Instrument Cluster
Type A
Type B
Type A
Type B
OTMA040014
OOSN041027N
OTMA040016
OOSN041028N
Since refuel(l)ing
Accumulated info
Trip distance (1), average fuel economy
Accumulated trip distance (1), average
(2), and total driving time (3) after the
fuel economy (2), and total driving time
vehicle has been refueled are displayed.
(3) are displayed.
To reset manually, press the OK switch
The information is accumulated starting
on the steering wheel for more than
from the last reset.
1 second when ‘Since Refueling’ is
To reset manually, press the OK switch
displayed.
on the steering wheel for more than
1 second when ‘Accumulated Info’ is
displayed.
Information
The vehicle must be driven for a minimum
of 0.19 miles (300 meters) since the last
Engine Start/Stop button cycle before the
average fuel economy will be recalculated.
Digital speedometer
OTMA040018
This message shows the speed of the
vehicle.
4-38

-------------------------------------------------------------------------------------------------------------------------------------------------------------

04
VEHICLE SETTINGS (INFOTAINMENT SYSTEM)
Vehicle Settings in the infotainment
Setting Your Vehicle
system provides user options for a
variety of settings including door lock/
unlock features, convenience features,
driver assistance settings, etc.
OCN7N041093
1. Press the SETUP button on the head
unit of the infotainment system.
OCN7N041122L
Vehicle Settings menu
- Driver Assistance
- Cluster
- Climate
- Light
- Door
- Convenience
The information provided may differ
OCN7N041093L
depending on which features are
2. Select ‘Vehicle’ and change the
applicable to your vehicle.
setting of the features.
WARNING
Do not operate the Vehicle Settings
while driving. This may cause
distraction resulting in an accident.
OCN7N041123L
For detailed information, refer to the
separately supplied infotainment
system manual.
4-39

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5. Convenience Features
Smart key
5-4
Locking
5-4
Unlocking your vehicle (When the Two Press Unlock feature is off)
5-5
Unlocking your vehicle (When the Two Press Unlock feature is on)
5-6
Trunk Unlocking
5-7
Panic Button
5-7
Remotely Starting Vehicle
5-7
Start-up
5-8
Mechanical Key
5-8
Loss of a Smart Key
5-8
Smart Key Precautions
5-9
Battery Replacement
5-10
Immobilizer System
5-11
Hyundai Digital Key
5-12
Operating Door Locks from Outside the Vehicle
5-27
Operating Door Locks from Inside the Vehicle
5-28
Automatic Door Lock and Unlock Features
5-30
Child-Protector Rear Door Locks
5-30
Rear Occupant Alert (ROA)
5-31
Rear Occupant Alert Operation
5-31
5
Theft-Alarm System
5-32
Steering Wheel
5-33
Electric Power Steering (EPS)
5-33
Tilt Steering / Telescope Steering
5-34
Horn
5-34
Mirrors
5-35
Inside Rearview Mirror
5-35
Side View Mirrors
5-46
Windows
5-48
Power Windows
5-49
Sunroof
5-52
Sunshade
5-52
Tilt Open/Close
5-53
Slide Open/Close
5-53
Automatic Reversal
5-54
Resetting the Sunroof
5-55
Sunroof Open Warning
5-55

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Hood
5-56
Trunk
5-58
Emergency Trunk Safety Release
5-59
Smart Trunk Release
5-60
Fuel Filler Door
5-63
Exterior Lights
5-65
Lighting Control
5-65
High Beam Operation
5-66
Turn Signals And Lane Change Signals
5-67
Battery Saver Function
5-68
Headlamp Delay Function
5-68
High Beam Assist (HBA)
5-69
Detecting Sensor
5-69
High Beam Assist Settings
5-69
High Beam Assist Operation
5-69
High Beam Assist Malfunction and Limitations
5-70
Interior Lights
5-72
Interior Lamp AUTO Cut
5-72
5
Front Lamps
5-72
Rear Lamp
5-73
Luggage Compartment Lamp
5-74
Vanity Mirror Lamp
5-74
Welcome System
5-75
Wipers and Washers
5-76
Windshield wipers
5-76
Windshield Washers
5-77
Manual Climate Control System
5-78
Heating and Air Conditioning
5-79
System Operation
5-85
System Maintenance
5-87
Automatic Climate Control System
5-89
Automatic Heating and Air Conditioning
5-90
Manual Heating and Air Conditioning
5-91
System Operation
5-97
System Maintenance
5-99

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5. Convenience Features
Windshield Defrosting and Defogging
5-101
Manual Climate Control System
5-101
Automatic Climate Control System
5-102
Defogging Logic
5-103
Auto Defogging System (only for automatic climate control system)
5-104
Defroster
5-105
Climate Control Additional Features
5-106
Sunroof Inside Air Recirculation
5-106
Automatic Ventilation
5-106
Storage Compartment
5-107
Center Console Storage
5-107
Glove Box
5-107
Interior Features
5-108
Cup Holder
5-108
Sunvisor
5-109
Power Outlet
5-109
Wireless Cellular Phone Charging System
5-110
Clock
5-112
Coat Hook
5-113
5
Infotainment System
5-114
USB Port
5-114
Antenna
5-114
Steering Wheel Audio Control
5-115
Infotainment System
5-116
Voice Recognition
5-116
Bluetooth® Wireless Technology Hands-free
5-116
How Vehicle Radio Works
5-117

