Power Steering NHST0036 Applied model All Steering gear type PR26AD Rack sliding force N (kg, lb) Under normal operating oil pres- Range within ± 11.5 mm ( ± 0.453 in) from the neutral position at rack Average force 216 - 284 (22 - 29, 49 - 64) Maximum force deviation 98 (10, 22) Except for the above range Maximum sliding force 294 (30, 66) Maximum force deviation 147 (15, 33) Steering wheel turning force N (kg, lb) 39 (4, 9) or less Fluid capacity (Approximate) (US qt, Imp qt) 1.0 (1-1/8, 7/8) Oil pump maximum pressure kPa (kg/cm 2 , psi) 8,140 - 8,728 (83 - 89, 1,180 - 1,266) GI MA EM LC EC FE AT AX SU BR RS BT HA SC EL IDX SERVICE DATA AND SPECIFICATIONS (SDS) Power Steering ST-31 |
