AT-132 < SERVICE INFORMATION > DTC P1710 A/T FLUID TEMPERATURE SENSOR CIRCUIT DTC P1710 A/T FLUID TEMPERATURE SENSOR CIRCUIT Description INFOID:0000000001327233 The A/T fluid temperature sensor detects the A/T fluid temperature and sends a signal to the TCM. CONSULT-III Reference Value in Data Monitor Mode INFOID:0000000001327234 On Board Diagnosis Logic INFOID:0000000001327235 Diagnostic trouble code “P1710 (A/T), P0710 (ENGINE) ATF TEMP SEN/CIRC” with CONSULT-III or 10th Possible Cause INFOID:0000000001327236 • Harness or connectors (Sensor circuit is open or shorted.) • A/T fluid temperature sensors 1 and/or 2 DTC Confirmation Procedure INFOID:0000000001327237 CAUTION: Always drive vehicle at a safe speed. WITH CONSULT-III 1. Turn ignition switch ON. 2. Select “SELECTION FROM MENU” in “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III 3. Touch “START”. 4. Start engine and maintain the following conditions for at least 10 minutes (Total). (It is not necessary to 5. If DTC is detected, go to WITH GST Follow the procedure “WITH CONSULT-III”. Item name Condition ° C ( ° F) Display value (Approx.) ATF TEMP SE 1 0 (32) - 20 (68) - 80 (176) 3.3 - 2.7 - 0.9 V ATF TEMP SE 2 3.3 - 2.5 - 0.7 V |
