Safety features of your vehicle
C041300AUN
•
Keep occupants away from the air
Additional safety precautions
bag covers. All occupants should sit
WARNING
•
Never let passengers ride in the
upright, fully back in their seats with
• Sitting improperly or out of posi-
cargo area or on top of a folded-
their seat belts on and their feet on the
tion can cause occupants to be
down back seat. All occupants should
floor. If occupants are too close to the
shifted too close to a deploying
sit upright, fully back in their seats with
air bag covers, they could be injured if
air bag, strike the interior struc-
their seat belts on and their feet on the
the air bags inflate.
ture or be thrown from the vehicle
floor.
•
Do not attach or place objects on or
resulting in serious injury or
•
Passengers should not move out of
near the air bag covers. Any object
death.
or change seats while the vehicle is
attached to or placed on the front or
• Always sit upright with the seat-
moving. A passenger who is not wear-
side air bag covers could interfere with
back in an upright position, cen-
ing a seat belt during a crash or emer-
the proper operation of the air bags.
tered on the seat cushion with
gency stop can be thrown against the
•
Do not modify the front seats.
your seat belt on, legs comfort-
inside of the vehicle, against other
Modification of the front seats could
ably extended and your feet on
occupants, or out of the vehicle.
interfere with the operation of the sup-
the floor.
•
Each seat belt is designed to
plemental restraint system sensing
restrain one occupant. If more than
components or side air bags.
one person uses the same seat belt,
•
Do not place items under the front
C041400AUN
they could be seriously injured or killed
seats. Placing items under the front
Adding equipment to or modifying
in a collision.
seats could interfere with the operation
your air bag-equipped vehicle
•
Do not use any accessories on seat
of the supplemental restraint system
If you modify your vehicle by changing
belts. Devices claiming to improve
sensing components and wiring har-
your vehicle's frame, bumper system,
occupant comfort or reposition the seat
nesses.
front end or side sheet metal or ride
belt can reduce the protection provided
•
Never hold an infant or child on your
height or front door module, this may
by the seat belt and increase the
lap. The infant or child could be seri-
affect the operation of your vehicle's air
chance of serious injury in a crash.
ously injured or killed in the event of a
bag system.
•
Passengers should not place hard
crash. All infants and children should
or sharp objects between them-
be properly restrained in appropriate
selves and the air bags. Carrying
child safety seats or seat belts in the
hard or sharp objects on your lap or in
rear seat.
your mouth can result in injuries if an
air bag inflates.
3 65
Safety features of your vehicle
1
2
OEN037045/OEN036046/OEN036048
C041200AUN-EU
Air bag warning label (if equipped)
Air bag warning labels, some required by the U.S. National Highway Traffic Safety Administration (NHTSA), are attached to alert
the driver and passengers of potential risks of the air bag system.
3 66
Keys / 4-3
Smart key / 4-4
Remote keyless entry / 4-8
Theft-alarm system / 4-12
Door locks / 4-14
Tailgate / 4-18
Windows / 4-25
Hood / 4-29
Features of your vehicle
4
Fuel filler door / 4-30
Sunroof / 4-32
Driver position memory system / 4-36
Power adjustable pedals / 4-38
Steering wheel / 4-39
Mirrors / 4-41
Instrument cluster / 4-51
Rear parking assist system / 4-67
Hazard warning flasher / 4-69
Lighting / 4-70
Wipers and washers / 4-74
Interior light / 4-78
Defroster / 4-83
Manual climate control system / 4-84
Automatic climate control system / 4-96
Windshield defrosting and defogging / 4-106
Storage compartment / 4-109
Interior features / 4-112
Exterior feature / 4-119
Audio system / 4-120
Rear seat entertainment system (RSE) / 4-153
4
Features of your vehicle
Features of your vehicle
KEYS
Type A
To reinstall the mechanical key, put the
key into the hole and push it until a click
sound is heard.
WARNING - Ignition key
Leaving children unattended in a
vehicle with the ignition key is dan-
gerous even if the key is not in the
ignition switch. Children copy
OUN026060
adults and they could place the key
Type B
in the ignition switch. The ignition
key would enable children to oper-
OUN046100L
ate power windows or other con-
D010100AEN
trols, or even make the vehicle
Record your key number
move, which could result in serious
The key code number is stamped on the
bodily injury or even death. Never
leave the keys in your vehicle with
bar code tag attached to the key set.
unsupervised children.
