DTC P1442 EVAP CONTROL SYSTEM EC-541 C D E F G H I J K L M A EC 10. CHECK IF EVAP CANISTER SATURATED WITH WATER 1. Remove EVAP canister with EVAP canister vent control valve attached. 2. Does water drain from the EVAP canister? Yes or No Yes >> GO TO 11. No (With CONSULT-II)>>GO TO 13. 11. CHECK EVAP CANISTER Weigh the EVAP canister with the EVAP canister vent control valve attached. OK or NG OK (With CONSULT-II)>>GO TO 13. >> GO TO 12. 12. DETECT MALFUNCTIONING PART Check the following. ● EVAP canister for damage ● EVAP hose between EVAP canister and water separator for clogging or poor connection >> Repair hose or replace EVAP canister. 13. CHECK EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE OPERATION With CONSULT-II 1. Disconnect vacuum hose to EVAP canister purge volume control solenoid valve at EVAP service port. 2. Start engine. 3. Perform “PURG VOL CONT/V” in “ACTIVE TEST” mode. 4. Touch “Qu” on CONSULT-II screen to increase “PURG VOL 5. Check vacuum hose for vacuum when revving engine up to OK or NG OK >> GO TO 16. NG >> GO TO 15. SEF596U PBIB0147E |
