RFD-50 REAR FINAL DRIVE ASSEMBLY 7. If the turning torque is outside the specification, use a thicker/ 60, "Side Bearing Adjusting Washer" CAUTION: Select a side bearing adjusting washer for right and left 8. Record the total amount of washer thickness required for the correct carrier side bearing preload. Pinion Gear Height 1. Make sure all parts are clean and that the bearings are well 2. Assemble the pinion gear bearings into the differential shim ● Pinion front bearing; make sure the J-34309-3 pinion front ● Pinion rear bearing; the pinion rear bearing pilot, J-34309-8, ● Installation of J-34309-9 and J-34309-16; place a suitable 3. Install the pinion rear bearing inner race into gear carrier. Then If the turning torque is less than the specified range: Use a thicker thrust washer. If the turning torque is greater than the specification: Use a thinner thrust washer. SPD772 Tool number : — (J-34309) SPD769 SPD197A SPD893 |