Should you lose your keys, this number
will enable an authorized HYUNDAI deal-
OEN042302
er to duplicate the keys easily. Remove
the bar code tag and store it in a safe
D010200AEN
WARNING
place. Also, record the code number and
Key operations
Use only HYUNDAI original parts
keep it in a safe place (not in the vehicle).
Type A
for the ignition key in your vehicle.
Used to start the engine, lock and unlock
If an aftermarket key is used, the
the doors.
ignition switch may not return to
Type B
ON after START. If this happens, the
Used to start the engine, lock and unlock
starter will continue to operate
the doors.
causing damage to the starter
To remove the mechanical key, press and
motor and possible fire due to
hold the release button (1) and remove
excessive current in the wiring.
the mechanical key (2).
4 3
Features of your vehicle
SMART KEY (IF EQUIPPED)
D040100AEN
Smart key functions
With possession of a smart key, you can
lock and unlock the vehicle doors (and
tailgate), and the smart key enables
starting of the engine as well. Detailed
information follows:
OEN046301
OEN046303
D040000AEN
D040101AEN
With a smart key, you can lock or unlock
Locking
a door (and tailgate) and even start the
Pressing the buttons in the front outside
engine without inserting the key.
door handles with all doors (and tailgate)
The functions of buttons on a smart key
closed and any door unlocked, locks all
are similar to the remote keyless entry.
the doors
(and tailgate). The hazard
(Refer to the “Remote keyless entry” in
warning lights blink and the chime
this section.)
sounds once to indicate that all doors
(and tailgate) are locked. The button will
only operate when the smart key is with-
in 28~40 in. (0.7~1 m) from the outside
door handle. If you want to make sure
that a door has locked or not, you should
check the door lock button inside the
vehicle or pull the outside door handle.
4 4
Features of your vehicle
D040102AEN-EU
D040103AEN-EE
D040104AEN
Unlocking
Tailgate unlocking
Start-up
Pressing the buttons in the driver’s out-
If you are within 28~40 in. (0.7~1 m) from
You can start the engine without inserting
side door handle with all doors (and tail-
the outside tailgate handle, with your
the key. For detailed information refer to
gate) closed and locked, unlocks the dri-
smart key in your possession, the tail-
the “Starting the engine with smart key”
ver’s door. The hazard warning lights
gate will unlock and open when you
in section 5.
blink and the chime sounds twice to indi-
press the tailgate handle switch.
cate that the driver’s door is unlocked. All
The hazard warning lights will blink twice
doors (and tailgate) are unlocked if the
to indicate that the tailgate is unlocked
button is pressed once more within 4
and open.
seconds. The hazard warning lights will
Also, once the tailgate is opened and
blink and the chime will sound twice to
then closed, the tailgate will be locked
indicate that all the doors (and tailgate)
automatically.
are unlocked.
Pressing the button in the front passen-
ger’s outside door handle with all doors
(and tailgate) closed and locked, unlocks
all the doors (and tailgate). The hazard
warning lights blink and the chime
sounds twice to indicate that all doors
(and tailgate) are unlocked. The button
will only operate when the smart key is
within 28~40 in. (0.7~1 m) from the out-
side door handle.
When the smart key is recognized in the
area of 28~40 in. (0.7~1 m) from the front
outside door handle, other people can
also open the door without possession of
the smart key.
4 5
Features of your vehicle
D040300AEN-EU
This device complies with Part 15 of
Smart key precautions
CAUTION
the FCC rules.
Keep the smart key away from
Operation is subject to the following two
✽ NOTICE
water or any liquid. If the keyless
conditions:
•
If, for some reason, you happen to lose
entry system is inoperative due to
1. This device may not cause harmful
your smart key, you will not be able to
exposure to water or liquids, it will
interference, and
start the engine. Tow the vehicle, if
not be covered by your manufactur-
2. This device must accept any interfer-
necessary, and contact an authorized
er’s vehicle warranty.
ence received, including interference
HYUNDAI dealer.
that may cause undesired operation.
•
A maximum of 2 smart keys can be
registered to a single vehicle. If you
lose a smart key, you should immedi-
WARNING
ately take the vehicle and key to your
Changes or modifications not
authorized HYUNDAI dealer to pro-
expressly approved by the party
tect it from potential theft.
responsible for compliance could
•
The smart key will not work if any of
void the user’s authority to operate
following occur:
the equipment. If the keyless entry
- The smart key is close to a radio
system is inoperative due to
transmitter such as a radio station or
changes or modifications not
an airport which can interfere with
expressly approved by the party
normal operation of the smart key.
responsible for compliance, it will
- You keep the smart key near a
not be covered by your manufactur-
mobile two-way radio system or a
er’s vehicle warranty.
cellular phone.