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
SMART KEY
Locking
OCN7N051005N
Your HYUNDAI uses a Smart Key, which
OCN7N051078L
you can use to lock or unlock a door (and
To lock :
trunk) and even start the engine.
1. Close all doors, engine hood and
1. Door Lock
trunk.
2. Door Unlock
2. Carry the smart key.
3. Remote start
3. Either press the door handle button or
4. Trunk Unlock
press the Door Lock button (1) on the
5. Panic
smart key.
4. The hazard warning lights will blink.
Also, the outside rearview mirror
will fold, if ‘Convenience → Welcome
mirror/light → On door unlock’ is
selected from the User Settings mode
on the LCD display. For more details,
refer to “LCD Display” in chapter 4.
5. Make sure the doors are locked by
pulling the door outside handle.
Information
The door handle button will only operate
when the smart key is within 28~40 in.
(0.7~1 m) from the outside door handle.
5-4

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
Even though you press the outside
Unlocking your vehicle
door handle button, the doors will not
(When the Two Press Unlock
lock and the chime will sound for three
feature is off)
seconds if any of the following occur:
Button type
• The Smart Key is in the vehicle.
• The Engine Start/Stop button is in
ACC or ON position.
• Any door except the trunk is open.
WARNING
Do not leave the Smart Key in your
vehicle with unsupervised children.
Unattended children could press the
Engine Start/ Stop button and may
OCN7050078
operate power windows or other
Touch sensor type
controls, or even make the vehicle
move, which could result in serious
injury or death.
OCN7050093N
1. Make sure you have the smart key in
your possession.
2. Press the Door Unlock button (2) on
the smart key, press the button on the
front door handle or touch the door
unlock sensor inside of the front door
handle to unlock the doors.
3. All of the doors will unlock. When the
doors unlock, the hazard warning
lights will blink two times.
• The door handle button will only
operate when the smart key is within
28~40 inches (0.7~1 m) from the
outside door handle.
• If you do not open the door after
unlocking within 30 seconds, it will
return to the lock mode.
• If you unlocked the door with the door
handle, the doors cannot be locked
with the sensor for up to 2 seconds.
5-5

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
Unlocking your vehicle
Two Press Unlock Feature
(When the Two Press Unlock
The priority for unlocking the driver door
feature is on)
only, or unlocking all the doors with
one press may be adjusted in the User
1. Make sure you have the smart key in
Settings mode in the cluster LCD display.
your possession.
The Two Press Unlock feature, when
2. Press the Door Unlock button (2) on
enabled, will require the user to press
the smart key, press the button on the
the door unlock button once for driver
front door handle or touch the door
door only and twice for unlocking all the
unlock sensor inside of the front door
doors.
handle to unlock the doors.
Select or Deselect the Two Press Unlock
3. The driver’s door will unlock.
feature in the User Settings mode in the
4. If you press the button on the front
cluster LCD display. The option can be
door handle or touch the door unlock
found under the following menu:
sensor inside of the front door handle
to unlock the doors within 4 seconds,
User Settings → Door → Two Press Unlock
all of the doors unlock. When the
doors unlock, the hazard warning
lights will blink two times.
Information
• The door handle button will only
If you press the front passenger outside
operate when the smart key is within
door handle with the smart key in your
28~40 inches (0.7~1 m) from the
possession, all the doors will unlock.
outside door handle.
• If you do not open the door after
unlocking within 30 seconds, it will
return to the lock mode.
• The factory default setting is in off
mode so you should set in the User’s
Settings mode.
• If you unlocked the door with the door
handle, the doors cannot be locked
with the sensor for up to 2 seconds.
5-6

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
Trunk Unlocking
Remotely Starting Vehicle
To unlock:
You can start the vehicle using the
Remote Start button (3) on the smart key.
1. Carry the smart key.
To start the vehicle remotely:
2. Either press inside the trunk emblem
or press the Trunk Unlock button (4)
1. Press the door lock button on the
on the smart key for more than one
smart key within 10 m (32 feet) from
second.
the vehicle.
3. The hazard warning lights will blink
2. Press the Remote Start button (3) for
two times.
more than 2 seconds within 4 seconds
after pressing the door lock button.
Once the trunk is opened and then
closed, the trunk will lock automatically.
3. Press the door lock button (1), and
then the hazard warning lights blink
once to alert you.
Information
4. To turn off the remote start function,
After unlocking the trunk, the trunk will
press the Remote Start button (3)
lock automatically after 30 seconds unless
once.
the trunk is opened.
Panic Button
Information
Press and hold the Panic button (5) for
• The vehicle must be in P (Park) for the
more than one second. The horn sounds
remote start function to start.
and hazard warning lights blink for about
• The engine turns off if you get on the
30 seconds. To cancel the panic mode,
vehicle without a registered smart key.
press any button on the Smart Key.
• The engine turns off if you do not get
on the vehicle within 10 minutes after
remotely starting the vehicle.
• The Remote Start button (4) may not
operate if the smart key is not within
10 m (32 feet).
• The vehicle will not remotely start if the
engine hood or trunk is opened.
• Do not idle the engine for a long period.
5-7

