BRM-26

< REMOVAL AND INSTALLATION >

BODY ALIGNMENT

Dimensions marked with

″

*

″

 indicate symmetrically identical dimensions on both right and left hand of the

vehicle.

Measurement Points

Unit: mm (in)

: Vehicle front

: Bolt head

JSKIA0563GB

BODY ALIGNMENT

BRM-27

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

BRM

N

O

P

Unit: mm (in)

: Vehicle front

Points

Coordinates

Remarks

Points

Coordinates

Remarks

X

Y

Z

X

Y

Z

A, a

±

416

-496

225

Hole

φ

13 (0.51)

J, j

±

473

2554

114

Bolt head

B, b

±

415

-104

134

Bolt head

K, k

±

452

3114

179

Bolt head

C, c

±

392

414

65

Bolt head

M

550

3215

316

Hole

φ

8 (0.31)

D, d

±

428

817

80

Hole 16

×

18 (0.63

×

0.71)

m

-500

3223

318

Hole

φ

8 (0.31)

E, e

±

438

1100

78

Hole

φ

16 (0.63)

N, n

±

533

3425

315

Hole

φ

16 (0.63)

F, f

±

438

1356

79

Hole

φ

14 (0.55)

O, o

±

423

38

675

Hole

φ

50 (1.97)

G, g

±

438

1760

81

Hole

φ

16 (0.63)

P, p

±

531

2643

516

Hole

φ

64 (2.52)

H, h

±

604

2341

128

Hole

φ

13 (0.51)

JSKIA0564ZZ

BRM-28

< REMOVAL AND INSTALLATION >

BODY ALIGNMENT

Underbody (AWD)

INFOID:0000000003758223

Measurement

Dimensions marked with

″

*

″

 indicate symmetrically identical dimensions on both right and left hand of the

vehicle.

Unit: mm (in)

JSKIA0565GB

BODY ALIGNMENT

BRM-29

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

BRM

N

O

P

Measurement Points

Unit: mm (in)

: Vehicle front

: Bolt head

: Vehicle front

Points

Coordinates

Remarks

Points

Coordinates

Remarks

X

Y

Z

X

Y

Z

A, a

±

416

-496

225

Hole

φ

13 (0.51)

J, j

±

473

2554

114

Bolt head

B, b

±

411

-261

106

Bolt head

K, k

±

452

3114

179

Bolt head

C, c

±

395

76

130

Bolt head

M

550

3215

316

Hole

φ

8 (0.31)

D, d

±

428

817

80

Hole 16

×

18 (0.63

×

0.71)

m

-500

3223

318

Hole

φ

8 (0.31)

E, e

±

438

1100

78

Hole

φ

16 (0.63)

N, n

±

533

3425

315

Hole

φ

16 (0.63)

F, f

±

438

1356

79

Hole

φ

16 (0.63)

O, o

±

423

38

675

Hole

φ

50 (1.97)

JSKIA0567ZZ