- Another vehicle’s smart key is being
operated close to your vehicle.
When the smart key does not work
correctly, open and close the door with
the mechanical key. If you have a
problem with the smart key, contact
an authorized HYUNDAI dealer.
4 6
Features of your vehicle
1. Pry open the rear cover of the smart
key.
2. Replace the battery with a new battery
(CR2032). When replacing the battery,
make sure the battery positive “+” sym-
bol faces up as indicated in the illus-
tration.
3. Install the battery in the reverse order
of removal.
OEN042302
OEN046208
✽ NOTICE
D040400AEN
D040500BEN
• Using the wrong battery can cause the
Restrictions in handling keys
Battery replacement
smart key to malfunction. Be sure to
When leaving keys with parking lot and
A smart key battery should last for sever-
use the correct battery.
valet attendants, the following proce-
al years, but if the smart key is not work-
• Circuits inside the smart key may
dures will ensure that your vehicle’s
ing properly, try replacing the battery with
develop problems when dropped,
exposed to moisture or static electrici-
glove box compartment can not be
a new one. If you are unsure how to use
opened in your absence.
your smart key or replace the battery,
ty.
contact an authorized HYUNDAI dealer.
• If you suspect that your smart key
1. Depress and hold the release button
might have sustained some damage,
(1) and remove the mechanical key (2).
or you feel your smart key is not
2. Close and then lock the glove box
✽ NOTICE
working correctly, contact an author-
using the mechanical key.
The circuit inside the smart key can
ized HYUNDAI dealer.
3. Leave the smart key with the atten-
have a problem if exposed to moisture
dant. The glove box is secure with the
or static electricity. If you are unsure
mechanical key.
CAUTION
how to use your smart key or replace the
battery,
contact an authorized
An inappropriately disposed bat-
HYUNDAI dealer.
tery can be harmful to the environ-
ment and human health.
Dispose the battery according to
your local law(s) or regulation.
4 7
Features of your vehicle
REMOTE KEYLESS ENTRY
Type A
However, if any door (or tailgate) remains
D020104BEN-EE
open, the hazard warning lights and the
Tailgate unlock (3)
chime will not operate. If all doors (and
With power tailgate
tailgate) are closed after the lock button
The tailgate is opened or closed auto-
is pressed, the hazard warning lights
matically if the button is pressed for more
blink.
than 1 second. The hazard warning lights
will blink and the chime will sound
3
D020102AEN-EU
times to indicate that the tailgate will
Unlock (2)
swing upward or downward.
Driver's door is unlocked if the unlock
OEN048002
button is pressed once. The hazard
✽ NOTICE
Type B
warning lights will blink twice to indicate
The power tailgate is opened or closed
that the driver's door is unlocked.
by the transmitter regardless of the door
All doors (and tailgate) are unlocked if
lock status. However, an authorized
the unlock button is pressed once more
HYUNDAI dealer can change the oper-
within
4 seconds. The hazard warning
ating logic so that the power tailgate
lights will blink and the chime will sound
may be operated by the transmitter
twice again to indicate that all doors (and
after any door is unlocked. If you want
tailgate) are unlocked.
this feature, consult an authorized
After depressing this button, the doors
HYUNDAI dealer.
OEN046301
(and tailgate) will be locked automatical-
ly unless you open any door within 30
Remote keyless entry system
CAUTION
seconds.
operations
The power tailgate can be operated
D020101AEN-EU
when the engine is not running.
Lock (1)
However, the power tailgate con-
sumes large amounts of vehicle
All doors (and tailgate) are locked if the
electric power. To prevent the bat-
lock button is pressed.
tery from being discharged, do not
If all doors (and tailgate) are closed, the
operate them consecutively (more
hazard warning lights blink and the
than approximately 10 times).
chime sounds once to indicate that all
doors (and tailgate) are locked.
4
8
Features of your vehicle
Without power tailgate
D020200AEN-EU
The tailgate is unlocked if the button is
Transmitter precautions
CAUTION
pressed for more than 1 second.
Keep the transmitter away from
✽ NOTICE
The hazard warning lights will blink twice
water or any liquid. If the keyless
The transmitter will not work if any of
to indicate that the tailgate is unlocked.
entry system is inoperative due to
following occur:
exposure to water or other liquids,
After depressing this button, the tailgate
• The ignition key is in ignition switch.
it will not be covered by your manu-
will be locked automatically unless you
• You exceed the operating distance
facturer’s vehicle warranty.
open the tailgate within 30 seconds.
limit (about 90 feet [30 m]).