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
Start-up
Mechanical Key
You can start the engine without
If the Smart Key does not operate
inserting the key. For detailed
normally, you can lock or unlock the door
information refer to the Engine Start/
by using the mechanical key.
Stop button in chapter 6.
Information
If the smart key is not moved for some
time, the detection function for smart key
operation will pause. Lift the smart key to
activate the detection again.
NOTICE
To prevent damaging the smart key:
OJSN048131
• Keep the smart key away from water
Press and hold the release button (1) and
or any liquid and fire. If the inside
remove the mechanical key (2). Insert the
of the smart key gets damp (due to
mechanical key into the key hole on the
drinks or moisture), or is heated,
door.
internal circuit may malfunction and
may void the vehicle warranty.
To reinstall the mechanical key, put the
key into the hole and push it until a click
• Avoid dropping or throwing the
sound is heard.
smart key.
• Protect the smart key from extreme
Loss of a Smart Key
temperatures.
A maximum of two smart keys can be
registered to a single vehicle. If you
NOTICE
happen to lose your smart key, it is
Always have the smart key with you
recommended that you immediately take
when leaving the vehicle. If the smart
the vehicle and remaining key to your
key is left near the vehicle, the vehicle
authorized HYUNDAI dealer or tow the
battery may be discharged.
vehicle, if necessary.
5-8

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
Smart Key Precautions
Information
The smart key will not work if any of the
This device complies with Part 15 of the
following occur:
FCC rules.
• The smart key is close to a radio
Operation is subject to the following three
transmitter such as a radio station or
conditions:
an airport which can interfere with
1. This device may not cause harmful
normal operation of the smart key.
interference.
• The smart key is near a mobile two
2. This device must accept any
way radio system or a cellular phone.
interference received, including
• Another vehicle’s smart key is being
interference that may cause undesired
operated close to your vehicle.
operation.
When the smart key does not work
3. Changes or modifications not expressly
correctly, open and close the door
approved by the party responsible
with the mechanical key. If you have
for compliance could void the user’s
a problem with the smart key, it is
authority to operate the device.
recommended that you contact an
authorized HYUNDAI dealer.
If the smart key is in close proximity to
Information
your mobile phone, the signal could be
Changes or modifications not expressly
blocked by your mobile phone’s normal
approved by the party responsible
operational signals.
for compliance could void the user’s
This is especially important when the
authority to operate the equipment. If the
phone is active such as making and
keyless entry system is inoperative due
receiving calls, text messaging, and/ or
to changes or modifications not expressly
sending/receiving emails.
approved by the party responsible for
compliance, it will not be covered by your
Avoid placing the smart key and your
manufacturer’s vehicle warranty.
mobile phone in the same location and
always try to maintain an adequate
distance between the two devices.
NOTICE
Keep the smart key away from
electromagnetic materials that blocks
electromagnetic waves to the key
surface.
5-9

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
Battery Replacement
Remove the smart key cover by turning
the screwdriver clockwise by inserting
If the Smart Key is not working properly,
the screwdriver (-) into the hole.
try replacing the battery with a new one.
Battery Type: CR2032
1. Remove the mechanical key.
2. Use a slim tool to pry open the rear
cover of the smart key.
3. Remove the old battery and insert the
new battery. Make sure the battery
position is correct.
4. Reinstall the rear cover of the smart
key.
If you suspect your smart key might have
OCN7N051006
sustained some damage, or you feel
your smart key is not working correctly,
it is recommended that you contact an
authorized HYUNDAI dealer.
Information
An inappropriately disposed
battery can be harmful to
the environment and human
health. Dispose of the battery
according to your local law(s)
and regulation.
OCN7N051007
WARNING
THIS PRODUCT CONTAINS A BUTTON
BATTERY
If swallowed, a lithium button battery
can cause severe or fatal injuries within
2 hours.
Keep batteries out of reach of children.
If you think batteries may have been
swallowed or placed inside any part
of the body, seek immediate medical
attention.
5-10

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
Immobilizer System
WARNING
The immobilizer system helps protect
In order to prevent theft of your
your vehicle from theft. If an improperly
vehicle, do not leave spare keys
coded key (or other device) is used, the
anywhere in your vehicle. Your
engine’s fuel system is disabled.
immobilizer password is a customer
unique password and should be kept
When the Engine Start/Stop button
confidential.
is pressed to the ON position, the
immobilizer system indicator should
NOTICE
come on briefly, then go off. If the
indicator starts to blink, the system does
The transponder in your key is an
not recognize the coding of the key.
important part of the immobilizer
system. It is designed to give years
Press the Engine Start/Stop button to
of trouble-free service, however you
the OFF position, then press the Engine
should avoid exposure to moisture,
Start/Stop button to the ON position
static electricity and rough handling.
again.
Immobilizer system malfunction could
occur.
In some circumstances, the vehicle may
not recognize your smart key if another
Information
smart key device is nearby or a metal
object such as a key chain is causing
This device complies with Part 15 of the
interference with the smart key.
FCC rules.
Operation is subject to the following three
If this occurs, your vehicle may not
conditions:
start. Remove any metal objects or
1. This device may not cause harmful
additional keys near the smart key before
interference.
attempting to start the vehicle again.
2. This device must accept any
interference received, including
If the system repeatedly does not
interference that may cause undesired
recognize the coding of the key, contact
operation.
your HYUNDAI dealer.
3. Changes or modifications not expressly
approved by the party responsible
Do not attempt to alter this system
for compliance could void the user’s
or add other devices to it. Electrical
authority to operate the device
problems could result that may make
your vehicle inoperable.
5-11

