Hyundai Tucson (2017 year). Instruction

What to do in an emergency

WARNING

(Continued)

LED illumination in red (system

Arbitrary

Removal

Emergency power supply of the

malfunction)

Modification

system ERA-GLONASS from

If red LED illuminates in normal

The ERA-GLONASS system

the battery

driving conditions, this can

calls emergency services for

• The ERA-GLONASS system

indicate malfunction of the

assistance. Thus, any arbitrary

battery supplies power during

ERA-GLONASS system. Please,

removal or changes to the ERA-

1 hour in case main power

have the ERA-GLONASS sys-

GLONASS system settings may

source of the vehicle is cut off

tem checked at an authorized

affect your driving safety. Also,

due to the collision during the

Hyundai dealership immediate-

it may even make an erroneous

emergency situations.

ly. Otherwise correct operation

emergency call to the single

• The ERA-GLONASS system

of the ERA-GLONASS system

duty dispatch service. Thereby,

battery should be replaced

device, installed in your car is

we kindly ask you not to make

every 3 years. For more infor-

not guaranteed. Owner of the

any changes by yourself or by

mation

refer

the

car incurs liability for conse-

the third parties in the settings

Maintenance Schedule in

quences, occurred as a result of

of the equipment of the ERA-

chapter 7.

nonobservance of conditions,

GLONASS system, installed in

mentioned above.

your car.

(Continued)

6-42

Test Mode

There is a technical opportunity to

You can start the ERA-GLONASS

check working ability of the ERA-

test mode by pressing the SOS

GLONASS device, installed in your

TEST button. The test mode starts

car. In order to avoid making erro-

with a voice guidance to check work-

neous calls and incorrect operation

ing ability of the ERA-GLONASS

of the device, checking of the ERA-

device. In the course of checking

GLONASS device, installed in your

working ability of the ERA-

car, should be carried out only by

GLONASS device red and green

specialists of authorized Hyundai

LED illuminate.

dealerships and on their territory in

Re-press the SOS TEST button

accordance with the following manu-

again to deactivate the test mode

(on applying user interface for

during the voice guidance.

launching test mode).

ETL-005

Elements of the system ERA-

GLONASS, installed in passenger

compartment:

➀ Microphone

➁ SOS button

➂ SOS TEST button

➃ LED

6-43

Maintenance

Engine compartment

7-3

Brake/clutch fluid

7-35

Maintenance services

7-6

Checking the brake/clutch fluid level

7-35

Owner's responsibility

7-6

Washer fluid

7-36

Owner maintenance precautions

7-6

Checking the washer fluid level

7-36

Owner maintenance

7-7

Parking brake

7-36

Owner maintenance schedule

7-8

Checking the parking brake

7-36

Scheduled maintenance services

7-10

Fuel filter (for Diesel)

7-37

Normal Maintenance Schedule

Draining water from fuel filter

7-37

(For Europe, Except Russia)

7-11

Fuel filter cartridge replacement

7-37

Maintenance Under Severe Usage and Low Mileage

Air cleaner

7-38

Conditions (For Europe, Except Russia)

7-15

Filter replacement

7-38

Normal Maintenance Schedule

Climate control air filter

7-40

(Except Europe, For Russia)

7-17

Filter inspection

7-40

Maintenance Under Severe Usage and Low Mileage

Filter replacement

7-40

Conditions (Except Europe, For Russia)

7-21

Wiper blades

7-41

Explanation of scheduled maintenance items..7-24

Blade inspection

7-41

Engine oil

7-28

Blade replacement

7-41

Checking the engine oil level (Gasoline engine)

7-28

Battery

7-44

Checking the engine oil level (Diesel engine)

