Liftgate unlocking
Panic button
NOTICE
To unlock:
Press and hold the Panic button (4)
To prevent damaging the smart key:
1. Carry the smart key.
for more than one second. The horn
sounds and hazard warning lights
•
Keep the smart key away from
2. Either press the liftgate handle
any liquid or fire. Internal circuits
blink for about 30 seconds. To cancel
button or press and hold the
the panic mode, press any button on
may malfunction if the inside of
Liftgate Unlock button (3) on the
the smart key gets damp (from
the Smart Key.
smart key for more than one sec-
liquids or moisture) or if it is heat-
3
ond.
Start-up
ed. This can exclude the smart
3. The hazard warning lights will
You can start the vehicle without
key from warranty coverage.
blink two times.
inserting the key.
•
Avoid dropping or throwing the
smart key.
i
Information
For more information, refer to the
•
Protect the smart key from
"Engine Start/Stop Button" sec-
extreme temperatures.
• The liftgate handle button will only
tion in chapter 5.
operate when the smart key is within
28 inches (0.7 m) from the liftgate
handle.
• The Liftgate Unlock button (3) will
only unlock the liftgate. It will not
release the latch and open the lift-
gate automatically. If the Liftgate
Unlock button is used, someone
must still press the liftgate handle
button to open the liftgate.
3-5
Convenient features of your vehicle
Mechanical key
Loss of a smart key
If the smart key is in close proximity
to your mobile phone, the signal
If the Smart Key does not operate nor-
A maximum of two Smart Keys can
could be blocked by your mobile
mally, you can lock or unlock the dri-
be registered to a single vehicle. If
phone’s normal operational signals.
ver’s door by using the mechanical key.
you happen to lose your smart key,
This is specifically relevant when the
you should immediately take the
phone is active such as making and
vehicle and remaining keys to your
receiving calls, text messaging,
authorized HYUNDAI dealer or tow
and/or sending/receiving emails.
the vehicle, if necessary.
Avoid placing the smart key and your
mobile phone in the same location
Smart key precautions
and always try to maintain an ade-
The smart key may not work if any of
quate distance between the two
the following occur:
devices.
• The smart key is close to a radio
NOTICE
transmitter such as a radio station
or an airport which can interfere
Keep the smart key away from
OAEE046001
with normal operation of the trans-
electromagnetic materials that
Press and hold the release button (1)
mitter.
blocks electromagnetic waves to
and remove the mechanical key (2).
• The smart key is near a mobile two
the key surface.
Insert the mechanical key into the
way radio system or a cellular
key hole on the door.
phone.
NOTICE
To reinstall the mechanical key, put
• Another vehicle’s smart key is being
the key into the hole and push it until
Always have the smart key with
operated close to your vehicle.
you when leaving the vehicle. If
a click sound is heard.
If the smart key does not work cor-
the smart key is left near the vehi-
rectly, open and close the door with
cle, the vehicle battery may be dis-
the mechanical key. If you have a
charged.
problem with the smart key, contact
an authorized HYUNDAI dealer.
3-6
Battery replacement
If you suspect your smart key might
i
Information
have sustained some damage, or
This device complies with Part 15 of
you feel your smart key is not work-
the FCC rules.
ing correctly, contact an authorized
Operation is subject to the following
HYUNDAI dealer.
three conditions:
1. This device may not cause harmful
i
Information
interference, and
3
An inappropriately disposed
2. This device must accept any inter-
battery can be harmful to the
ference received, including interfer-
environment and human
ence that may cause undesired
health. Dispose of the battery
operation.
according to your local law(s)
3. Changes or modifications not
OLF044008
or regulation(s).
expressly approved by the party
If the Smart Key is not working prop-
responsible for compliance could
erly, try replacing the battery with a
void the user's authority to operate
new one.
the device.
Battery Type: CR2032
To replace the battery:
1. Pry open the rear cover of the
smart key.
2. Remove the old battery and insert
the new battery.
3. Reinstall the rear cover of the
smart key.
3-7
Convenient features of your vehicle
Immobilizer System
Do not attempt to alter this system or
i
Information
add other devices to it. Electrical
The immobilizer system helps protects
problems could result that may make
This device complies with Part 15 of
your vehicle from theft. If an improper-
your vehicle inoperable.
the FCC rules.
ly coded key (or other device) is used,
Operation is subject to the following
the engine's fuel system is disabled.