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
Hyundai Digital Key
Digital key (smartphone) NFC
(if equipped)
function
Digital Key Application
You can use the Digital Key NFC (Near
Field Communication) function after
To use Hyundai Digital Key mobile app,
turning on your smartphone function in
you should install Hyundai digital key
the NFC settings. And you should unlock
application. Search ‘Hyundai digital key’
& turn on smartphone screen to use it.
in the Google Play Store and download
the app. Please refer to the detailed
 To change the NFC mode of the
manual of the digital key app. The option
smartphone, please refer to the
can be found under the following app
smartphone manual or contact
menu:
to the customer service center of
smartphone manufacturers.
Menu → Application Info → Tutorial
Please note the manual before using the
app.
 This service is only available for
Android smartphones. Please confirm
supported/compatible devices on our
website.
WARNING
For used vehicle
If any of the digital key (smartphone key
or card key) is already registered when
you press ON button after unlocking
the doors, the message ‘Digital key(s)
active’ appears on the instrument
cluster once. If you buy a used vehicle,
you should confirm the message and
delete the registered smartphone key
and card key. In addition, please notify
the Hyundai Customer Care Center.
If the card key does not work properly,
please delete the card key and register
the smartphone key and re-register the
card key.
For vehicle maintenance
If you need to have your Digital Key
System repaired or replaced please
ensure your Smartphone Key is still
active. You may have to pair your phone
again.
In this case, re-initialize your Digital
Keys using the Hyundai Digital Key
mobile app.
5-12

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
Digital key (smartphone)
Information
The [Save] button will be disabled if the
digital key (Smartphone key) is already
saved.
Please refer to “Digital Key Delete” in this
manual and follow the digital key delete
procedure in your car before attempting a
Digital key save.
Please refer to the ‘Tutorial’ on your
Digital key app and delete the previous
saved key in your smartphone before
ODN8A059129
attempting a save.
3. Select the vehicle to save on your
Digital key application and activate
the save mode.
 Save mode is available only on
the vehicle owner’s Digital key
application.
4. Place the backside of smartphone
onto the wireless charging pad(in-
vehicle authentication pad).
ODN8A059240
The saving process will begin
automatically.
Hyundai Digital Key (Smartphone)
Pairing
5. Once the digital key save is complete,
a message will be shown on the
1. Turn the vehicle on with the Smart key
infotainment screen or cluster.
and make sure to keep the smart key
inside the vehicle during digital key
6. Remove the smartphone from the pad
registration.
and complete the saving process.
2. Register your Digital key from the
vehicle user setting menu as follows.
 With Navigation screen :
From the infotainment screen menu,
go to [Setup] - [Vehicle] - [Digital Key]
- [Smart Phone Key] then select the
[Save] from submenu.
 Without navigation screen :
From cluster menu, go to [Digital Key]
- [Smart Phone Key] and select [Save].
OCN7N051070N
[A] : Wireless Charging Pad (In-vehicle Authentication
Pad)
5-13

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
3. Once the digital key delete is
complete, a message will be shown
on the infotainment screen or cluster.
4. Go to [Initialize Digital Key] menu on
the digital key application and select
the vehicle to delete the digital key
information.
• Open the Hyundai Digital Key app →
Menu → Initialize Digital Key
 If the saved digital key information
ODN8A059129
in your car is deleted due to vehicle
maintenance, the digital key in your
smartphone should be deleted as well.
 For more information, please refer to
the ‘Tutorial’ on your Digital key app.
CAUTION
•
If the smartphone is removed
from the interior authentication
pad during enrollment, the saving
process will be canceled.
ODN8A059130
•
If the infotainment or instrument
Hyundai Digital Key (Smartphone Key)
cluster screen is changed during
Deletion
enrollment, the saving process will
be canceled.
1. Turn the vehicle on with the Smart
key and make sure to keep the smart
•
If the vehicle is turned off during
key inside the vehicle during delete
enrollment, the saving process will
process.
be canceled.
2. Delete your Digital key from the
•
If the gear is shifted, the saving
vehicle user setting menu as follows.
process will be canceled.
 With Navigation screen :
•
If you try to save the smartphone
From the infotainment screen menu,
which is not logged in with the
go to [Setup] - [Vehicle] - [Digital Key]
vehicle owner’s ID or if you try to
- [Smart Phone Key] then select the
save the Card key, the saving process
[Delete] from submenu.
will not begin.
 Without navigation screen :
•
If the NFC setting on your
From cluster menu, go to [Digital
smartphone is off, the saving process
Key] - [Smart Phone Key] and select
will not begin.
[Delete].
•
If the smartphone screen is changed
to off or locked status, the saving
process will be canceled.
Information
•
If there is no Smart key during the
The [Delete] button will be disabled if there
save process, the saving process will
is no digital key (Smartphone key) saved.
not begin.
5-14

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
Set up main vehicle
Note that you cannot lock your vehicle
when you touch NFC antenna in the
You can manage multiple digital keys
from the Digital key app. From the list of
smartphone to the door handle pad if
any of the following occurs:
digital keys you own, select the vehicle
you want to make your priority vehicle.
• The Proximity / Smart Key is in the
vehicle.
For more information, please refer to
the ‘Tutorial’ on your Digital key app.
• The POWER button is in ACC or ON
position.
• Any of the doors, hood or trunk is
opened.
If the smartphone digital key does not
work, please remove the smartphone
more than 4 inches (0.1 m) from the door
handle authentication pad and try it
again.
Start-up with Digital Key
1. After placing your registered
smartphone onto the interior
OCN7050128
authentication pad (wireless charger),
[1] : Door handle authentication pad
step on the brake and press the
Engine Start/Stop button.
NFC door lock/unlock
2. After start-up, the digital key data
You should touch your smartphone’s
will be automatically updated. It
NFC antenna(backside of phone) to door
takes 5 to 20 seconds, after that, the
handle authentication pad (1) marked
smartphone will go into the wireless
position near by the lock button) of
charging mode automatically. Once
driver’s (or front passenger’s) outside
the engine is started, you may remove
door for 2 seconds to lock or unlock the
the smartphone from the pad.
doors. If the Two Press Unlock feature
is applied (press twice for unlocking),
driver’s seat door will be unlocked by
touching the digital key (smartphone
key). In this state, if you touch one more
time within 4 seconds, all the doors
unlock. Please make sure the doors are
locked. If you do not open any of the
doors after unlocking, it automatically
re-lock after 30 seconds.
OCN7N051070
[A] : Wireless Charging Pad (In-vehicle Authentication
Pad)
5-15

