TROUBLE DIAGNOSIS

How to Erase Self-diagnostic Results

1.

Touch “SELF-DIAG RESULTS” on “SELECT DIAG MODE”
screen.

2.

Touch ”ERASE”. (The self-diagnostic results will be erased.)

DATA MONITOR MODE
Operation Procedure

1.

Touch “DATA MONITOR” on “SELECT DIAG MODE” screen.

NOTE:
When malfunctions detected, CONSULT-II performs “REAL-
TIME DIAGNOSIS”. Also, any malfunction detected while in
this mode will be displayed at real time.

Display Items List

 X: Standard, —: Not applicable,

: Option

BCIA0031E

PCIA0061E

BCIA0031E

Monitored item (Unit)

Monitor Item Selection

Remarks

ECU

INPUT

SIGNALS

MAIN SIG-

NALS

SELEC-

TION

FROM
MENU

VHCL/S SE-A/T (km/h)

X

X

Revolution sensor

VHCL/S SE-MTR (km/h)

X

—

ACCELE POSI (0.0/8)

X

—

Accelerator pedal position signal

THROTTLE POSI (0.0/8)

X

X

Degree of opening for accelerator recognized by
the TCM.
For fail-safe operation, the specific value used
for control is displayed.

CLSD THL POS (ON/OFF)

X

—

Signal input with CAN communications.

W/O THL POS (ON/OFF)

X

—

BRAKE SW (ON/OFF)

X

—

Stop lamp switch

TROUBLE DIAGNOSIS

AT-97

D

E

F

G

H

I

J

K

L

M

A

B

AT

GEAR

—

X

Gear position recognized by the TCM updated
after gear-shifting.

ENGINE SPEED (rpm)

X

X

TURBINE REV (rpm)

X

X

OUTPUT REV (rpm)

X

X

GEAR RATIO

—

X

TC SLIP SPEED (rpm)

—

X

Difference between engine speed and torque
converter input shaft speed.

F SUN GR REV (rpm)

—

—

F CARR GR REV (rpm)

—

—

ATF TEMP SE 1 (V)

X

—

ATF TEMP SE 2 (V)

X

—

ATF TEMP 1 (

°

C)

—

X

ATF TEMP 2 (

°

C)

—

X

BATTERY VOLT (V)

X

—

ATF PRES SW 1 (ON/OFF)

X

X

(for FR/B solenoid)

ATF PRES SW 2 (ON/OFF)

X

X

(for LC/B solenoid)

ATF PRES SW 3 (ON/OFF)

X

X

(for I/C solenoid)

ATF PRES SW 5 (ON/OFF)

X

X

(for D/C solenoid)

ATF PRES SW 6 (ON/OFF)

X

X

(for HLR/C solenoid)

PNP SW 1 (ON/OFF)

X

—

PNP SW 2 (ON/OFF)

X

—

PNP SW 3 (ON/OFF)

X

—

PNP SW 4 (ON/OFF)

X

—

1 POSITION SW (ON/OFF)

X

—

SLCT LVR POSI

—

X

Selector lever position is recognized by the
TCM.
For fail-safe operation, the specific value used
for control is displayed.

OD CONT SW (ON/OFF)

X

—

Not mounted but displayed.

POWERSHIFT SW (ON/OFF)

X

—

HOLD SW (ON/OFF)

X

—

MANU MODE SW (ON/OFF)

X

—

NON M-MODE SW (ON/OFF)

X

—

UP SW LEVER (ON/OFF)

X

—

DOWN SW LEVER (ON/OFF)

X

—

Monitored item (Unit)

Monitor Item Selection

Remarks

ECU

INPUT

SIGNALS

MAIN SIG-

NALS

SELEC-

TION

FROM
MENU

AT-98

TROUBLE DIAGNOSIS

SFT UP ST SW (ON/OFF)

—

—

Not mounted but displayed.

SFT DWN ST SW (ON/OFF)

—

—

ASCD·OD CUT (ON/OFF)

—

—

ASCD·CRUISE (ON/OFF)

—

—

ABS SIGNAL (ON/OFF)

—

—

ACC OD CUT (ON/OFF)

—

—

Intelligent cruise control (ICC) system

ACC SIGNAL (ON/OFF)

—

—

TCS GR/P KEEP (ON/OFF)

—

—

TCS SIGNAL 2 (ON/OFF)

—

—

TCS SIGNAL 1 (ON/OFF)

—

—

TCC SOLENOID (A)

—

X

LINE PRES SOL (A)

—

X

I/C SOLENOID (A)

—

X

FR/B SOLENOID (A)

—

X

D/C SOLENOID (A)

—

X

HLR/C SOL (A)

—

X

ON OFF SOL (ON/OFF)

—

—

LC/B solenoid

TCC SOL MON (A)

—

—

L/P SOL MON (A)

—

—

I/C SL MON (A)

—

—

FR/B SOL MON (A)

—

—

D/C SOL MON (A)

—

—

HLR/C SOL MON (A)

—

—

ON OFF SOL MON (ON/OFF)

—

—

LC/B solenoid

P POSI IND (ON/OFF)

—

—

R POSI IND (ON/OFF)

—

—

N POSI IND (ON/OFF)

—

—

D POSI IND (ON/OFF)

—

—

4TH POSI IND (ON/OFF)

—

—

3RD POSI IND (ON/OFF)

—

—

2ND POSI IND (ON/OFF)

—

—

1ST POSI IND (ON/OFF)

—

—

MANU MODE IND (ON/OFF)

—

—

POWER M LAMP (ON/OFF)

—

—

F-SAFE IND/L (ON/OFF)

—

—

Monitored item (Unit)

Monitor Item Selection

Remarks

ECU

INPUT

SIGNALS

MAIN SIG-

NALS

SELEC-

TION

FROM
MENU
