Maintenance
WASHER FLUID
PARKING BRAKE
Checking the washer fluid
Checking the parking brake
WARNING
level
To prevent serious injury or
death, take the following safety
precautions when using washer
fluid:
Do not use engine coolant or
antifreeze in the washer fluid
reservoir. Engine coolant can
severely obscure visibility
when sprayed on the wind-
shield and may cause loss of
vehicle control resulting in an
OPD056016
OPDEN077017
accident or damage to paint
Check the stroke of the parking
and body trim.
Check the fluid level in the washer
brake by counting the number of
Do not allow sparks or flames
fluid reservoir and add fluid if neces-
“clicks’’ heard while fully applying it
to contact the washer fluid or
sary. Plain water may be used if
from the released position. Also, the
washer fluid is not available.
the washer fluid reservoir.
parking brake alone should securely
Washer fluid may contain
However, use washer solvent with
hold the vehicle on a fairly steep
antifreeze characteristics in cold cli-
alcohol and can be flamma-
grade. If the stroke is more or less
ble.
mates to prevent freezing.
than specified, we recommend that
Do not drink washer fluid and
the system be serviced by an author-
avoid contact with skin.
ized HYUNDAI dealer.
Washer fluid is poisonous to
humans and animals.
Stroke : 5~6 “clicks’’ at a force of
20 kg (44 lbs, 196 N).
Keep washer fluid away from
children and animals.
7-26
AIR CLEANER
Filter replacement
OPDEN077021
OPDEN077022
1. Loosen the air cleaner cover
2. Pull out the part written PULL (1).
OPDEN077018
attaching clips and open the cover.
3. Pull out the air cleaner filter (2).
The air cleaner filter can be cleaned
4. When installing, place the part
for inspection using compressed air.
written PULL
(1) first, and then
Do not attempt to wash or to rinse it,
place the new air filter (2) in the
as water will damage the filter.
original position.
If soiled, the air cleaner filter must be
5. Lock the cover with the cover
replaced.
attaching clips.
7
6. Check that the cover is firmly
installed.
7-27
Maintenance
i
Information
i
Information
Example
If the vehicle is operated in extremely
dusty or sandy areas, replace the element
more often than the usual recommended
intervals (refer to “Maintenance Under
Severe Usage Conditions” in this chap-
ter).
NOTICE
• Do not drive with the air cleaner
filter removed. This will result in
excessive engine wear.
OPD077104L
• When removing the air cleaner
Be sure to insert the hinge (A) before
filter, be careful that dust or dirt
locking the cover with the cover
does not enter the air intake, or
attaching clips.
damage may result.
• Use HYUNDAI genuine parts.
Use of non-genuine parts could
damage the air flow sensor.
7-28
CLIMATE CONTROL AIR FILTER
Filter inspection
Filter replacement
If the vehicle is operated in the
severely air-polluted cities or on
dusty rough roads for a long period,
it should be inspected more fre-
quently and replaced earlier. When
you, the owner, replace the climate
control air filter, replace it performing
the following procedure, and be care-
ful to avoid damaging other compo-
OPD076025
nents.
3. Press and hold the lock (1) on both
Replace the filter according to the
OPD076024
sides of the cover.
Maintenance Schedule.
1. With the glove box open, remove
4. Pull out the cover (2).
the stoppers on both sides.
7
OPD076026
OPD076023
5. Replace the climate control air filter.
2. Remove the support strap (1).
6. Reassemble in the reverse order
of disassembly.
7-29
Maintenance
WIPER BLADES
NOTICE
Blade inspection
NOTICE
Contamination of either the wind-
Install a new climate control air filter
To prevent damage to the wiper
shield or the wiper blades with for-
in the correct direction with the
blades, arms or other compo-
eign matter can reduce the effective-
arrow symbol() facing downwards,
nents, do not:
ness of the windshield wipers.
otherwise, it may be noisy and the
• Use gasoline, kerosene, paint
effectiveness of the filter may be
Common sources of contamination
thinner, or other solvents on or
reduced.
are insects, tree sap, and hot wax
near them.
treatments used by some commer-
• Attempt to move the wipers
cial car washes. If the blades are not
manually.
wiping properly, clean both the win-
dow and the blades with a good
• Use non-specified wiper blades.
cleaner or mild detergent, and rinse
thoroughly with clean water.
i
Information
Commercial hot waxes applied by
automatic car washes have been
known to make the windshield diffi-
cult to clean.
i
Information
Wiper blades are consumable item and
normal wear of the wipers may not be
covered by your vehicle warranty.