7-29

For best battery service

7-44

Checking the engine oil and filter

7-30

Battery capacity label

7-46

Engine coolant

7-31

Battery recharging

7-46

Checking the engine coolant level

7-31

Reset items

7-47

Changing the engine coolant

7-34

Tires and wheels

7-48

Appearance care

7-93

Tire care

7-48

Exterior care

7-93

Recommended cold tire inflation pressures

7-48

Interior care

7-99

Checking tire inflation pressure

7-50

Emission control system

7-100

Tire rotation

7-51

Crankcase emission control system

7-100

Wheel alignment and tire balance

7-52

Evaporative emission control system

7-100

Tire replacement

7-52

Exhaust emission control system

7-101

Wheel replacement

7-54

Tire traction

7-54

Tire maintenance

7-54

Tire sidewall labeling

7-54

Low aspect ratio tire

7-59

Fuses

7-60

Fuse/Relay panel description

7-65

Light bulbs

7-75

Headlamp, static bending lamp, position lamp,

turn signal lamp and fog lamp light bulb

replacement

7-76

Side repeater lamp replacement

7-81

Headlamp and front fog lamp aiming

7-82

Rear combination light bulb replacement

7-87

High mounted stop lamp replacement

7-90

License plate light bulb replacement

7-90

Interior light bulb replacement

7-91

Maintenance

MAINTENANCE SERVICES

You should exercise the utmost care

Detailed warranty information is pro-

NOTICE

to prevent damage to your vehicle

vided in your Service Passport.

and injury to yourself whenever per-

Improper owner maintenance dur-

Repairs and adjustments required as

forming any maintenance or inspec-

ing the warranty period may affect

a result of improper maintenance or

tion procedures.

warranty coverage. For details, read

a lack of required maintenance are

the separate Service Passport pro-

We recommend you have your vehi-

not covered.

vided with the vehicle. If you're

cle maintained and repaired by an

unsure about any servicing or main-

authorized HYUNDAI dealer. An

Owner maintenance precautions

tenance procedure, we recommend

authorized HYUNDAI dealer meets

that the system be serviced by an

HYUNDAI’s high service quality stan-

Inadequate, incomplete or insufficient

authorized HYUNDAI dealer.

dards and receives technical support

servicing may result in operational

from HYUNDAI in order to provide

problems with your vehicle that could

you with a high level of service satis-

lead to vehicle damage, an accident,

faction.

or personal injury. This chapter pro-

vides instructions only for the mainte-

nance items that are easy to perform.

Owner’s responsibility

Several procedures can be done only

Maintenance service and record reten-

by an authorized HYUNDAI dealer

tion are the owner’s responsibility.

with special tools.

You should retain documents that show

Your vehicle should not be modified in

proper maintenance has been per-

any way. Such modifications may

formed on your vehicle in accordance

adversely affect the performance,

with the scheduled maintenance serv-

safety or durability of your vehicle and

ice charts shown on the following

may, in addition, violate conditions of

pages. You need this information to

the limited warranties covering the

establish your compliance with the

vehicle.

servicing and maintenance require-

ments of your vehicle warranties.

7-6

OWNER MAINTENANCE

The following lists are vehicle checks

WARNING

(Continued)

and inspections that should be per-

•

Block the tires (front and back)

formed by the owner or an authorized

Performing maintenance work

to prevent the vehicle from

HYUNDAI dealer at the frequencies

on a vehicle can be dangerous.

moving.

indicated to help ensure safe, depend-

If you lack sufficient knowledge

Remove loose clothing or jew-

able operation of your vehicle.

and experience or the proper

elry that can become entan-

Any adverse conditions should be

tools and equipment to do the

gled in moving parts.

brought to the attention of your dealer

work, we recommend that the

•

If you must run the engine

as soon as possible.

system be serviced by an author-

during maintenance, do so

ized HYUNDAI dealer. ALWAYS

These Owner Maintenance vehicle

out doors or in an area with

checks are generally not covered by

follow these precautions for

plenty of ventilation.

performing maintenance work:

warranties and you may be charged

•

Keep flames, sparks, or smok-

for labor, parts and lubricants used.

• Park your vehicle on level

ing materials away from the

ground, move the shift lever

battery and fuel-related parts.

into the P (Park, for automatic

transaxle/dual clutch transmis-

sion vehicle) position, apply the

parking brake, place the igni-

tion switch in the LOCK/OFF

position.