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
Remote Control with Digital Key
Information
To use the remote control function with
After reconnecting the vehicle battery
your android smartphone, Bluetooth
power supply or charging the battery, it
must be turned on.
may take time to operate due to remote
renewal of security information. When you
Remote Control Connection with Digital
lock or unlock the door with NFC, please
Key
touch and hold your smartphone on the
door handle until it works.
1. Open Hyundai digital key application
on the smartphone. Select the
When the mobile data connection of the
vehicle to activate the remote control
smartphone is weak, the remote renewal
function as a main vehicle.
of security information may fail. In this
case, you should lock, unlock or turn on
2. Approach with the activated
the vehicle with the card key. When you
smartphone app to your vehicle
are in the place where the mobile data
and you can check whether the
connection of your smartphone is available
connection is available. If it enables
and place your smartphone on the interior
your smartphone to connect, connect
authentication pad (wireless charger) and
with your vehicle by pressing the
start up your vehicle or touch the digital
connect button. The remote control
key on the door handle to lock or unlock
function is activated after completing
the door, the remote renewal of security
the process.
information starts automatically. Even
though the engine is turned on, please
Remote Control Operation with Digital
wait until the remote renewal process
Key
is completed and wireless charger is
You can execute the remote control
converted to charging mode.
operation including door lock/unlock,
panic on/off, remote start / remote
stop and trunk opening. The icon for
CAUTION
each function will be highlighted and
The engine can be turned on if the
alarm/vibration also provided when the
registered smartphone or card key is
operation is performed.
placed on the interior authentication
Note that you cannot lock your vehicle
pad (wireless charger). Do not leave
using the Hyundai digital key app if any
unsupervised children or people who
of the following occurs:
are not aware of the system since it
can result in serious injury or death.
• The POWER button is in ACC or ON
Always have the registered digital key
position.
(smartphone) or card key with you to
• Any doors are open.
prevent vehicle theft when leaving the
When the smartphone and the vehicle
vehicle.
are connected by the Bluetooth function
For more information, refer to the
but the remote control command
Engine Start/Stop button in chapter 6.
cannot be received over 5 minutes, the
remote control connection is canceled
automatically.
5-16

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
Remote Start with Digital Key
CAUTION
• When the shift lever of your vehicle
•
If metallic window tint was applied
is in P (Park) and all of the doors
to your vehicle, it may cause
including trunk and hood is locked
bad Bluetooth connection or
and the vehicle is off, press the Door
performance degradation of the
Lock button in the Hyundai Digital
digital key.
Key app then press the Remote Start
•
If multiple users operate the remote
button within 4 seconds.
control function simultaneously, the
You can confirm the engine is on if the
connection between the digital key
hazard warning lights blinks two times
and the vehicle might result in failed
and the chime sounds.
commands. Please connect and
• If you want to turn off the engine,
operate the remote control function
press Remote Engine Stop. Air
only with the necessary user.
Conditioner / Heating system
•
When using the remote control
maintains the same status as when
operation, the driver (the remote
you last used the vehicle.
control user) should leave the vehicle
• Unless you put the registered digital
after confirming the door lock (the
key(smartphone) on the interior
chime sounds once and the hazard
authentication pad (wireless charger)
warning lights blink).
when the remote start function is on,
•
The remote functions of the Digital
the engine will turn off.
Key app enables the vehicle to be
• If you do not get into the vehicle
controlled from a set distance. If
within 10 minutes after the engine
the digital key or the vehicle goes
turns on, the vehicle will turn off.
beyond the operable distance, the
remote control function might be
For more information, refer to the Engine
Start/Stop button in chapter 6.
disconnected or canceled.
•
If the digital key (smartphone) is
Vehicle information Display
connected with the vehicle for the
remote control, the driver with the
The digital key application displays
key goes far away from the vehicle,
the vehicle information such as
the function might not work.
driving or door conditions through the
communication with the vehicle.
•
If the remote control operation
is executed where the mobile
• How to check : Select the vehicle
connection is weak, Bluetooth
what you want to check and touch
connection is poor due to several
the vehicle image, then vehicle
Bluetooth devices or there is an
information display page will be
object such as metal or concrete, it
shown.
might be delayed or the operable
• Contents : accumulated odometer,
distance might decrease. You should
latest fuel economy, driving range,
not cover the smartphone with your
fuel remaining, tire pressure, doors
hand or place other devices which
lock/unlock status and last data
can cause frequency interference. It
updated time.
may result in poor performance.
 Displayed vehicle data could be
•
If the remote control function is not
differed from the current vehicle
available, please use NFC function to
condition.
lock or unlock the doors.
For more information, please refer to
the ‘Tutorial’ on your Digital key app.
5-17