7-30
Blade replacement
Front windshield wiper service
4. Turn the wipers to any ON position
positions
to return the wipers to the bottom
When the wipers no longer clean
resting position.
adequately, the blades may be worn
or cracked, and require replacement.
NOTICE
To prevent damage to the wiper arms
or other components, do not attempt
to move the wipers manually.
NOTICE
The use of a non-specified wiper
OPDE076027
blade could result in wiper mal-
function and failure.
This vehicle has a "hidden" wiper
design which means that the wipers
cannot be lifted when they are in
NOTICE
their bottom resting position.
• In order to prevent damage to
1. Within 20 seconds of turning off the
the hood and the wiper arms, the
engine, move the wiper lever down
7
wiper arms should only be lifted
and hold it to the
position for
when in the top wiping position.
about 2 seconds until the wipers
• Always return the wiper arms to
move to the top wipe position.
the windshield before driving.
2. At this time you can lift the wipers
off the windshield.
3. Gently put the wipers back down
onto the windshield.
7-31
Maintenance
Rear window wiper blade
OAD075074L
OAD075076L
3. Remove the wiper blade from the
OTL075050
wiper arm (5).
1. Raise the wiper arm and pull out
4. Install a new wiper blade assem-
the wiper blade assembly.
bly in the reverse order of removal.
5. Return the wiper arm on the wind-
shield.
OAD075075L
1. Lift up the wiper blade clip
(1).
Then lift up the wiper blade (2).
2. While pushing the lock
(3), pull
down the wiper blade (4).
7-32
BATTERY
WARNING
(Continued)
Batteries contain sulfu-
To prevent SERIOUS INJURY or
ric acid which is highly
DEATH to you or bystanders,
corrosive. Do not allow
always follow these precautions
acid to contact your
when working near or handling
eyes, skin or clothing.
the battery:
If acid gets into your eyes, flush
Always read and follow
your eyes with clean water for at
instructions carefully
least 15 minutes and get imme-
when handling a battery.
diate medical attention. If acid
OTL075051
Wear eye protection
gets on your skin, thoroughly
designed to protect the
wash the area. If you feel pain or
2. Install the new blade assembly by
eyes from acid splashes.
a burning sensation, get med-
inserting the center part into the
ical attention immediately.
slot in the wiper arm until it clicks
Keep all flames, sparks,
into place.
or smoking materials
When lifting a plastic-cased
away from the battery.
battery, excessive pressure
3. Make sure the blade assembly is
on the case may cause battery
installed firmly by trying to pull it
Hydrogen is always
acid to leak. Lift with a battery
slightly.
present in battery cells,
carrier or with your hands on
is highly combustible,
To prevent damage to the wiper arms
opposite corners.
and may explode if ignit-
7
or other components, we recommend
ed.
Do not attempt to jump start
that the wiper blades be replaced by
your vehicle if your battery is
an authorized HYUNDAI dealer.
Keep batteries out of
frozen.
reach of children.
(Continued)
(Continued)
7-33
Maintenance
For best battery service
Battery capacity label
(Continued)
■ Example
NEVER attempt to recharge
the battery when the vehicle’s
battery cables are connected
to the battery.
The electrical ignition system
works with high voltage.
NEVER touch these compo-
nents with the engine running
or when the ignition switch is
in the ON position.
OPDEN077028
OLMB073072
NOTICE
The actual battery label in the vehicle
Keep the battery securely mounted.
• When you do not use the vehicle
may differ from the illustration.
Keep the battery top clean and dry.
for a long time in a low tempera-
1. CMF60L-BCI
: The HYUNDAI
ture area, disconnect the battery
Keep the terminals and connec-
model name of battery
and keep it indoors.
tions clean, tight, and coated with
petroleum jelly or terminal grease.
2.12V : The nominal voltage
• Always charge the battery fully
to prevent battery case damage
Rinse any spilled electrolyte from
3.60Ah(20HR) : The nominal capacity
in low temperature areas.
the battery immediately with a
(in Ampere hours)
solution of water and baking soda.