(Continued)

7-7

Maintenance

Owner maintenance schedule

While operating your vehicle:

WARNING

When you stop for fuel:

•

Note any changes in the sound of

the exhaust or any smell of exhaust

Diesel Engine

• Check the engine oil level.

fumes in the vehicle.

Never manipulate or modify the

• Check coolant level in the engine

•

Check for vibrations in the steering

injection system while running

coolant reservoir.

wheel. Notice if there is any

the diesel engine or within 30

• Check the windshield washer fluid

increased steering effort or loose-

seconds after turning OFF the

level.

ness in the steering wheel, or

diesel engine. The high-pressure

• Check for low or under-inflated tires.

change in its straight-ahead position.

pump, high-pressure pipes, rail,

•

Notice if your vehicle constantly turns

and injectors are still subject to

slightly or “pulls” to one side when

the high pressure right after

WARNING

traveling on smooth, level road.

stopping the diesel engine.

Be careful when checking your

•

When stopping, listen and check for

When the fuel leakage vents out,

engine coolant level when the

unusual sounds, pulling to one side,

it may cause serious body injury.

engine is hot. This may result in

increased brake pedal travel or

Any people, who are implement-

coolant being blown out of the

“hard-to-push” brake pedal.

ed with the artificial cardiac

opening and cause serious

pacemaker, should remain away

•

If any slipping or changes in the

burns and other injuries.

from the ECU or the wiring har-

operation of your transaxle occurs,

ness by at least 30 cm, while run-

check the transaxle fluid level.

ning the diesel engine. The high

•

Check the automatic transaxle/

currents of the electric engine

dual clutch transmission P (Park)

control system produce a con-

function.

siderable amount of magnetic

•

Check the parking brake.

fields.

•

Check for fluid leaks under your

vehicle (water dripping from the air

conditioning system during or after

use is normal).

7-8

At least monthly:

At least twice a year:

At least once a year:

• Check coolant level in the engine

(i.e., every Spring and Fall)

• Clean body and door drain holes.

coolant reservoir.

• Check radiator, heater and air condi-

• Lubricate door hinges and hood

• Check the operation of all exterior

tioning hoses for leaks or damage.

hinges.

lights, including the stoplights, turn

• Check windshield washer spray

• Lubricate door and hood locks and

signals and hazard warning flashers.

and wiper operation. Clean wiper

latches.

• Check the inflation pressures of all

blades with clean cloth dampened

• Lubricate door rubber weather

with washer fluid.

tires including the spare for tires

strips.

that are worn, show uneven wear,

• Check headlamp alignment.

• Check the air conditioning system.

or are damaged.

• Check muffler, exhaust pipes,

• Inspect and lubricate automatic

• Check for loose wheel lug nuts.

shields and clamps.

transaxle linkage and controls.

• Check the seat belts for wear and

• Clean the battery and terminals.

function.

• Check the brake fluid level.

7-9

Maintenance

SCHEDULED MAINTENANCE SERVICES

Follow Normal Maintenance Schedule if the vehicle is usually operated where none of the following conditions apply.

If any of the following conditions apply, you must follow the Maintenance Under Severe Usage Conditions.

• Repeated driving short distance of less than 8 km (5 miles) in normal temperature or less than 16 km(10 miles) in

freezing temperature

• Extensive engine idling or low speed driving for long distances

• Driving on rough, dusty, muddy, unpaved, graveled or salt-spread roads

• Driving in areas using salt or other corrosive materials or in very cold weather

• Driving in the condition of inflowing sand or dust into engine

• Driving in heavy traffic area

• Driving on uphill, downhill, or mountain road repeatedly

• Towing a trailer or using a camper, or roof rack

• Driving as a patrol car, taxi, other commercial use of vehicle towing

• Driving over 170 km/h (106 mile/h)

• Frequently driving in stop-and-go condition

If your vehicle is operated under the above conditions, you should inspect, replace or refill more frequently than the

following Normal Maintenance Schedule. After the periods or distance shown in the chart, continue to follow the pre-

scribed maintenance intervals.