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
Smartphone change/App deletion
CAUTION
If you change your smartphone or delete
•
Do not leave the registered digital
the Hyundai Digital Key App, please refer
key (smartphone) and card key in
to the following to set up your Digital
your vehicle. Please carry around
Key:
your keys all the time.
•
If you happen to lose your digital
Smartphone Change/ Reset
key (smartphone) or card key
If you change or reset the smartphone,
registered as a main user’s key, you
the registered digital key in your previous
should immediately delete the key
smartphone may not be used. Please
on the vehicle’s key menu. For more
refer to following procedure to use the
information, refer to the Digital Key
digital key.
Deletion in this chapter.
1. Install the digital key application and
•
If you registered your digital key
log in.
(smartphone) or card key in the
2. If you are the owner, retry the Digital
vehicle, a message appears on the
key save process.
instrument cluster and informs you
that the key is registered.
3. If you are the sharer, need to re-share
the key from owner.
(Message: Digital key(s) active.)
•
If you buy a used vehicle, you should
App delete & reinstall/ Delete App data
confirm the message and delete the
registered smartphone key and card
You can re-download the digital key from
key. In this case, you should carry
the server and follow these procedures.
your smart key.
1. Reinstall the application and log in.
•
If you keep the NFC card of
2. Input the PIN number for user
the digital key on the interior
verification.
authentication pad (wireless
3. If PIN is correct, digital key data
charger) while driving, it may cause a
will be re-downloaded to your
malfunction of the NFC card.
smartphone and you can use it
•
You should remove your NFC card
without any further registration or
of the digital key on the interior
sharing.
authentication pad after turning on
the engine.
Smartphone operability with Digital Key
•
Hyundai digital key app may not
The digital key application may not be
work properly when the NFC or
available to older type smartphones.
Bluetooth communication between
Please check the available smartphone
smartphone and car is poor.
models with your dealer. NFC antenna
•
If the remote control operation
position on the smartphone can be
is executed where the mobile
confirmed on each smartphone’s manual
connection is weak, Bluetooth
or contact to customer service center of
connection is poor due to other
the smartphone manufacturer.
Bluetooth devices or there is an
object such as metal or concrete, it
might be delayed or the operable
distance might decrease. You should
not cover the smartphone with your
hand or place other devices which
can cause frequency interference. It
may result in poor performance.
5-18

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
•
If the remote control function is not
- If you use a smart phone cover that
activated, please use NFC function to
uses wireless communication or is
lock or unlock the doors
made of metal, the digital key NFC
function may not work properly.
•
You should be careful not to
press the remote control button
Remove the smart phone cover
before using the digital key NFC
on the digital key (smartphone)
accidentally.
function.
• The vehicle may not be controlled by
•
If the digital key (smartphone) is
the smartphone if any of the following
discharged or defective or you
occurs:
cannot use the digital key since the
vehicle battery is discharged, use the
- Basic and necessary functions of
inside door lock button to lock all of
the smartphone manufacturer are
the doors.
operating. (General call, urgent
call, audio or NFC payment)
- Wireless earphone is operating.
CAUTION
(General call, urgent call or audio)
•
Hyundai digital key app on the
- The digital key app function such
smartphone and card key may not
as basic setting or app launching
work if any of the following occurs:
is limited by prior policy according
-
Hyundai digital key app on the
to the manufacturer while using a
smartphone is deleted. (Required
smartphone produced by domestic
to reinstall the app)
and foreign manufactures.
-
Account log in information of
If you change the smartphone
Hyundai digital key app is expired.
number, you should modify the user
(Required to re-log in)
account information on the HYUNDAI
-
When you try to log in to another
customer web site to use the digital
smartphone instead of the
key app.
registered smartphone with same
If the vehicle owner changes
user account.
the smartphone device, the new
-
Smartphone rooting or app
smartphone should be registered in
hacking is detected.
the car after deleting the registered
digital key(smartphone).
-
Smartphone battery or the vehicle
battery is discharged.
If a sharer changes or resets the
smartphone, the key should be re-
-
Smartphone’s screen is off or
shared from owner.
locked.
Some older smartphones may not
-
NFC or Bluetooth is turned off on
work properly. Please check the
the smartphone settings.
available smartphone models with
-
Smartphone’s mobile network
your dealer.
setting is off or airplane mode is
NFC antenna position on the
activated.
smartphone can be confirmed
-
A credit card is overlapped in the
on each smartphone’s manual or
back of your smartphone or metal
contact to customer service center
or thick case is used.
of the smartphone manufacturer.
-
The card key is overlapped with
other credit cards or the key is
used as inserted in the wallet or
card wallet.
5-19

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
Digital key (Card key)
3. Register the NFC card key on the
User’s Settings menu after turning on
the vehicle.
 With Navigation screen : From the
infotainment screen menu, go to
[Setup] - [Vehicle] - [Digital Key] -
[Card Key] then select the [Save] from
submenu.
 Without navigation screen : From
cluster menu, go to [Digital Key] -
[Card Key] and select [Save].
The [Save] button will be disabled if
ODN8A059243
the digital key (Card key) is already
saved.
Please refer to “Digital Key Delete” in
this manual and follow the digital key
delete procedure in your car before
Digital key save.
4. Place the NFC card key onto the
interior authentication pad (wireless
charger). The saving process will
begin automatically.
5. If the key is enrolled, the message
ODN8A059131
will be displayed on the infotainment
screen or instrument cluster.
Digital key (Card key) save
1. Install Hyundai digital key app in
main user’s smartphone and register
Information
the digital key (smartphone). Please
•
Once the card key registration mode
refer to the registration method of the
is activated, the process should be
digital key (smartphone).
completed within 5 minutes. After then,
2. Using the [Pair Card Key] menu on the
you should reactivate once again for
digital key application, you can activate
registration.
the Card Key registration mode.
•
For the digital key(card key) saving,
 NFC authentication : enter the NFC
the smart key(fob) must be inside the
authentication menu and touch the
vehicle.
smartphone on the outside door
•
Once a Card key is registered, it cannot
handle.
be reused in another vehicle.
 Bluetooth authentication : enter the
Bluetooth authentication menu and
press the [OK] button for activation.
If you activate the registration mode,
you should complete the Card saving
process with in 5 minutes.
 If you have not registered the digital
key (smartphone), please register the
digital key (card key) with two smart
keys.
5-20

