Shift-lock system
Shift-lock release
For your safety, the dual clutch trans-
If the shift lever cannot be moved
mission has a shift-lock system
from the P (Park) position into R
which prevents shifting the transmis-
(Reverse) position with the brake
sion from P (Park) into R (Reverse)
pedal depressed, continue depress-
unless the brake pedal is depressed.
ing the brake, and then do the follow-
To shift the transmission from P
ing:
(Park) into R (Reverse):
1. Depress and hold the brake pedal.
2. Start the engine or place the igni-
tion switch in the ON position.
OTLE055002
3. Move the shift lever.
1. Place the ignition switch in the
LOCK/OFF position.
5
2. Apply the parking brake.
3. Carefully remove the cap (1) cov-
ering the shift-lock access hole.
4. Insert a tool (e.g. flathead screw-
driver) into the access hole and
press down on the tool.
5. Move the shift lever while holding
down the screwdriver.
6. Remove the tool from the shiftlock
release access hole then install
the cap.
7. Depress the brake pedal, and then
restart the engine.
5-37
Driving your vehicle
If you need to use the shift-lock
Parking
Good driving practices
release, we recommend that the sys-
Always come to a complete stop and
•
Never move the shift lever from P
tem be inspected by an authorized
continue to depress the brake pedal.
(Park) or N (Neutral) to any other
HYUNDAI dealer immediately.
Move the shift lever into the P (Park)
position with the accelerator pedal
position, apply the parking brake,
depressed.
Ignition key interlock system
and place the ignition switch in the
•
Never move the shift lever into P
(if equipped)
LOCK/OFF position. Take the Key
(Park) when the vehicle is in
with you when exiting the vehicle.
The ignition key cannot be removed
motion.
unless the shift lever is in the P
Be sure the vehicle is completely
(Park) position.
WARNING
stopped before you attempt to shift
into R (Reverse) or D (Drive).
When you stay in the vehicle
•
Do not move the shift lever to N
with the engine running, be
(Neutral) when driving. Doing so
careful not to depress the accel-
may result in an accident because
erator pedal for a long period of
of a loss of engine braking and the
time. The engine or exhaust
transmission could be damaged.
system may overheat and start
•
Do not drive with your foot resting
a fire.
on the brake pedal. Even light, but
The exhaust gas and the
consistent pedal pressure can
exhaust system are very hot.
result in the brakes overheating,
Keep away from the exhaust
brake wear and possibly even
system components.
brake failure.
Do not stop or park over flam-
•
When driving in sports mode, slow
mable materials, such as dry
down before shifting to a lower
grass, paper or leaves. They
gear. Otherwise, the lower gear
may ignite and cause a fire.
may not be engaged if the engine
rpms are outside of the allowable
range.
5-38
•
Always apply the parking brake
WARNING
(Continued)
when leaving the vehicle. Do not
depend on placing the transmis-
• In the event your vehicle
To reduce the risk of SERIOUS
leaves the roadway, do not
sion in P (Park) to keep the vehicle
INJURY or DEATH:
steer sharply. Instead, slow
from moving.
•
ALWAYS wear your seatbelt.
down before pulling back into
•
Exercise extreme caution when
In a collision, an unbelted
the travel lanes.
driving on a slippery surface. Be
occupant is significantly more
• HYUNDAI recommends you
especially careful when braking,
likely to be seriously injured
follow all posted speed limits.
accelerating or shifting gears. On a
or killed than a properly belt-
slippery surface, an abrupt change
ed occupant.
in vehicle speed can cause the
i
Information - Kickdown
drive wheels to lose traction and
•
Avoid high speeds when cor-
Mechanism (if equipped)
may cause loss of vehicle control
nering or turning.
resulting in an accident
•
Do not make quick steering
Use the kickdown mechanism for
5
•
Optimum vehicle performance and
wheel movements, such as
maximum acceleration. Depress the
economy is obtained by smoothly
sharp lane changes or fast,
accelerator pedal beyond the pressure
depressing and releasing the
sharp turns.
point. The automatic transaxle will
accelerator.
shift to a lower gear depending on the
•
The risk of rollover is greatly
engine speed.
increased if you lose control
of your vehicle at highway
speeds.