WARNING
three conditions:
When the Engine Start/Stop button is
1. This device may not cause harmful
placed in the ON position, the immo-
In order to prevent theft of your
interference, and
bilizer system indicator should come
vehicle, do not leave spare keys
on briefly, then go off. If the indicator
2. This device must accept any interfer-
anywhere in your vehicle. Your
starts to blink, the system does not
ence received, including interference
immobilizer password is a cus-
recognize the coding of the key.
that may cause undesired operation.
tomer unique password and
Place the Engine Start/Stop button to
3. Changes or modifications not
should be kept confidential.
the OFF position, then place the
expressly approved by the party
Engine Start/Stop button to the ON
responsible for compliance could
position again.
void the user's authority to operate
NOTICE
the device.
The system may not recognize your
The transponder in your key is an
key's coding if another immobilizer
important part of the immobilizer
key or other metal object (i.e., key
system. It is designed to give
chain) is near the key. The vehicle
years of trouble-free service, how-
may not start because the metal may
ever you should avoid exposure to
interrupt the transponder signal from
moisture, static electricity and
transmitting normally.
rough handling. Immobilizer sys-
If the system repeatedly does not
tem malfunction could occur.
recognize the coding of the key, it is
recommended that you contact your
HYUNDAI dealer.
3-8
DOOR LOCKS
Operating Door Locks from
If you lock the driver's door with a
Smart key
Outside the Vehicle
mechanical key, all vehicle doors will
lock. If you unlock the driver's door
Mechanical key
with a mechanical key, the driver's
door will unlock and the passenger
doors will unlock according to the
current two press unlock setting.
Once the doors are unlocked, they
3
Lock
may be opened by pulling the door
handle.
Unlock
When closing the door, push the
door by hand. Make sure that doors
OAE046001
are closed securely.
Door
Door
Unlock
Lock
OAEE046188N
To remove the cover:
1. Pull out the door handle (1).
2. Press the lock (2) located inside
the bottom part of the cover with a
key or flat-head screwdriver.
3. Push out the cover while pressing
OLF044003
the lock.
Press the button on the driver's out-
side door handle while carrying the
To install the cover:
Smart Key with you or press the Door
1. Pull out the door handle.
Unlock button on the Smart Key, the
2. Install the cover.
driver's door will unlock. If you press
the button on the front passenger's
outside door, all doors will unlock.
3-9
Convenient features of your vehicle
Once the doors are unlocked, they
Operating Door Locks from
• If the inner door handle of the dri-
may be opened by pulling the door
Inside the Vehicle
ver’s (or front passenger’s) door is
handle.
pulled when the door lock button is
With the door lock button
in the lock position, the button is
When closing the door, push the
unlocked and door opens.
door by hand. Make sure that doors
are closed securely.
• Doors cannot be locked if the
smart key is in the vehicle and any
door is open.
i
Information
Lock
•
In cold and wet climates, door lock
Unlock
i
Information
and door mechanisms may not work
properly due to freezing conditions.
If a power door lock ever fails to func-
tion while you are in the vehicle try
•
If the door is locked/unlocked multi-
one or more of the following tech-
ple times in rapid succession with
niques to exit:
either the vehicle key or door lock
OAE046004N
switch, the system may stop operat-
• Operate the door unlock feature
ing temporarily in order to protect
•
To unlock a door, pull the door lock
repeatedly
(both electronic and
the circuit and prevent damage to
button (1) to the "Unlock" position.
manual) while simultaneously
system components.
The red mark (2) on the door lock
pulling on the door handle.
•
Two press unlock setting can be
button will be visible.
• Operate the other door locks and
changed with the smart key or in the
•
To lock a door, push the door lock
handles, front and rear.
User Settings mode on the cluster.
button (1) to the "Lock" position. If
• Lower a front window and use the
the door is locked properly, the red
mechanical key to unlock the door
mark (2) on the door lock button
from outside.
will not be visible.
•
To open a door, pull the door han-
dle (3) outward.
3-10
With the central door lock
WARNING
WARNING
switch
■ Driver’s door
■ Passenger’s door
•
The doors should always be
Always secure your vehicle.
fully closed and locked while
Leaving your vehicle unlocked
the vehicle is in motion. If the
increases the potential risk to
doors are unlocked, the risk of
you or others from someone
being thrown from the vehicle
hiding in your vehicle.
3
in a crash is increased.
To secure your vehicle, while
•
Do not pull the inner door
depressing the brake, move the
handle of driver's or passen-
shift lever to the P (Park) posi-
ger's door while the vehicle is
tion, engage the parking brake,
moving.
and place the Engine Start/Stop
button in the OFF position, close
OAE046005N/OAEE046509N
all windows, lock all doors, and
WARNING
always take the key with you.
When pressing the (
) switch (1), all
vehicle doors will lock.
