Hyundai Ioniq Electric (2019 year). Instruction - part 11

LIGHT

Exterior Lights

Daytime running light (DRL)

(if equipped)

Lighting control

The Daytime Running Lights (DRL)

To operate the lights, turn the knob at

can make it easier for others to see

the end of the control lever to one of

the front of your vehicle during the

the following positions:

day, especially after dawn and before

sunset.

3

The DRL system will turn the dedi-

cated lamp OFF when :

• The light switch is in the DRL OFF

OAEE046510N

position.

AUTO light position (if equipped)

• The headlights are ON.

The parking lamp and headlamp will

• The vehicle is turned off.

be turned ON or OFF automatically

depending on the amount of light

outside the vehicle.

OLF044084N

Even with the AUTO light feature in

1. DRL (Daytime Running Lights)

operation, it is recommended to

OFF position

manually turn ON the lamps when

2. AUTO light position

driving at night or in a fog, driving in

the rain, or when you enter dark

3. Parking lamp position

areas, such as tunnels and parking

4. Headlamp position

facilities.

3-95

Convenient features of your vehicle

NOTICE

• Do not cover or spill anything on

the sensor (1) located in front of

the instrument panel.

• Do not clean the sensor using a

window cleaner, the cleanser may

leave a light film which could

interfere with sensor operation.

• If your vehicle has window tint

or other types of metallic coat-

ing on the front windshield, the

OLF044086N

OLF044087N

AUTO light system may not work

Parking lamp position (

)

Headlamp position (

)

properly.

The parking lamp, license plate lamp

The headlamp, parking lamp, license

and instrument panel lamp are turned

plate lamp and instrument panel lamp

ON.

are turned ON.

i

Information

The POWER button must be in the

ON position to turn on the headlamp.

3-96

High beam operation

High Beam Assist (HBA)

(if equipped)

3

OLF044088N

To flash the high beam headlamp,

OLF044089N

pull the lever towards you, then

OAE048581L

To turn on the high beam headlamp,

release the lever. The high beams

push the lever away from you. The

The High Beam Assist (HBA) is a

will remain ON as long as you hold

lever will return to its original position.

system that automatically adjusts the

the lever towards you.

The high beam indicator will light

headlamp range (switches between

when the headlamp high beams are

high beam and low beam) according

switched on.

to the brightness of other vehicles

and road conditions.

To turn off the high beam headlamp,

pull the lever towards you. The low

beams will turn on.

Operating condition

1. Place the headlamp switch in the

WARNING

AUTO position.

2. Turn on the high beam by pushing

Do not use high beam when there

the lever away from you.

are other vehicles approaching

The High Beam Assist (HBA) (

)

you. Using high beam could

indicator will illuminate.

obstruct the other driver’s vision.

3-97

Convenient features of your vehicle

3. The High Beam Assist (HBA) will

When the High Beam Assist (HBA) is

turn on when vehicle speed is

operating, the high beam switches to

above 25 mph (40 km/h).

low beamif any of the following condi-

tions occur :

• If the headlamp switch is pushed

away when the High Beam Assist

-

When the headlamp of an on-com-

(HBA) is operating, the High Beam

ing vehicle is detected.

Assist (HBA) will turn off and the

-

When the tail lamp of a vehicle in

high beam will be on continuously.

front is detected.

• If the headlamp switch is pulled

-

When the headlamp or tail lamp of

towards you when the high beam

a motorcycle or a bicycle is detect-

is off, the high beam will turn on

ed.

OAE058237L

without the High Beam Assist

-

When the surrounding ambient

(HBA) canceled. When you let go

Warning light and message

light is bright enough that high

of the light switch, the lever will

beams are not required.

When the High Beam Assist (HBA) is

move to the middle and the high

not working properly, the Check High

beam will turn off.

-

When streetlights or other lights

Beam Assist warning message will

are detected.

• If the headlamp switch is pulled

come on for a few second. After the

towards you when the high beam

-

When the headlamp switch is not

message disappears, the master

is on by the High Beam Assist

in the AUTO position.

warning light (

) will illuminate. Take

(HBA), the low beam will be on

-

When the High Beam Assist (HBA)

your vehicle to an authorized

and the High Beam Assist (HBA)

is off.

HYUNDAI dealer and have the system

will turn off.

-

When vehicle speed is below 15

checked.

• If the headlamp switch is placed

mph (24 km/h).

to the headlamp ON position, the

High Beam Assist (HBA) will turn

off and the low beam will be on

continuously.

