SE-12

< SERVICE INFORMATION >

AUTOMATIC DRIVE POSITIONER

AUTOMATIC DRIVE POSITIONER

System Description

INFOID:0000000001328097

• The system automatically moves the driver seat to facilitate entry/exit to/from the vehicle. The automatic

drive positioner control unit can also store the optimum driving positions (driver seat, steering wheel position
(tilt, telescopic) and door mirror position) for 2 people. If the driver is changes, one-touch operation allows
changing to the other driving position.

• The settings (ON/OFF) of the automatic sliding seat (Entry/Exiting operation) at entry/exit can be changed

as desired, using the display unit in the center of the instrument panel. The set content is transmitted by
CAN communication, from display control unit to driver seat control unit.

• Using CONSULT-III, the seat slide and steering wheel amount at entry/exit setting can be changed.

MANUAL OPERATION

The driving position [seat position, steering wheel position (tilt, telescopic) and door mirror position] can be
adjusted with the power seat switch or ADP steering switch or door mirror remote control switch.
NOTE:
• The seat can be manually operated with the ignition switch OFF.
• The door mirrors can be manually operated with the ignition switch turned ACC or ON.

AUTOMATIC OPERATION

NOTE:

• Disconnecting the battery erases the stored memory.

• After connecting the battery, insert the key into the ignition cylinder and turn the driver door switch ON (open)

→

OFF (close)

→

(open), the Entry/ Exiting operation becomes possible.

• After exiting operation is carried out, return operation can be operated.

NOTE:

During automatic operation, if the ignition switch is turned ON

→

START, the automatic operation is suspended. When the ignition switch

returns to ON, it resumes.

MEMORY STORING AND KEYFOB INTERLOCK STORING

• Store the 2 driving positions and shifts to the stored driving position with the memory switch.

Function Description

Memory switch operation

The seat, steering and door mirror move to the stored driving position by pushing
memory switch (1 or 2).

Entry/Exiting function

Exiting operation

At exit, the seat moves backward and steering wheel moves forward/upward.

Entry operation

At entry, the seat and steering wheel returns from the exiting position to the previous
driving position.

keyfob interlock operation

Perform memory operation, exiting operation and entry operation by pressing keyfob
unlock button.

Auto operation temporary stop
conditions.

When ignition switch turned to START during memory switch operation and return opera-
tion, memory switch operation and entry operation is stopped.

Auto operation stop conditions.

• When the vehicle speed becomes 7 km/h (4 MPH) or higher.
• When the setting switch, memory switch 1, or 2 are pressed.
• When A/T selector lever is in any position other than P.
• When the door mirror remote control switch is operated (when ignition switch turned to

ON or ACC).

• When power seat switch turned ON.
• When ADP steering switch turned ON (telescopic operation or tilt operation).
• When door mirror operates (only memory switch operation).
• When driver seat sliding Entry/Exiting setting is OFF (only entry/exiting operation).
• When steering wheel tilt and telescopic Entry/Exiting setting is OFF (only entry/exiting op-

eration).

• When the tilt and telescopic sensor malfunction is detected.

AUTOMATIC DRIVE POSITIONER

SE-13

< SERVICE INFORMATION >

• Keyfob interlock function is set simultaneously with setting driving position memory. It can set driving posi-

tion to memory position.

NOTE:
• If another keyfob interlock function setting is performed by same key, newly registered setting is valid.
• If new memory string is performed to memory switch that already set keyfob interlock function, keyfob inter-

lock function setting is reset.

• If key does not set previously, keyfob interlock function cannot set.

MEMORY SWITCH OPERATION

PIIB3487E