•
Loss of control often occurs if
two or more wheels drop off
the roadway and the driver
over steers to reenter the
roadway.
(Continued)
5-39
Driving your vehicle
BRAKING SYSTEM
Power brakes
WARNING
(Continued)
Your vehicle has power-assisted
•
Wet brakes may impair the
brakes that adjust automatically
Take the following precautions:
vehicle’s ability to safely slow
through normal usage.
•
Do not drive with your foot
down; the vehicle may also
If the engine is not running or is
pull to one side when the
resting on the brake pedal.
turned off while driving, the power
This will create abnormal high
brakes are applied. Applying
assist for the brakes will not work.
the brakes lightly will indicate
brake temperatures, exces-
You can still stop your vehicle by
sive brake lining and pad
whether they have been
applying greater force to the brake
affected in this way. Always
wear, and increased stopping
pedal than typical. The stopping dis-
distances.
test your brakes in this fash-
tance, however, will be longer than
ion after driving through deep
•
When descending a long or
with power brakes.
water. To dry the brakes, light-
steep hill, shift to a lower gear
When the engine is not running, the
ly tap the brake pedal to heat
and avoid continuous applica-
up the brakes while maintain-
reserve brake power is partially
tion of the brakes. Applying
depleted each time the brake pedal
ing a safe forward speed until
the brakes continuously will
brake performance returns to
is applied. Do not pump the brake
cause the brakes to overheat
pedal when the power assist has
normal. Avoid driving at high
and could result in a tempo-
speeds until the brakes func-
been interrupted.
rary loss of braking perform-
tion correctly.
Pump the brake pedal only when
ance.
necessary to maintain steering con-
(Continued)
trol on slippery surfaces.
5-40
Disc brakes wear indicator
Parking brake
WARNING
(hand type, if equipped)
When your brake pads are worn and
new pads are required, you will hear
To reduce the risk of SERIOUS
a high pitched warning sound from
INJURY or DEATH, do not oper-
your front or rear brakes. You may
ate the parking brake while the
hear this sound come and go or it
vehicle is moving except in an
may occur whenever you depress
emergency situation. It could
the brake pedal.
damage the brake system and
Please remember some driving con-
lead to an accident.
ditions or climates may cause a
brake squeal when you first apply (or
lightly apply) the brakes. This is nor-
mal and does not indicate a problem
with your brakes.
OTL075011
5
Always set the parking brake before
NOTICE
leaving the vehicle, to apply:
To avoid costly brake repairs, do
Firmly depress the brake pedal.
not continue to drive with worn
Pull up the parking brake lever as far
brake pads.
as possible.
i
Information
Always replace brake pads as com-
plete front or rear axle sets.
5-41
Driving your vehicle
NOTICE
WARNING
•
Do not apply the accelerator
•
Whenever leaving the vehicle
pedal while the parking brake is
or parking, always come to a
engaged. If you depress the
complete stop and continue to
accelerator pedal with the park-
depress the brake pedal. Move
ing brake engaged, warning will
the shift lever into the 1st gear
sound. Damage to the parking
(for manual transaxle vehicle)
brake may occur.
or P
(Park, for automatic
•
Driving with the parking brake on
transaxle/dual clutch trans-
can overheat the braking system
mission vehicle) position, then
OTL055013
and cause premature wear or
apply the parking brake, and
damage to brake parts. Make sure
To release:
place the ignition switch in the
the parking brake is released and
Firmly depress the brake pedal.
LOCK/OFF position.
the Brake Warning Light is off
Slightly pull up the parking brake
Vehicles with the parking
before driving.
lever.
brake not fully engaged are at
risk for moving inadvertently
While pressing the release button
and causing injury to yourself
(1), lower the parking brake (2).
or others.