Do not leave children or animals
When pressing the (
) switch (2), all
unattended in your vehicle. An
vehicle doors will unlock.
enclosed vehicle can become
If the smart key is in the vehicle and
extremely hot, causing death or
any door is opened, the doors will
serious injury to unattended
not lock even though the lock button
children or animals who cannot
(1) of the central door lock switch is
escape the vehicle. Children
pressed.
might operate features of the
vehicle that could injure them,
or they could encounter other
harm, possibly from someone
gaining entry to the vehicle.
3-11
Convenient features of your vehicle
Auto Door Lock/Unlock Features
Child-Protector Rear Door Locks
CAUTION
Impact sensing door unlock
Opening a door when something
All doors will be automatically
is approaching may cause dam-
unlocked when an impact causes the
age or injury. Be careful when
air bags to deploy.
opening doors and watch for
vehicles, motorcycles, bicycles
Speed sensing door lock
or pedestrians approaching the
vehicle in the path of the door.
All doors will be automatically locked
(when set on cluster) when vehicle
speed exceeds 9 mph (15 km/h).
WARNING
All of the doors will be automatically
unlocked after the vehicle is turned off.
OAEE046002N
If you stay in the vehicle for a
The child safety lock is provided to
long time while the weather is
Shift lever auto door lock
help prevent children seated in the
very hot or cold, there are risks
rear from accidentally opening the
of injuries or danger to life. Do
All doors will be automatically locked
rear doors. The rear door safety locks
not lock the vehicle from the
when shifted out of P (Park) with the
should be used whenever children
outside when someone is in the
vehicle in the ready (
) mode.
are in the vehicle.
vehicle.
The child safety lock is located on
You can activate or deactivate the
the edge of each rear door. When the
Auto Door Lock/Unlock features from
child safety lock is in the lock posi-
the User Settings mode on the LCD
tion, the rear door will not open if the
display.
inner door handle is pulled.
For more information, refer to the
"LCD Display" section in this
chapter.
3-12
THEFT-ALARM SYSTEM
To lock the child safety lock, insert a
This system helps to protect your
Once the security system is set,
key (or screw driver) (1) into the hole
vehicle and valuables. The horn will
opening any door, the liftgate, or the
and turn it to the lock position.
sound and the hazard warning lights
hood without using the smart key will
will blink continuously if any of the
cause the alarm to activate.
To allow a rear door to be opened
following occur:
from inside the vehicle, unlock the
The Theft Alarm System will not set if
child safety lock.
- A door is opened without using the
the hood, the liftgate, or any door is
smart key.
not fully closed. If the system will not
set, check the hood, the liftgate, or
3
- The liftgate is opened without
WARNING
the doors are fully closed.
using the smart key.
If children accidently open the
- The engine hood is opened.
Do not attempt to alter this system or
add other devices to it.
rear doors while the vehicle is
The alarm continues for 30 seconds,
in motion, they could fall out of
then the system resets. To turn off
the vehicle. The rear door safety
the alarm, unlock the doors with the
i
Information
locks should always be used
smart key.
•
Do not lock the doors until all pas-
whenever children are in the
The Theft Alarm System automati-
sengers have left the vehicle. If the
vehicle.
cally sets 30 seconds after you lock
remaining passenger leaves the
the doors and the liftgate. For the
vehicle when the system is armed,
system to activate, you must lock the
the alarm will be activated.
doors and the liftgate from outside
•
If the vehicle is not disarmed with
the vehicle with the smart key or by
the smart key, open the doors by
pressing the button on the outside of
using the mechanical key and start
the door handles with the smart key
the vehicle by directly pressing the
in your possession.
Engine Start/Stop button with the
The hazard warning lights will blink
smart key.
and the chime will sound once to
•
When the system is disarmed but a
indicate the system is armed.
door or liftgate is not opened within
30 seconds, the system will be
rearmed.
3-13
Convenient features of your vehicle
DRIVER POSITION MEMORY SYSTEM (IF EQUIPPED)
Storing Positions into Memory
WARNING
1. Check that the shift lever is in P
(Park) while the Engine Start/Stop
Never attempt to operate the driv-
er position memory system while
button is in the ON position.
the vehicle is moving.
2. Adjust the driver's seat position,
This could result in loss of con-
side view mirror position and
instrument panel illumination
trol, and an accident causing
death, serious injury, or property
intensity to positions comfortable
for the driver.
damage.
3. Press the SET button. The system
will beep once and notify you
OAE046036N
"Press button to save settings"on
The Driver Position Memory System
the LCD display.
is provided to store and recall the fol-
4. Press one of the memory buttons
lowing memory settings with a sim-
(1 or 2) within 4 seconds. The sys-
ple button operation.
tem will beep twice when the mem-
- Driver's seat position
ory has been successfully stored.
