DTC P2138 APP SENSOR EC-645 [VQ35DE] C D E F G H I J K L M A EC 15. REPLACE ACCELERATOR PEDAL ASSEMBLY 1. Replace accelerator pedal assembly. 2. Perform EC-86, "Accelerator Pedal Released Position Learning" 3. Perform EC-86, "Throttle Valve Closed Position Learning" 4. Perform EC-86, "Idle Air Volume Learning" >> INSPECTION END 16. CHECK INTERMITTENT INCIDENT Refer to EC-153, "TROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENT" >> INSPECTION END Component Inspection NBS0057F ACCELERATOR PEDAL POSITION SENSOR 1. Reconnect all harness connectors disconnected. 2. Turn ignition switch ON. 3. Check voltage between ECM terminals 106 (APP sensor 1 sig- 4. If NG, replace accelerator pedal assembly and go to next step. 5. Perform EC-86, "Accelerator Pedal Released Position Learning" 6. Perform EC-86, "Throttle Valve Closed Position Learning" 7. Perform EC-86, "Idle Air Volume Learning" Removal and Installation NBS0057G ACCELERATOR PEDAL Refer to ACC-3, "ACCELERATOR CONTROL SYSTEM" Terminal Accelerator pedal Voltage 106 Fully released 0.4 - 1.1V Fully depressed 3.7 - 4.8V 98 Fully released 0.20 - 0.55V Fully depressed 1.85 - 2.40V MBIB0023E |
