Key to Symbols Signifying Measurements or NHGI0006S02 Symbol Symbol explanation Symbol Symbol explanation Check after disconnecting the con- Procedure with Generic Scan Tool Check after connecting the connector Procedure without CONSULT-II or Insert key into ignition switch. A/C switch is “OFF”. Remove key from ignition switch. A/C switch is “ON”. Turn ignition switch to “OFF” position. REC switch is “ON”. Turn ignition switch to “ON” position. REC switch is “OFF”. Turn ignition switch to “START” posi- Fan switch is “ON”. (At any position Turn ignition switch from “OFF” to Fan switch is “OFF”. Turn ignition switch from “ACC” to Apply positive voltage from battery Turn ignition switch from “OFF” to Drive vehicle. Turn ignition switch from “ON” to Disconnect battery negative cable. Do not start engine, or check with Depress brake pedal. Start engine, or check with engine Release brake pedal. Apply parking brake. Depress accelerator pedal. Release parking brake. Release accelerator pedal. MA EM LC EC FE AT AX SU BR ST RS BT HA SC EL IDX HOW TO FOLLOW TROUBLE DIAGNOSES Key to Symbols Signifying Measurements or Procedures GI-37 |