- Side view mirror position
5. "Driver 1 (or 2) settings saved" will
- Instrument panel illumination intensity
appear on the LCD display.
If the battery is disconnected, the
position memory will be lost and the
driving positions must be stored in
the system again.
If the Driver Position Memory System
does not operate normally, have the
system checked by an authorized
HYUNDAI dealer.
3-14
Recalling Positions from
NOTICE
Easy Access Function
Memory
The system will move the driver's
•
While recalling the "1" memory
1. Check that the shift lever is in P
seat automatically as follows:
position, pressing the SET or 1
(Park) while the Engine Start/Stop
button temporarily stops the
The shift lever is in P (Park)
button is in the ON position.
adjustment of the recalled memo-
• It will move the driver's seat rear-
2. Press the desired memory button
ry position. Pressing the 2 button
ward when the Engine Start/Stop
(1 or 2). The system will beep once,
recalls the "2" memory position.
button is in the OFF position and
3
and then the driver's seat position,
•
While recalling the "2" memory
the driver's door is opened.
side view mirror position and instru-
position, pressing the SET or 2
• It will move the driver's seat forward
ment panel illumination intensity
button temporarily stops the
when the vehicle is turned ON or
will automatically adjust to the
adjustment of the recalled memo-
the driver’s door is closed with the
stored positions.
ry position. Pressing the 1 button
smart key with you.
3. "Driver 1(or 2) settings is applied"
recalls the "1" memory position.
You can activate or deactivate the
will appear on the LCD display.
•
While recalling the stored posi-
Easy Access Function from the User
tions, pressing one of the con-
Settings mode on the LCD display.
trol buttons for the driver’s seat,
side view mirror or instrument
For more information, refer to the
panel illumination will cause the
"LCD Display" section in this
movement of that component to
chapter.
stop and move in the direction
that the control button is
pressed.
3-15
Convenient features of your vehicle
STEERING WHEEL
Electric Power Steering (EPS)
Tilt Steering / Telescope Steering
i
Information
The system assists you with steering
Adjust the steering wheel so it points
The following symptoms may occur
the vehicle. If the vehicle is turned off
toward your chest, not toward your
during normal vehicle operation:
or if the power steering system
face. Make sure you can see the
•
The steering effort may be high
becomes inoperative, you may still
instrument cluster warning lights and
immediately after placing the Engine
steer the vehicle, but it will require
gauges. After adjusting, push the
Start/Stop button in the ON position.
increased steering effort.
steering wheel both up and down to
This happens as the system performs
be certain it is locked in position.
Should you notice any change in the
the EPS system diagnostics. When
Always adjust the position of the
effort required to steer during normal
the diagnostics are completed, the
steering wheel before driving.
vehicle operation, have the system
steering wheel will return to its nor-
checked by an authorized HYUNDAI
mal condition.
dealer.
WARNING
•
A click noise may be heard from the
EPS relay after the Engine Start/Stop
NEVER adjust the steering wheel
CAUTION
button is in the ON or OFF position.
while driving. This may cause
•
Motor noise may be heard when the
loss of vehicle control resulting
If the Electric Power Steering
vehicle is at a stop or at a low driving
in an accident.
System does not operate nor-
speed.
mally, the warning light (
) will
•
When you operate the steering wheel
illuminate on the instrument
in low temperature, abnormal noise
cluster. You may steer the vehi-
may occur. If temperature rises, the
cle, but it will require increased
noise will disappear. This is a normal
steering efforts. Take your vehi-
condition.
cle to an authorized HYUNDAI
dealer and have the system
•
When an error is detected from the
checked as soon as possible.
EPS, the steering effort assist func-
tion will not be activated in order to
prevent fatal accidents. Instrument
cluster warning lights may be on or
the steering effort may be high.
When the following symptoms occur,
immediately drive the vehicle to a
3-16
safe area and check it.
Horn
Heated Steering Wheel
(for Canada, if equipped)
3
OAEE046014
To change the steering wheel angle
OAE046009
and height:
OAE046008N
To sound the horn, press the area
1. Pull down the lock-release lever (1).
indicated by the horn symbol on your
When the Engine Start/Stop button
2. Adjust the steering wheel to the
steering wheel (see illustration). The
is in the ON position or when the
desired angle (2) and distance for-
horn will operate only when this area
vehicle is in the ready (
) mode,
ward/back (3).
is pressed.
press the heated steering wheel but-
3. Pull up the lock-release lever to
ton to warm the steering wheel. The
lock the steering wheel in place.