3-98

WARNING

(Continued)

(Continued)

 When external condition is

• When a vehicle suddenly

The driver must be cautious in

intervened

appears from a curve.

the below situations may not

•

When there is a similar shape

• When the vehicle is tilted from

work properly when recognition

lamp with the front vehicle’s

a flat tire or being towed.

of light from on-coming or front

lamps.

• When the LKA (Lane Keeping

vehicle is poor or limited:

•

When the headlamp is not

Assist) system failure indica-

3

 When the light from on-com-

repaired or replaced at an

tor

(yellow) illuminates

(if

ing or front vehicle is poor

authorized dealer.

equipped) and etc.

•

When the light from the on-

•

When headlamp aiming is not

 When front visibility is poor

coming or front vehicle is not

properly adjusted.

•

When the lamp of the on-com-

detected because of lamp

•

When driving on a narrow

ing or front vehicle is covered

damage, hidden from sight,

curved road, rough road,

with dust, snow or water.

etc.

downhill or uphill.

•

When the light from the on-

•

When the lamp of the on-com-

•

When only part of the vehicle

coming or front vehicle is not

ing or front vehicle is covered

in front is visible on a cross-

detected because of exhaust

with dust, snow or water.

road or curved road.

fume, smoke, fog, snow, etc.

•

When the front vehicle's head-

•

When there is a traffic light,

•

When the front window is cov-

lamps are off but the fog

reflecting sign, flashing sign

ered with foreign matters.

lamps on and etc.

or mirror ahead.

•

When it is hard to see

(Continued)

•

When there is a temporary

because of fog, heavy rain or

reflector or flash ahead (con-

snow and etc.

struction area).

(Continued)

•

When the road conditions are

bad such as being wet, iced or

covered with snow.

(Continued)

3-99

Convenient features of your vehicle

Turn signals and lane change

(Continued)

(Continued)

signals

•

Do not disassemble a front

•

At times, the High Beam Assist

view camera temporarily for

may not work properly. The

tinted window or attaching

system is for your convenience

any types of coatings and

only. It is the responsibility of

accessories. If you disassem-

the driver for safe driving prac-

ble the camera and assemble

tices and always check the

it again, take your vehicle to

road conditions for your safety.

an authorized HYUNDAI deal-

•

When the system does not

er and have the system

operate normally, change the

checked to need a calibration.

lamp position manually

•

When you replace or reinstall

between the high beam and

the windshield glass, front

low beam.

view camera, take your vehi-

OLF044091N

cle to an authorized HYUNDAI

To signal a turn, push down on the

dealer and have the system

lever for a left turn or up for a right

checked.

turn in position (A).

•

Be careful that water doesn’t

If an indicator stays on and does not

get into the High Beam Assist

flash or if it flashes abnormally, one of

unit and do not remove or

the turn signal bulbs may be burned

damage related parts of the

out and will require replacement.

High Beam Assist system.

•

Do not place objects on the

crash pad that reflect light

such as mirrors, white paper,

etc. The system may malfunc-

tion if sunlight is reflected.

(Continued)

3-100

Convenient features of your vehicle

NOTICE

AFLS (Adaptive Front Lighting

Change the switch to the AUTO posi-

System) a.k.a. DBL (Dynamic

tion when the vehicle is in the ready

If the driver gets out of the vehicle

(

) mode. The adaptive front light-

Bending Light) (if equipped)

through other doors (except dri-

ing system will operate when the

ver’s door), the battery saver func-

headlamp is ON. To turn off the

tion does not operate and the

AFLS, change the switch to other

headlamp delay function does not

positions. After turning the AFLS off,

turn off automatically. Therefore, It

headlamp swiveling no longer

causes the battery to be dis-

occurs, but leveling operates contin-

charged. In this case, make sure

uously.

to turn off the lamp before getting

If the AFLS malfunction indicator

out of the vehicle.

comes on, the AFLS is not working

properly. Drive to the nearest safe

location and restart the vehicle (

indicator ON). If the indicator contin-

OAEE046510N

uously remains on, have the system

be checked by an authorized

Adaptive front lighting system uses

HYUNDAI dealer.

the steering angle and vehicle

speed, to keep your field of vision

wide by swiveling and leveling the

headlamp.

