the following symptoms are observed.

33

(R)

Ground

Battery power supply

Input

—

Battery voltage

34

(B)

Ground

Sliding motor back-
ward output signal

Output

Seat sliding

Operate
(backward)

12

Other than the
above

0

35

(G)

Ground

Reclining motor for-
ward output signal

Output

Seat reclining

Operate
(forward)

12

Other than the
above

0

36

(L)

Ground

Lifting motor (front)
down output signal

Output

Seat lifting (front)

Operate
(down)

12

Other than the
above

0

38

(GR)

Ground

Sliding motor forward
output signal

Output

Seat sliding

Operate
(forward)

12

Other than the
above

0

39

(Y)

Ground

Reclining motor back-
ward output signal

Output

Seat reclining

Operate
(backward)

12

Other than the
above

0

40

(W)

Ground

Lifting motor (front) up
output signal

Output

Seat lifting (front)

Operate
(up)

12

Other than the
above

0

41

(V)

Ground

Lifting motor (rear) up
output signal

Output

Seat lifting (rear)

Operate
(up)

12

Other than the
above

0

42

(P/B)

Ground

Lifting motor (rear)
down output signal

Output

Seat lifting (rear)

Operate
(down)

12

Other than the
above

0

43

(LG)

Ground

Ground

—

—

0

Operating in

fail-safe mode

Malfunction Item

Related

DTC

Diagnosis

Only manual functions operate normally.

CAN communication

U1000

ADP-56

CONTROL UNIT

U1010

ADP-57

EEPROM

B2130

ADP-66

Only manual functions, except door mirror, operate normally.

UART communication

B2128

ADP-64

Only manual functions, except seat sliding, operate normally.

Seat sliding output

B2112

ADP-58

Only manual functions, except seat reclining, operate normally.

Seat reclining output

B2113

ADP-60

Only manual functions, except steering tilt, operate normally.

Steering column tilt output

B2116

ADP-62

DRIVER SEAT CONTROL UNIT

ADP-31

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

K

L

M

A

B

ADP

N

O

P

DTC Index

INFOID:0000000006248319

*1

:

• 0: Current malfunction is present

• 1-39: Displayed if any previous malfunction is present when current condition is normal. The numeral value increases by one at each

IGN ON to OFF cycle from 1 to 39. The counter remains at 39 even if the number of cycles exceeds it. However, the counter is reset
to 1 if any malfunction is detected again, the normal operation is resumed and the ignition switch is turned from OFF to ON.

CONSULT-III

display

Timing

*1

Item

Reference page

Current mal-

function

Previous mal-

function

CAN COMM CIRCUIT
[U1000]

0

1-39

CAN communication

ADP-56

CONTROL UNIT
[U1010]

0

1-39

Control unit

ADP-57

SEAT SLIDE
[B2112]

0

1-39

Seat slide motor output

ADP-58

SEAT RECLINING
[B2113]

0

1-39

Seat reclining motor output

ADP-60

STEERING TILT
[B2116]

0

1-39

Tilt motor output

ADP-62

UART COMM
[B2128]

0

1-39

UART communication

ADP-64

EEPROM
[B2130]

0

1-39

EEPROM

ADP-66

ADP-32

< ECU DIAGNOSIS INFORMATION >

AUTOMATIC DRIVE POSITIONER CONTROL UNIT

AUTOMATIC DRIVE POSITIONER CONTROL UNIT

Reference Value

INFOID:0000000006248320

TERMINAL LAYOUT

PHYSICAL VALUES

JMJIA3671ZZ

Terminal No.

(wire color)

Description

Condition

Voltage (V)

(Approx.)

+

-

Signal name

Input/

Output

1

(Y)

Ground

Tilt switch up signal

Input

Tilt switch

Operate
(up)

0

Other than the
above

5

2

(GR/B)

Ground

Changeover switch RH
signal

Input

Changeover
switch position

RH

0

Neutral or LH

5

3

(Y/G)

Ground

Mirror switch up signal

Input

Mirror switch

Operated
(up)

0

Other than the
above

5

4

(GR/R)

Ground

Mirror switch left signal

Input

Mirror switch

Operated
(left)

0

Other than the
above

5

5

(R/B)

Ground

Door mirror sensor (pas-
senger side) up/down
signal

Input

Door mirror RH position

Change between 3.4 (close to
peak) 0.6 (close to valley)

6

(L/Y)

Ground

Door mirror sensor (driv-
er side) up/down signal

Input

Door mirror LH position

Change between 3.4 (close to
peak) 0.6 (close to valley)

7

(P)

Ground

Telescopic switch for-
ward signal

Input

Telescopic
switch

Operate
(forward)

0

Other than the
above

5

8

(LG/R)

Ground

UART communication
(TX/RX)

Output

Ignition switch ON

JMJIA1391ZZ
