DTC P0443 EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE EC-1109 [VK45DE] C D E F G H I J K L M A EC On Board Diagnosis Logic NBS005H6 DTC Confirmation Procedure NBS005H7 NOTE: ° C (41 ° F) or more. WITH CONSULT-II 1. Start engine and warm it up to normal operating temperature. 2. Turn ignition switch OFF and wait at least 10 seconds. 3. Turn ignition switch ON. 4. Select “PURG VOL CN/V P1444” of “EVAPORATIVE SYSTEM” in “DTC WORK SUPPORT” mode with 5. Touch “START”. 6. Start engine and let it idle until “TESTING” on CONSULT-II changes to “COMPLETED”. (It will take 7. Make sure that “OK” is displayed after touching “SELF-DIAG RESULTS”. If “NG” is displayed, refer to WITH GST 1. Start engine and warm it up to normal operating temperature. 2. Turn ignition switch OFF and wait at least 10 seconds. 3. Start engine and let it idle for at least 20 seconds. 4. Select Service $07 with GST. 5. If 1st trip DTC is detected, go to EC-1112, "Diagnostic Procedure" DTC No. Trouble diagnosis name DTC detecting condition Possible cause P0443 EVAP canister purge The canister purge flow is detected during the ● EVAP control system pressure sensor ● EVAP canister purge volume control ● EVAP canister vent control valve ● EVAP canister ● Hoses PBIB0839E |