4.92RC : The nominal reserve capac-
NOTICE
If the vehicle is not going to be
ity (in min.)
used for an extended time, discon-
5.550CCA : The cold-test current in
If you connect unauthorized elec-
nect the battery cables.
amperes by SAE
tronic devices to the battery, the
battery may be discharged. Never
6.440A
: The cold-test current in
use unauthorized devices.
amperes by EN
7-34
Battery recharging
WARNING
(Continued)
By battery charger
Watch the battery during
Your vehicle has a maintenance-free,
Always follow these instructions
charging, and stop or reduce
calcium-based battery.
when recharging your vehicle’s
the charging rate if the battery
battery to avoid the risk of SERI-
cells begin boiling violently.
If the battery becomes discharged
OUS INJURY or DEATH from
in a short time (because, for exam-
The negative battery cable
explosions or acid burns:
ple, the headlights or interior lights
must be removed first and
were left on while the vehicle was
Before performing mainte-
installed last when the battery
not in use), recharge it by slow
nance or recharging the bat-
is disconnected. Disconnect
charging (trickle) for 10 hours.
tery, turn off all accessories
the battery charger in the fol-
and place the Engine Start/
lowing order:
If the battery gradually discharges
Stop button to the OFF posi-
because of high electric load while
(1) Turn off the battery charger
tion.
the vehicle is being used, recharge
main switch.
it at 20-30A for two hours.
Keep all flames, sparks, or
(2) Unhook the negative
smoking materials away from
clamp from the negative
the battery.
battery terminal.
Always work outdoors or in an
(3) Unhook the positive clamp
area with plenty of ventilation.
from the positive battery
Wear eye protection when
terminal.
checking the battery during
7
Always use a genuine HYUNDAI
charging.
approved battery when you
The battery must be removed
replace the battery.
from the vehicle and placed in
a well ventilated area.
(Continued)
7-35
Maintenance
By jump starting
Reset items
CAUTION
After a jump start from a good bat-
The following items may need to be
tery, drive the vehicle for 20-30 min-
reset after the battery has been dis-
AGM battery (if equipped)
utes before it is shutoff. The vehicle
charged or the battery has been dis-
Absorbent Glass Matt (AGM)
may not restart if you shut it off
connected.
batteries are maintenance-
before the battery had a chance to
Auto up/down window
free and we recommend that
adequately recharge. See
“Jump
Sunroof
Starting” in chapter 6 for more infor-
the AGM battery be serviced
by an authorized HYUNDAI
mation on jump starting procedures.
Trip computer
dealer. For charging your
Climate control system
AGM battery, use only fully
i
Information
Driver position memory system
automatic battery chargers
that are specially developed
An inappropriately disposed
Clock
for AGM batteries.
battery can be harmful to
Audio system
the environment and human
When replacing the AGM bat-
health.
tery, we recommend that you
use parts for replacement
Dispose of the battery according to
from an authorized HYUNDAI
your local law(s) or regulations.
dealer.
Do not open or remove the
cap on top of the battery. This
may cause leaks of internal
electrolyte that could result in
severe injury.
7-36
TIRES AND WHEELS
(Continued)
i
Information - Power Hop
WARNING
Replace tires that are worn,
When fully accelerating the vehicle
Tire failure may cause loss of
show uneven wear, or are dam-
from standstill, a front tire oscillation
vehicle control resulting in an
aged. Worn tires can cause
called “Power Hop“ of i30 N may occur
accident. To reduce risk of
loss of braking effectiveness,
due to the high torque of engine and
SERIOUS INJURY or DEATH,
steering control, or traction.
the characteristics of high performance
take the following precautions:
tire. This is affected by road condition
ALWAYS replace tires with the
Inspect your tires monthly for
same size as each tire that
and temperatures. Additionally it is a
proper inflation as well as
was originally supplied with
normal phenomenon in powerful front-
wear and damage.
this vehicle. Using tires and
wheel drive vehicles. i30 N will act on
this phenomenon with the traction con-
The recommended cold tire
wheels other than the recom-
trol in all ESC modes with the main
pressure for your vehicle can
mended sizes could cause
focus on high performance character.
be found in this manual and on
unusual handling characteris-
the tire label located on the dri-
tics, poor vehicle control, or
ver’s side center pillar. Always
negatively affect your vehi-
i
Information - Wheel nut
use a tire pressure gauge to
cle’s Anti-Lock Brake System
When the wheel is detached and
measure tire pressure. Tires
(ABS) resulting in a serious
reassembled frequently, replace all
with too much or too little
accident.
used wheel nuts with new wheel nuts
pressure wear unevenly caus-
or accessory wheel nut.
ing poor handling.