NOTICE
indicator on the button will illuminate.
To turn the heated steering wheel off,
Do not strike the horn severely to
i Information
press the button again. The indicator
operate it, or hit it with your fist.
on the button will turn off.
After adjustment, sometimes the lock
Do not press on the horn with a
release lever may not lock the steering
sharp-pointed object.
The heated steering wheel will auto-
wheel. It is not a malfunction. This
matically turn off after approximately
occurs when two gears are not
30 minutes.
engaged correctly. In this case, adjust
the steering wheel again and then lock
the steering wheel.
3-17
Convenient features of your vehicle
MIRRORS
NOTICE
Inside Rearview Mirror
WARNING
Before you start driving, adjust the
Do not install any cover or acces-
rearview mirror to the center on the
sory on the steering wheel. The
NEVER adjust the mirror while
cover or accessory could cause
view through the rear window.
driving. This may cause loss of
damage to the heated steering
vehicle control resulting in an
wheel system.
accident.
WARNING
Make sure your line of sight is
NOTICE
not obstructed. Do not place
When cleaning the mirror, use a
objects in the rear seat, cargo
paper towel or similar material
area, or behind the rear head-
dampened with glass cleaner. Do
rests which could interfere with
not spray glass cleaner directly on
your vision through the rear
the mirror as that may cause the
window.
liquid cleaner to enter the mirror
housing.
WARNING
To prevent serious injury during
an accident or deployment of
the air bag, do not modify the
rearview mirror and do not
install a wide mirror.
3-18
Day/night rearview mirror
Blue Link® center (if equipped)
Electric chromic mirror (ECM)
(if equipped)
with HomeLink® system,
compass and Blue Link®
(for U.S.A)
Your vehicle may be equipped with a
Gentex Automatic-Dimming Mirror
Night
with a Z-Nav™ Electronic Compass
Display and an Integrated HomeLink®
3
Wireless Control System. During
nighttime driving, this feature will
automatically detect and reduce
rearview mirror glare while the com-
pass indicates the direction the vehi-
OAD045011N
Day
cle is pointed. The HomeLink®
OAE046010
For details, refer to the Blue Link®
Universal Transceiver allows you to
Make this adjustment before you
Owner's Guide, Navigation Manual
activate your garage door(s), electric
start driving and while the day/night
or Audio Manual.
gate, home lighting, etc.
lever is in the day position.
Pull the day/night lever towards you
to reduce glare from the headlights
of the vehicles behind you during
night driving.
Remember that you lose some
rearview clarity in the night position.
3-19
Convenient features of your vehicle
Automatic-Dimming Night Vision
Your mirror will automatically dim
Safety™ (NVS®) Mirror
upon detecting glare from the vehi-
(if equipped)
cles traveling behind you. The auto-
dimming function can be controlled
The NVS® Mirror automatically
by pressing the Dimming ON/OFF
reduces glare by monitoring light lev-
button (4):
els in the front and the rear of the
vehicle. Any object that obstructs
either light sensor will degrade the
1. Pressing and holding the button
automatic dimming control feature.
for 3 seconds turns the auto-dim-
ming function OFF which is indi-
For more information regarding
cated by the green Status
OAD045045N
NVS® mirrors and other applica-
Indicator LED turning off.
(1) Blue Link Center button
tions, please refer to the Gentex
2. Pressing and holding the button
website:
for 3 seconds again turns the auto-
(2) Blue Link POI button
dimming function ON which is indi-
(3) Blue Link SOS button
cated by the green Status Indicator
(4) Compass control button &
LED turning on.
Dimming ON/OFF button
The mirror defaults to the ON posi-
(5) Status indicator LED
tion each time the vehicle is started.
(6) Channel 1 button
(7) Channel 2 button
Z-Nav™ Compass Display
(8) Channel 3 button
The NVS™ Mirror in your vehicle is
also equipped with a Z-Nav™
(9) Compass display
Compass that shows the vehicle
(10) Rear light sensor
Compass heading in the Display
Window using the 8 basic cardinal
headings (N, NE, E, SE, etc.).
3-20
Compass function
The Compass can be turned ON and
OFF and will remember the last state
when the ignition is cycled. To turn
the display feature ON/OFF:
1. Press and release the
button
within 1 second to turn the display
feature OFF.
3
2. Press and release the
button
again within 1 second to turn the
display back ON.
Additional options can be set with
press and hold sequences of the
button and are detailed below.
There is a difference between mag-
netic north and true north. To com-
pensate for this difference you will
need to adjust the Zone setting based
on where you live.
B520C05NF
3-21