Also, once the tailgate is opened and
• The battery in the transmitter is
then closed, the tailgate will be locked
weak.
automatically.
• Other vehicles or objects may be
blocking the signal.
D020105AUN
• The weather is extremely cold.
• The transmitter is close to a radio
Alarm (4)
transmitter such as a radio station or
The horn sounds and hazard warning
an airport which can interfere with
lights flash for about 30 seconds if this
normal operation of the transmitter.
button is pressed for more than 0.5 sec-
When the transmitter does not work
ond. To stop the horn and lights, press
correctly, open and close the door with
any button on the transmitter.
the ignition key. If you have a problem
with the transmitter, contact an author-
ized HYUNDAI dealer.
4 9
Features of your vehicle
This device complies with Part 15 of
the FCC rules.
WARNING
Operation is subject to the following two
Changes or modifications not
conditions:
expressly approved by the party
1. This device may not cause harmful
responsible for compliance could
interference, and
void the user’s authority to operate
2. This device must accept any interfer-
the equipment. If the keyless entry
ence received, including interference
system is inoperative due to
that may cause undesired operation.
changes or modifications not
expressly approved by the party
responsible for compliance, it will
not be covered by your manufactur-
er’s vehicle warranty.
OEN048003
D020300AEN
Battery replacement
Transmitter uses a 3 volt lithium battery
which will normally last for several years.
When replacement is necessary, use the
following procedure.
1. Insert a slim tool into the slot and gen-
tly pry open the transmitter center
cover.
4 10
Features of your vehicle
CAUTION
•
The keyless entry system trans-
mitter is designed to give you
years of trouble-free use, howev-
er it can malfunction if exposed to
moisture or static electricity. If
you are unsure how to use your
transmitter or replace the battery,
contact an authorized HYUNDAI
dealer.
•
Using the wrong battery can
OEN046004
cause the transmitter to malfunc-
tion. Be sure to use the correct
2. Replace the battery with a new battery
battery.
(CR2032). When replacing the battery,
make sure the battery positive “+” sym-
•
To avoid damaging the transmit-
bol faces up as indicated in the illus-
ter, don't drop it, get it wet, or
tration.
expose it to heat or sunlight.
3. Install the battery in the reverse order
of removal.
CAUTION
For replacement transmitters, see an
An inappropriately disposed bat-
authorized HYUNDAI dealer for transmit-
tery can be harmful to the environ-
ter reprogramming.
ment and human health.
Dispose the battery according to
your local law(s) or regulation.
4 11
Features of your vehicle
THEFT-ALARM SYSTEM
D030100AEN-EU
The system can also be armed by lock-
Armed stage
ing the doors with the key from the front
Park the car and stop the engine. Arm
doors; however, the hazard warning
Armed
the system as described below.
lights will not blink using this method.
stage
1. Remove the ignition key from the igni-
tion switch and exit the vehicle.
✽ NOTICE
2. Make sure that all doors (and tailgate)
The theft-alarm system by the key can
and engine hood are closed and
be deactivated by an authorized
Disarmed
Theft-alarm
latched.
HYUNDAI dealer.
stage
stage
3. Lock the doors using the transmitter of
If you want this feature, consult an
the keyless entry system
(or smart
authorized HYUNDAI dealer.
key).
After completion of the steps above, the
Do not arm the system until all pas-
D030000AEN
sengers have left the vehicle. If the
hazard warning lights will blink and the
This system is designed to provide pro-
chime will sound once to indicate that the
system is armed while a passenger(s)
tection from unauthorized entry into the
system is armed.
remains in the vehicle, the alarm may
car. This system is operated in three
be activated when the remaining pas-
stages: the first is the "Armed" stage, the
senger(s) leave the vehicle. If any
If any door (or tailgate) or engine hood
second is the "Theft-alarm" stage, and
door (or tailgate) or engine hood is
remains open, the hazard warning lights
the third is the "Disarmed" stage. If trig-
opened within 30 seconds after the
and the chime will not operate and the
gered, the system provides an audible
system enters the armed stage, the
theft-alarm will not arm. If all doors (and
alarm with blinking of the hazard warning
system is disarmed to prevent an
tailgate) and engine hood are closed
lights.
unnecessary alarm.
after the lock button is pressed, the haz-
ard warning lights blink once.