7
Check the pressure of the
spare every time you check
the pressure of the other tires
on your vehicle.
(Continued)
7-37
Maintenance
Tire care
Recommended cold tire infla-
WARNING
tion pressures
For proper maintenance, safety, and
maximum fuel economy, you must
All tire pressures
(including the
Recommended pressures must
always maintain recommended tire
spare) should be checked when the
be maintained for the best ride,
inflation pressures and stay within the
tires are cold. “Cold tires” means the
vehicle handling, and minimum
load limits and weight distribution rec-
vehicle has not been driven for at
tire wear.
ommended for your vehicle.
least three hours or has been driven
Over-inflation or under-inflation
for less than 1.6 km (1 mile).
can reduce tire life, adversely
Warm tires normally exceed recom-
affect vehicle handling, and
mended cold tire pressures by 28 to
lead to sudden tire failure that
41 kPa (4 to 6 psi). Do not release air
could result in loss of vehicle
from warm tires to adjust the pres-
control resulting in an accident.
sure or the tires will be under-inflat-
Severe under-inflation can lead
ed. For recommended inflation pres-
to severe heat build-up, causing
sure, refer to “Tire and Wheels” in
blowouts, tread separation and
chapter 8.
other tire failures that can result
in the loss of vehicle control
resulting in an accident. This
OPD086007
risk is much higher on hot days
and when driving for long peri-
All specifications (sizes and pressures)
ods at high speeds.
can be found on a label attached to the
driver’s side center pillar.
7-38
Check tire inflation pressure
Recheck the tire pressure with the
CAUTION
tire gauge. Be sure to put the valve
Check your tires, including the spare
caps back on the valve stems.
tire, once a month or more.
Under-inflation results in
Without the valve cap, dirt or mois-
excessive wear, poor handling
ture could get into the valve core and
and reduced fuel economy.
How to check
cause air leakage. If a valve cap is
Wheel deformation is also
Use a good quality tire pressure
missing, install a new one as soon as
possible. Keep your tire pres-
gauge to check tire pressure. You
possible.
sures at the proper levels. If a
can not tell if your tires are properly
tire frequently needs refilling,
inflated simply by looking at them.
Tire rotation
we recommend it be checked
Radial tires may look properly inflat-
by an authorized HYUNDAI
To equalize tread wear, HYUNDAI
ed when they are under-inflated.
dealer.
recommends that the tires be rotated
Remove the valve cap from the tire
every 12,000 km (7,500 miles) or
Over-inflation produces a
valve stem. Press the tire gauge firm-
sooner if irregular wear develops.
harsh ride, excessive wear at
ly onto the valve to get a pressure
the center of the tire tread,
During rotation, check the tires for
measurement. If the cold tire inflation
and a greater possibility of
correct balance.
pressure matches the recommended
damage from road hazards.
pressure on the tire and loading
When rotating tires, check for uneven
information label, no further adjust-
wear and damage. Abnormal wear is
ment is necessary. If the pressure is
usually caused by incorrect tire pres-
low, add air until you reach the rec-
sure, improper wheel alignment, out-
7
ommended pressure. Make sure to
of-balance wheels, severe braking or
put the valve caps back on the valve
severe cornering. Look for bumps or
stems. Without the valve cap, dirt or
bulges in the tread or side of the tire.
moisture could get into the valve
Replace the tire if you find any of
core and cause air leakage. If a valve
these conditions. Replace the tire if
cap is missing, install a new one as
fabric or cord is visible. After rotation,
soon as possible.
be sure to bring the front and rear tire
pressures to specification and check
If you overfill the tire, release air by
lug nut tightness (proper torque is
pushing on the metal stem in the
11~13 kgf·m [79~94 lbf·ft]).
center of the tire valve.
7-39
Maintenance
■ 18 inch tire
Wheel alignment and tire bal-
i
Information
ance
The outside and inside of the unsym-
The wheels on your vehicle were
metrical tire is distinguishable. When
aligned and balanced carefully at the
installing an unsymmetrical tire, be
factory to give you the longest tire life
sure to install the side marked "out-
and best overall performance.
side" face the outside. If the side
marked "inside" is installed on the
In most cases, you will not need to
outside, it will have a negative effect
have your wheels aligned again.
on vehicle performance.