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
• To delete the saved digital key (card
key), the smart key must be inside the
vehicle.
• The deleted digital key (card key) can
be re-registered before registering a
new digital key (card key).
• If you register a new digital key (card
key), the previously registered digital
key (card key) cannot be used again.
ODN8A059243
ODN8A059132
Digital key (Card key) deletion
You should have the smart key to delete
digital key (card key). Please have the
smart key in your possession.
1. Get into the vehicle with the smart
key.
2. Delete the NFC card key on the User’s
Settings menu after turning on the
engine.
 With Navigation screen : From the
infotainment screen menu, go to
[Setup] - [Vehicle] - [Digital Key] -
[Card Key] then select the [Delete]
from submenu.
 Without navigation screen : From
cluster menu, go to [Digital Key] -
[Card Key] and select [Delete].
If there is no saved digital key(card key),
[Delete] menu will not be activated.
5-21

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
Inoperable condition
If you do not touch the digital key (card
key) to the center of the door handle
authentication pad accurately. it may not
work. In addition, if you overlap and use
the key with NFC-enabled cards such as
transportation card or credit card, it may
not work.
Note that if you try to lock your vehicle
with digital key (card key) in following
cases, the doors will not be locked and
OCN7050128
chime will sound for 3 seconds.
[1] : Door handle authentication pad
• The Smart Key is in the vehicle.
NFC door lock/unlock
• The POWER button is in ACC or ON
You should touch digital key (card key)
position.
to door handle authentication pad (1,
• Any of the doors, hood or trunk are
marked position near by the lock button)
open
of driver’s (or front passenger’s) outside
If the digital key (card key) does not work,
door for 2 seconds to lock or unlock the
please move the card 4 inches (0.1m)
doors. If the Two Press Unlock feature
away from the handle authentication
is applied (press twice for unlocking),
pad and retry to touch. If the card key is
driver’s seat door will be unlocked by
damaged by impact, it may not operate
touching the digital key (card key). In this
properly or at all. You should buy a new
state, if you touch one more time within
card and register again. Long-time
4 seconds, all the doors unlock.
exposure to high temperature may cause
the card key to malfunction. Please be
careful not to expose the key to direct
sunlight or high temperature.
5-22

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
Start-up with Card key
Type A
After placing your registered card key
onto the interior authentication pad
(wireless charger), step on the brake and
press the Engine Start/Stop button.
WARNING
• If you do not place the digital key
(card key) onto the center of the
interior authentication pad (wireless
ODN8A059133
charger) exactly, the card key may
not be recognized. If the engine is
Type B
not turned on, adjust and place the
key again.
• If you overlap and use the key
with NFC-enabled cards such as
transportation card or credit card,
the card key may not be recognized.
• If the digital key (card key) does
not work, please move the card 4
inches (0.1m) away from the handle
authentication pad and retry to
ODN8A059247
touch.
Digital key application/cancellation
• If the card key is damaged by impact,
it may not operate properly or at
If you do not want to use the digital key
all. You should buy a new card and
(smartphone and card key), you can
register again.
disable the function temporarily. You
should have the smart key when you
For more information, refer to the
change the settings
Engine Start/Stop button in chapter 6.
 With Navigation screen :
From the infotainment screen menu,
go to [Setup] - [Vehicle] - [Digital Key]
- [Enable Digital Keys] (deselect)
 Without navigation screen :
From cluster menu, go to [Digital Key]
- [Enable Digital Keys] (deselect)
Information
If you do not have the smart key in your
possession, you cannot deselect [Enable
digital keys]. However, if you want to
select [Enable digital keys] again, you do
not need to have the smart key in your
possession.
5-23

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
Profile link/unlinked
CAUTION
Profile link
If you uncheck Enable digital keys, it is
1. Select Setup → User Profile →
impossible to lock or unlock the doors
or start up the vehicle with digital keys
Profile Settings → Link Digital Key
(Smartphone) on the infotainment
such as smartphone and card key. If
you check Enable digital keys again, the
system menu.
registered digital keys(smartphone and
2. Unlock your digital key installed
card key) are available. Even though
smart phone screen and place it onto
you stop the digital key function, the
the wireless charger according to a
registered keys (smartphone and card
message.
key) are not deleted.
3. It begins the profile link with a
message.
Personalized profile and vehicle
4. If you select Link, the registered
settings
phone number’s digital key and the
Connect the registered digital key with
user’s profile are linked.
personalized profile. Then in case you
5. The interconnection process is
lock or unlock the door with the digital
completed with a message.
key NFC function or unlock the door
remotely by digital key application
Profile unlink
Bluetooth connection, the vehicle
will play the personalized user profile
1. Select Digital Key information on
settings. Profile connection and
infotainment Vehicle Settings menu. It
personalization are available for Driver 1
is possible to unlink only if the profile
and Driver 2.
is interconnected.
2. Profile unlink is completed with a
message.
Information
If you connect both Driver 1 and Driver 2
with a single smartphone, the smartphone
digital key always works as Driver 1.
If you unlink the Driver 1, personalization
function will operate as Driver 2.
5-24