7-10

Normal Maintenance Schedule (For Europe, Except Russia)

MAINTENANCE

Months

120

144

168

192

INTERVALS

Miles x 1,000

100

120

140

160

MAINTENANCE

ITEM

Km x 1,000

120

150

180

210

240

First Inspect at 90,000 km (60,000 miles) or 72 months,

Drive belts (Gasoline) *1

after every 30,000 km (20,000 miles) or 24 months

First Inspect at 90,000 km (60,000 miles) or 48 months,

Drive belts (Diesel) *1

after every 30,000 km (20,000 miles) or 24 months

Diesel *2 *3 *4

Engine oil and

Gasoline (1.6 GDI) *2 *5

engine oil filter **

Gasoline (1.6 T-GDI) *2

Replace every 15,000 km (10,000 miles) or 12 months

Gasoline (2.0 MPI) *2

Replace every 15,000 km (10,000 miles) or 12 months

I : Inspect and if necessary, adjust, correct, clean or replace.

R : Replace or change.

** : The engine oil level should be checked regularly and maintained properly. Operating with an insufficient amount of oil can dam-

age the engine, and such damage is not covered by warranty.

*1 : Inspect drive belt tensioner, idler and alternator pulley and if necessary correct or replace.

*2 : Check the engine oil level and leak every 500 km (350 miles) or before starting a long trip.

*3 : This maintenance schedule depends on fuel quality. It is applicable only when using a qualified fuel <"EN590 or equivalent">.

If the diesel fuel specifications don't meet the EN590, it must be replaced according to the severe maintenance schedule.

*4 : If the recommended oil is not available, replace engine oil and engine oil filter every 20,000 km or 12 months.

*5 : If the recommended oil is not available, replace engine oil and engine oil filter every 15,000 km.

7-11

Maintenance

Normal Maintenance Schedule (For Europe, Except Russia) (Cont.)

MAINTENANCE

Months

120

144

168

192

INTERVALS

Miles x 1,000

100

120

140

160

MAINTENANCE

Km x 1,000

120

150

180

210

240

ITEM

Fuel additives (Gasoline) *7

Add every 15,000 km (10,000 miles) or 12 months

Intercooler, in/out hose,

1.6 T-GDI

Inspect every 10,000 km (6,500 miles)

air intake hose

Air cleaner filter

For 1.6 T-GDI

Replace every 75,000 km (50,000 miles) *8 or 60 months

Spark plugs

Except 1.6 T-GDI

Replace every 160,000 km (100,000 miles) *8 or 120 months

Vapor hose and fuel filler cap (Gasoline)

Fuel tank air filter (Gasoline)

Fuel filter (Gasoline) *9

Fuel lines, hoses and connections (Gasoline)

Fuel lines, hoses and connections (Diesel)

I : Inspect and if necessary, adjust, correct, clean or replace.

R : Replace or change.

*7 : If good quality gasolines meet Europe Fuel standards (EN228) or equivalents including fuel additives is not available, one bot-

tle of additive is recommended. Additives are available from your authorized HYUNDAI dealer along with information on how to

use them. Do not mix other additives.

*8 : For your convenience, it can be replaced prior to it's interval when you do maintenance of other items.

*9 : The fuel filter is considered to be maintenance free but periodic inspection is recommended for this maintenance schedule

depends on fuel quality. If there are some important matters like fuel flow restriction, surging, loss of power, hard starting prob-

lem etc, replace the fuel filter immediately regardless of maintenance schedule and consult an authorized HYUNDAI dealer for

details.

7-12

Normal Maintenance Schedule (For Europe, Except Russia) (Cont.)

MAINTENANCE

Months

120

144

168

192

INTERVALS

Miles x 1,000

100

120

140

160

MAINTENANCE

ITEM

Km x 1,000

120

150

180

210

240

Fuel filter cartridge (Diesel) *10

Inspect “Coolant level adjustment and leak” every day.