However, if you notice unusual tire
ODH073802
wear or your vehicle pulling one way
■ 19 inch tire
or the other, the alignment may need
WARNING
to be reset.
If you notice your vehicle vibrating
Do not use the compact spare
when driving on a smooth road, your
tire for tire rotation.
wheels may need to be rebalanced.
Do not mix bias ply and radial
ply tires under any circum-
NOTICE
stances. This may cause
unusual handling characteris-
Incorrect wheel weights can dam-
tics that may cause loss of
age your vehicle’s aluminum
ODH073803
vehicle control resulting in an
wheels. Use only approved wheel
accident.
weights.
Disc brake pads should be inspected
for wear whenever tires are rotated.
7-40
Tire replacement
WARNING
(Continued)
When replacing tires
(or
Tread wear indicator
To reduce the risk of DEATH or
wheels), it is recommended to
SERIOUS INJURY:
replace the two front or two
Replace tires that are worn,
rear tires (or wheels) as a pair.
show uneven wear, or are
Replacing just one tire can
damaged. Worn tires can
seriously affect your vehicle’s
cause loss of braking effec-
handling. If only replacing one
tiveness, steering control, and
pair of tires, it is recommend-
traction.
ed to install the pair of new
tires on the rear axle.
Always replace tires with the
same size as each tire that
Tires degrade over time, even
OLMB073027
was originally supplied with
when they are not being used.
this vehicle. Using tires and
Regardless of the remaining
If the tire is worn evenly, a tread wear
wheels other than the recom-
tread, HYUNDAI recommends
indicator will appear as a solid band
mended sizes could cause
that tires be replaced after six
across the tread. This shows there is
unusual handling characteris-
(6) years of normal service.
less than 1.6 mm (1/16 in.) of tread
left on the tire. Replace the tire when
tics, poor vehicle control, or
Heat caused by hot climates or
negatively affect your vehi-
frequent high loading condi-
this happens.
cle’s Anti-Lock Brake System
tions can accelerate the aging
Do not wait for the band to appear
7
(ABS) resulting in a serious
process. Failure to follow this
across the entire tread before replac-
accident.
warning may cause sudden
ing the tire.
(Continued)
tire failure, which could lead to
a loss of vehicle control result-
ing in an accident.
7-41
Maintenance
Compact spare tire replacement
Wheel replacement
Tire maintenance
(if equipped)
When replacing the metal wheels for
In addition to proper inflation, correct
A compact spare tire has a shorter
any reason, make sure the new
wheel alignment helps to decrease
tread life than a regular size tire.
wheels are equivalent to the original
tire wear. If you find a tire is worn
Replace it when you can see the
factory units in diameter, rim width
unevenly, have your dealer check the
tread wear indicator bars on the tire.
and offset.
wheel alignment.
The replacement compact spare tire
When you have new tires installed,
should be the same size and design
make sure they are balanced. This
Tire traction
tire as the one provided with your
will increase vehicle ride comfort and
new vehicle and should be mounted
Tire traction can be reduced if you
tire life. Additionally, a tire should
on the same compact spare tire
drive on worn tires, tires that are
always be rebalanced if it is removed
wheel. The compact spare tire is not
improperly inflated or on slippery
from the wheel.
designed to be mounted on a regular
road surfaces. Tires should be
size wheel, and the compact spare
replaced when tread wear indicators
Tire sidewall labeling
tire wheel is not designed for mount-
appear. To reduce the possibility of
ing a regular size tire.
losing control, slow down whenever
This information identifies and
there is rain, snow or ice on the road.
describes the fundamental charac-
WARNING
teristics of the tire and also provides
the tire identification number
(TIN)
The original tire should be
for safety standard certification. The
repaired or replaced as soon as
TIN can be used to identify the tire in
possible to avoid failure of the
case of a recall.
spare and loss of vehicle control
resulting in an accident.The com-
pact spare tire is for emergency
use only. Do not operate your
vehicle over 80 km/h (50 mph)
when using the compact spare
tire.
7-42















Content   ..  23  24  25  26   ..