4 12
Features of your vehicle
D030200AEN-EU
D030400BEN-EU
Theft-alarm stage
Disarmed stage
CAUTION
The alarm will be activated if any of the
Do not change, alter or adjust the
The system will be disarmed when the
following occurs while the system is
theft-alarm system because it could
doors (and tailgate) are unlocked with the
armed.
transmitter (or smart key) or the ignition
cause the theft-alarm system to
• A front or rear door is opened without
key.
malfunction. The system should
using the ignition key or transmitter (or
After depressing the unlock button, the
only be serviced by an authorized
smart key).
hazard warning lights will blink and the
HYUNDAI dealer.
• The tailgate is opened without using
chime will sound twice to indicate that the
Malfunctions caused by improper
the transmitter (or smart key).
system is disarmed.
alterations, adjustments or modifi-
• The engine hood is opened.
After depressing the unlock button, if any
cations to the theft-alarm system
are not covered by your vehicle
The horn will sound and the hazard
door (or tailgate) is not opened within 30
manufacturer warranty.
warning lights will blink continuously for
seconds, the system will be rearmed.
approximately 30 seconds, and repeat
the alarm once more unless the system
✽ NOTICE
is disarmed. To turn off the system,
• Avoid trying to start the engine while
unlock the doors with the ignition key or
the alarm is activated. The vehicle
transmitter.
starting motor is disabled during the
theft-alarm stage.
If the system is not disarmed with the
transmitter, insert the key into the
ignition switch, turn the ignition
switch to the ON position and wait for
30 seconds. Then the system will be
disarmed. (if equipped)
• If you lose your keys, consult your
authorized HYUNDAI dealer.
4 13
Features of your vehicle
DOOR LOCKS
• Doors can also be locked and
unlocked with the transmitter (or smart
key).
• Once the doors are unlocked, they may
be opened by pulling the door handle.
• When closing the door, push the door
by hand. Make sure that doors are
Unlock
closed securely.
Lock
✽ NOTICE
•
In cold and wet climates, door lock
and door mechanisms may not work
OEN046005
OEN046006
properly due to freezing conditions.
D050100AEN-EU
•
To lock a door without the key, push the
•
If the door is locked/unlocked multi-
Operating door locks from out-
inside door lock button (1) or central
ple times in rapid succession with
side the vehicle
door lock switch (2) to the “Lock” posi-
either the vehicle key or door lock
switch, the system may stop operating
tion and close the door (3).
• Turn the key toward the rear of the
temporarily in order to protect the
•
If you lock the door with the central
vehicle to unlock and toward the front
circuit and prevent damage to system
door lock switch (2), all vehicle doors
of the vehicle to lock.
components.
will lock automatically.
• If you lock the door with a key, all vehi-
cle doors will lock automatically.
✽ NOTICE
• From the driver’s door, turn the key to
WARNING
Always remove the ignition key, firmly
the right once to unlock the driver’s
• If you don't close the door
engage the parking brake, close all win-
door and once more within 4 seconds
securely, the door may open
dows and lock all doors when leaving
to unlock all doors.
again.
your vehicle unattended.
• Be careful that someone's body
and hands are not trapped when
closing the door.
4 14
Features of your vehicle
• Front doors cannot be locked if the
Driver’s door
ignition key is in the ignition switch and
any front door is open.
WARNING - Door lock mal-
Lock
function
Unlock
If a power door lock ever fails to
function while you are in the vehi-
cle, try one or more of the following
techniques to exit:
•
Operate the door unlock feature
OEN046008
Passenger’s door
OEN046007
repeatedly
(both electronic and
manual) while simultaneously
Operating door locks from inside
pulling on the door handle.
the vehicle
•
Operate the other door locks and
D050201AEN-EE
handles, front and rear.
With the door lock button
•
Lower a front window and use the
• To unlock a door, pull the door lock but-
key to unlock the door from out-
ton (1) to the “Unlock” position. The red
side.
mark (2) on button will be visible.
•
Move to the cargo area and open
• To lock a door, push the door lock but-
the tailgate.
ton (1) to the “Lock” position. If the door
OEN046009
is locked properly, the red mark (2) on
D050202AUN
the door lock button will not be visible.
With central door lock switch
• To open a door, pull the door handle
Operate by depressing the central door
(3) outward.
lock switch.
• If the inner door handle of the driver’s
(or front passenger’s) door is pulled
when the door lock button is in lock
position, the button is unlocked and
door opens. (if equipped)
4 15