Cooling system

At first, inspect 60,000 km (40,000 miles) or 48 months

after that, inspect every 30,000 km (20,000 miles) or 24 months

At first, replace at 210,000 km (120,000 miles) or 10 years :

Engine coolant *11

after that, replace every 30,000 km (20,000 miles) or 24 months *12

Battery condition

Brake lines, hoses and connections

Parking brake

Brake/clutch fluid

Disc brakes and pads

Steering gear rack, linkage and boots

I : Inspect and if necessary, adjust, correct, clean or replace.

R : Replace or change.

*10 : This maintenance schedule depends on fuel quality. It is applicable only when using a qualified fuel <"EN590 or equivalent">.

If the diesel fuel specifications don't meet the EN590, it must be replaced more frequently. If there are some important safety

matters like fuel flow restriction, surging, loss of power, hard starting problem etc., replace the fuel filter immediately regard-

less of maintenance schedule. We recommend that you consult an authorized HYUNDAI dealer for details.

*11 : When adding coolant, use only deionized water or soft water for your vehicle and never mix hard water in the coolant filled at

the factory. An improper coolant mixture can result in serious malfunction or engine damage.

*12 : For your convenience, it can be replaced prior to it's interval when you do maintenance of other items.

7-13

Maintenance

Normal Maintenance Schedule (For Europe, Except Russia) (Cont.)

MAINTENANCE

Months

120

144

168

192

INTERVALS

Miles x 1,000

100

120

140

160

MAINTENANCE

ITEM

Km x 1,000

120

150

180

210

240

Driveshaft and boots

Tire (pressure & tread wear)

Front suspension ball joints

Air conditioner refrigerant

Air conditioner compressor

Climate control air filter

Manual transaxle fluid *13

Dual clutch transmission fluid *13

Automatic transaxle fluid

No check, No service required

Transfer case oil (4WD) *13

Rear differential oil (4WD) *13

Propeller shaft (4WD)

Valve clearance (Gasoline 1.6) *14

Exhaust system

I : Inspect and if necessary, adjust, correct, clean or replace.

R : Replace or change.

*13 : Manual transaxle/dual clutch transmission fluid, transfer case oil and differential oil should be changed anytime they have been

submerged in water.

*14 : Inspect for excessive valve noise and/or engine vibration and adjust if necessary.We recommend that the system be checked

by an authorized HYUNDAI dealer.

7-14

Maintenance Under Severe Usage and Low Mileage Conditions (For Europe, Except Russia)

The following items must be serviced more frequently on cars mainly used under severe and low mileage driving con-

ditions. Refer to the chart below for the appropriate maintenance intervals.

R : Replace I : Inspect and if necessary, adjust, correct, clean or replace

Maintenance

Maintenance item

Maintenance intervals

Driving condition

operation

Diesel

Replace every 15,000 km (10,000 miles)

Gasoline (1.6 GDI)

or 12 months

Engine oil and

A, B, C, D, E, F, G,

Replace every 7,500 km (4,500 miles)

Gasoline (1.6 T-GDI)

engine oil filter

H, I, K, L

or 6 months

Replace every 7,500 km (4,500 miles)

Gasoline (2.0 MPI)

or 6 months

Replace more frequently

Air cleaner filter

C, E

depending on the condition

Replace more frequently

Spark plugs

B, H

depending on the condition

Inspect more frequently

Steering gear rack, linkage and boots

C, D, E, F, G

depending on the condition

Inspect more frequently

Front suspension ball joints

C, D, E, F, G

depending on the condition

Inspect more frequently

Disc brakes and pads, calipers and rotors

C, D, E, G, H

depending on the condition

Inspect more frequently

Parking brake

C, D, G, H

depending on the condition

Inspect more frequently

Driveshaft and boots

C, D, E, F, G, H, I

depending on the condition

7-15

Hyundai Tucson (2017 year). Instruction - part 26