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
PRECAUTION for vehicle profile link and
Vehicle personalization operation
unlink
The personalization function linked with
When you link or unlink the profile of
digital key works as following conditions:
digital key, you should be careful of the
• Touch the driver’s door handle with
following.
the profile linked smart phone to lock
•
Profile link is possible to use with the
or unlock the doors (Personalization
digital key. (Infotainment Vehicle
does not operate when locking or
Settings Mode → Digital Key → Enable
unlocking the front passenger door.)
Digital Keys)
• Remote door unlock with the profile
•
Profile link information remains even
linked smartphone digital key app.
when you disable the digital key
The profile linked with digital key can be
function.
changed manually in the infotainment
•
Only the smart phone with digital key
system setup screen.
app enables you to link your profile.
(Impossible to link with NFC card)
Precaution for digital key profile link and
•
Profile link works only when the
unlink
smart phone and the digital key are
Profile operation according to door lock/
registered to the vehicle. The smart
unlock system is as follows.
phone with another vehicle’s digital
key cannot link profile.
Personalization
Item
•
If you remove the smart phone
Operation
from the wireless charger before
Initial value
Guest
completing the profile link, it does not
work.
Profile linked
smart phone
Linked profile
•
To unlink the profile, the smart phone
key
does not need to be on the wireless
charger.
Profile unlinked
smart phone
key
Recently activated
profile
NFC card key
Smart key
• The personalization function using
the digital key can be operated
after linking the digital key on the
infotainment system profile menu.
• You should use the personalization
function only when the vehicle is
safely parked.
5-25

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
Vehicle personalization with digital key
The available personalization function in the vehicle is as follows.
System
Personalization Item
Setting up temperature unit, Block air inflow/
Air conditioning
Automatic ventilation/Window defroster On/Off
Information display on the cluster, Voice volume,
Cluster
Welcome sound
USM
Lamp
Blink number of one-touch signal lamps
Door
Automatic door lock/unlock, Two Press Unlock
Preferred volume of the navigation system
Navigation
Infotainment
Recent destination
menu
User preset
Radio preset, My menu list settings
Latest operation setup of the following functions:
Air conditioning
(for automatic
Operating
Temperature, AUTO, air flow direction, air volume,
climate control
condition
air conditioner, air intake control, SYNC, Front
system)
windshield defroster, OFF
For more information of personalization, refer to the infotainment system manual.
The information provided may differ depending on which functions are applicable
to your vehicle.
CAUTION
If you leave the digital key after locking or unlocking the doors or starting up the
vehicle with the smart key, the doors can be locked by the central door lock. Please
carry the digital key at all times.
5-26

-------------------------------------------------------------------------------------------------------------------------------------------------------------

05
DOOR LOCKS
Operating Door Locks from
Information
Outside the Vehicle
• Be careful when locking the door by
Mechanical key
mechanical key operation, only the
driver’s door can be locked/unlocked.
• Refer to Chapter 5 “Operating door
locks from inside the vehicle” to lock
from inside the vehicle.
• When all doors are locked with the
mechanical key, lock all doors by using
the central door lock switch inside
the vehicle. Open the door using the
driver’s inner door handle, and then
close the door and lock the driver’s
door with mechanical key operation.
OCN7050009
1. Press the lever located under the
cover with mechanical key. (1)
Information
2. While pushing the lever so that the
When removing the cover, be careful not
mechanical key does not fall out of
to lose cover and any scratches.
the cover hole, slowly push it towards
When the key cover freezes and does not
the rear of the vehicle and remove the
open, lightly tap or indirectly warm(hand
cover. (2)
temperature, etc.) it.
3. After removing the cover, only driver’s
Do not apply excessive force to the door
door can be locked or unlocked by
and door handle. It may be damaged.
using mechanical key.
4. Turn the key toward the rear of the
vehicle to lock and toward the front of
the vehicle to unlock. (3)
If you lock/unlock the driver’s door with
a key, the driver’s door will lock/ unlock
automatically.
Once the door is unlocked, it may be
opened by pulling the door handle.
Make sure that doors are closed securely.
5-27

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience Features
Smart key
Operating Door Locks from
Inside the Vehicle
With the door handle
OCN7N051078L
To lock the doors, press the button on
the outside door handle while carrying
OCN7050010
the smart key with you or press the door
Front door
lock button on the smart key.
To unlock the doors, press the button on
If the inner door handle is pulled when
the door is locked, the door will unlock
the outside door handle while carrying
the smart key with you or press the door
and open.
unlock button on the smart key.
Rear door
Once the doors are unlocked, they may
be opened by pulling the door handle.
If the inner door handle is pulled once
when the door is locked, the door will
When closing the door, push the door by
unlock. If the inner door handle is pulled
hand. Make sure that doors are closed
once more, the door will open.
securely.
Information
Information
If a power door lock ever fails to function
• In cold and wet climates, door lock
while you are in the vehicle try one or
and door mechanisms may not work
more of the following techniques to exit:
properly due to freezing conditions.
• Operate the door unlock feature
• If the door is locked/unlocked multiple
repeatedly (both electronic and
times in rapid succession with either
manual) while simultaneously pulling
the vehicle key or door lock switch, the
on the door handle.
system may stop operating temporarily
in order to protect the circuit and
• Operate the other door locks and
prevent damage to system components.
handles, front and rear.
• Two press unlock setting can be
• Lower a front window and use the
changed in the User Settings mode on
mechanical key to unlock the door from
the cluster.
outside.
5-28















Content      ..     3      4      5      6     ..