3-102

Interior Lights

Front lamps

Front Door Lamp (

):

WARNING

The front or rear room lamps come

on when the front or rear doors are

Do not use the interior lights

opened. When doors are unlocked by

when driving in the dark.The inte-

the smart key, the front and rear

rior lights may obscure your view

lamps come on for approximately 30

and cause an accident.

seconds as long as any door is not

3

opened. The front and rear room

lamps go out gradually after approxi-

NOTICE

mately

30 seconds if the door is

closed. However, if the POWER but-

Do not use the interior lights for

ton is in the ON position or all doors

extended periods when the vehi-

OAD045405

are locked, the front and rear lamps

cle is turned off or the battery will

(1) Front Map Lamp

will turn off. If a door is opened with

discharge.

the POWER button in the ACC posi-

(2) Front Door Lamp

tion or the OFF position, the front

(3) Front Room Lamp ON

Interior lamp AUTO cut

and rear lamps stay on for about 20

(4) Front Room Lamp OFF

minutes.

The interior lamps will automatically

go off approximately 20 minutes after

the vehicle is turned off and the

Front Map Lamp :

doors closed. If a door is opened, the

Press either of these lenses to turn

lamp will go off 40 minutes after the

the map lamp on or off. This light pro-

vehicle is turned off. If the doors are

duces a spot beam for convenient

locked by the smart key and the vehi-

use as a map lamp at night or as a

cle enters the armed stage of the

personal lamp for the driver and the

theft alarm system, the lamps will go

front passenger.

off five seconds later.

3-103

Convenient features of your vehicle

Front room lamp

Rear lamp

Luggage room lamp

•

:

■ Type A

Press the button to turn ON the

room lamp for the front/rear seats.

Re-press the button to turn OFF

the room lamp.

•

:

Press the button to turn OFF the

room lamp for the front/rear seats

regardless of front or rear door open

OAE046445

■ Type B

position.

OAEE046401N

The luggage room lamp comes on

when the liftgate is opened.

NOTICE

The luggage room lamp comes on

as long as the liftgate is open. To

prevent unnecessary charging

system drain, close the liftgate

OAEE046421

securely after using the luggage

Rear Room Lamp (

):

room.

Press this switch to turn the room

lamp on and off.

3-104

Vanity mirror lamp (if equipped)

Puddle lamp (if equipped)

Escort light

When the POWER button is in the

OFF position and the driver's door is

opened, the puddle lamp will come

on for 30 seconds. If the driver's door

is closed within the 30 seconds, the

puddle lamp will turn off after 15 sec-

onds. If the driver's door is closed

3

and locked, the puddle lamp will turn

off immediately.

The Puddle Lamp Escort Light will

turn on only the first time the driver's

door is opened after the vehicle is

OAD045410

OAE046419

turned off.

Push the switch to turn the light on or

Welcome light

off.

When all doors (and tailgate) are

•

: The lamp will turn on if this

closed and locked, the puddle lamp

button is pressed.

will come on for 15 seconds if the

•

: The lamp will turn off if this

door is unlocked by the smart key or

button is pressed.

outside door handle button.

NOTICE

For more details, refer to "Welcome

System" in this chapter.

Always have the switch in the off

position when the vanity mirror

lamp is not in use. If the sunvisor

is closed without the lamp off, it

may discharge the battery or dam-

age the sunvisor.

3-105

Convenient features of your vehicle

Welcome System (if equipped)

Door handle lamp (if equipped)

Headlamp and parking lamp

Welcome light (if equipped)

When all the doors (and liftgate) are

When the headlamp (lamp switch in the

closed and locked, the door handle

headlamp or AUTO position) is on and

lamp will come on for about 15 sec-

all doors (and liftgate) are locked and

onds if any of the below is performed.

closed, the parking lamp and head-

lamp will come on for 15 seconds if/or

•

When the door unlock button is

any of the below is performed.

pressed on the smart key.

• When the door unlock button is

•

When the button of the outside door

pressed on the smart key.

handle is pressed with the smart

key in possession.

At this time, if you press the door lock

or unlock button, the parking lamp and

•

When the vehicle is approached

with the smart key in possession.

headlamp will turn off immediately.

You can activate or deactivate the

OAEE046400N

Welcome Light from the User

Settings mode on the LCD display.

Puddle lamp (if equipped)

For more details, refer to "LCD

When all the doors (and liftgate) are

Display" in this chapter.

closed and locked, the puddle lamp

will come on for about 15 seconds if

any of the below is performed.

• When the door unlock button is

pressed on the smart key.

• When the button of the outside

door handle is pressed with the

smart key in possession.

• When the vehicle is approached

with the smart key in possession.

3-106

Convenient features of your vehicle

WIPERS AND WASHERS

Windshield Wipers

i

Information

Operates as follows when the

If there is heavy accumulation of snow

POWER button is in the ON position.

or ice on the windshield, defrost the

MIST : For a single wiping cycle,

windshield for about 10 minutes, or

push the lever upward and

until the snow and/or ice is removed

release. The wipers will oper-

before using the windshield wipers to

ate continuously if the lever is

ensure proper operation.

held in this position.

If you do not remove the snow and/or

OFF : Wiper is not in operation.

ice before using the wiper and washer,

INT : Wiper operates intermittently at

it may damage the wiper and washer

OLF044278

the same wiping intervals. To

system.

vary the speed setting, move

A : Wiper speed control

the speed control lever. The top

· MIST - Single wipe

most setting will run the wipers

· OFF - Off

most frequently (for more rain).

· INT - Intermittent wipe

The bottom setting will run the

wipers the least frequently (for

· LO - Low wiper speed

less rain).

· HI - High wiper speed

LO : The wiper runs at a lower speed.

HI : The wiper runs at a higher speed.

B : Intermittent control wipe time

adjustment

C : Wash with brief wipes

3-108

Windshield Washers

NOTICE

WARNING

•

To prevent possible damage to

When the outside temperature

the washer pump, do not oper-

is below freezing, ALWAYS

ate the washer when the fluid

warm the windshield using the

reservoir is empty.

defroster to help prevent the

•

To prevent possible damage to

washer fluid from freezing on

the wipers or windshield, do not

3

the windshield and obscuring

operate the wipers when the

your vision which could result

windshield is dry.

in an accident and serious

•

To prevent damage to the wiper

injury or death.

arms and other components, do

not attempt to move the wipers

OLF044095N

manually.

In the OFF position, pull the lever

•

To prevent possible damage to

gently toward you to spray washer

the wipers and washer system,

fluid on the windshield and to run the

use anti-freezing washer fluids

wipers

1-3 cycles. The spray and

in the winter season or cold

wiper operation will continue until you

weather.

release the lever. If the washer does

not work, you may need to add wash-

er fluid to the washer fluid reservoir.

3-109

Convenient features of your vehicle

DRIVER ASSIST SYSTEM

Rear View Monitor

This is a supplemental system that

WARNING

provides a view of the area behind

the vehicle through the A/V display

•

Never rely solely on the Rear

while the vehicle is in the R (Reverse)

position.

View Monitor when backing-

up.

•

ALWAYS look around your

WARNING

vehicle to make sure there are

no objects or obstacles before

The Rear View Monitor is not a

moving the vehicle in any

safety device. It only serves to

direction to prevent a collision.

assist the driver in identifying

OAEE046417L

•

Always pay close attention

objects directly behind the mid-

when the vehicle is driven

dle of the vehicle. The monitor

close to objects, particularly

does NOT cover the complete

pedestrians, and especially

area behind the vehicle.

children.

NOTICE

Always keep the monitor lens

clean. The monitor may not work

normally if the lens is covered

OAEE046416N

with dirt or snow.

The Rear View Monitor will activate

when the vehicle is in the ready (

)

mode and when you shift to the R

(Reverse) position.

3-110

DEFROSTER

NOTICE

Rear Window Defroster

i

Information

To prevent damage to the conduc-

• If there is heavy accumulation of

tors bonded to the inside surface

snow on the rear window, brush it off

of the rear window, never use

before operating the rear defroster.

sharp instruments or window

• The rear window defroster automat-

cleaners containing abrasives to

ically turns off after approximately

clean the window.

20 minutes or when the POWER

3

button is in the OFF position.

If you want to defrost and defog

the front windshield, refer to

Side view mirror defroster

the "Windshield Defrosting and

Defogging" section in this chapter.

If your vehicle is equipped with the

OAEE046322L

side view mirror defrosters, they will

operate at the same time you turn on

The defroster heats the window to

the rear window defroster.

remove frost, fog and thin ice from

the interior and exterior of the rear

window while the vehicle is in the

ready (

) mode.

• To activate the rear window

defroster, press the rear window

defroster button located in the center

facia switch panel. The indicator on

the rear window defroster button illu-

minates when the defroster is ON.

• To turn off the defroster, press the

rear window defroster button again.

3-111

Content   ..  9  10  11  12   ..