•
NEVER allow anyone who is
If the parking brake does not release
unfamiliar with the vehicle to
or does not release all the way, we
touch the parking brake. If the
recommend that the system be
parking brake is released
checked by an authorized HYUNDAI
unintentionally, serious injury
dealer.
may occur.
•
Only release the parking brake
when you are seated inside the
vehicle with your foot firmly on
the brake pedal.
5-42
Check the Parking
If the Parking Brake Warning Light
Electronic Parking Brake (EPB)
Brake Warning Light
remains on after the parking brake is
(if equipped)
by placing the ignition
released while engine is running,
Applying the parking brake
switch to the ON posi-
there may be a malfunction in the
tion
(do not start the
brake system. Immediate attention is
engine).
necessary.
This light will be illuminated when the
If at all possible, cease driving the
parking brake is applied with the igni-
vehicle immediately. If that is not pos-
tion switch in the START or ON posi-
sible, use extreme caution while
tion.
operating the vehicle and only con-
tinue to drive the vehicle until you
Before driving, be sure the parking
can reach a safe location.
brake is released and the Brake
Warning Light is OFF.
5
OTL055015
To apply the EPB
(Electronic Parking Brake):
1. Depress the brake pedal.
2. Pull up the EPB switch.
Make sure the Parking Brake
Warning Light comes on.
5-43
Driving your vehicle
Also, the EPB is applied automatical-
Releasing the parking brake
To release EPB (Electronic Parking
ly if the [AUTO HOLD] switch is on
Brake) automatically:
when the engine is turned off.
•
Shift lever in P (Park)
However, if you press the EPB switch
With the engine running depress
within one second after the engine is
the brake pedal and shift out of P
turned off, the EPB will not be
(Park) to R (Rear) or D (Drive).
applied.
•
Shift lever in N (Neutral)
With the engine running depress
WARNING
the brake pedal and shift out of N
(Neutral) to R (Rear) or D (Drive).
To reduce the risk of SERIOUS
INJURY or DEATH, do not oper-
•
Automatic transaxle/Dual clutch
ate the EPB while the vehicle is
transmission vehicle
OTL055016
moving except in an emergency
1. Start the engine.
situation. It could damage the
To release the EPB (Electronic
2. Fasten the driver's seat belt.
brake system and lead to an
Parking Brake), press the EPB
switch in the following condition:
3. Close the driver's door, engine
accident.
hood and tailgate.
• Place the Engine Start/Stop button
in the ON position.
4. Depress the accelerator pedal
while the shift lever is in R (Rear),
• Depress the brake pedal.
D (Drive) or Sports mode.
Make sure the Parking Brake
Warning Light goes off.
Make sure the Parking Brake
Warning light goes off.
5-44
NOTICE
When the EPB (Electronic Parking
i
Information
Brake) does not release:
• For your safety, you can engage the
• If the parking brake warning
We recommend that you contact an
EPB even though the Engine
light is still on even though the
authorized HYUNDAI dealer by load-
Stop/Start button is in the OFF posi-
EPB has been released, we rec-
ing the vehicle on a flatbed tow truck
tion, but you cannot release it.
ommend that the system be
and have the system checked.
checked by an authorized
• For your safety, depress the brake
HYUNDAI dealer.
pedal and release the parking brake
manually with the EPB switch when
• Do not drive your vehicle with
EPB (Electronic Parking Brake)
may be automatically applied
you drive downhill or when backing
the EPB applied. It may cause
up the vehicle.
excessive brake pad and brake
when:
rotor wear.
• The EPB is overheated
• It is requested by other systems
• The engine is turned off with the
5
EPB applied
i
Information
If the driver turns the engine off while
Auto Hold is operating, EPB will be
automatically applied. However, if
you press the EPB switch within one
second after the engine is turned off,
the EPB will not be applied.
5-45
Driving your vehicle
Warning messages
NOTICE
WARNING
■ Type A
■ Type B
•
Do not apply the accelerator
•
Whenever leaving the vehicle
pedal while the parking brake is
or parking, always come to a
engaged. If you depress the
complete stop and continue
accelerator pedal with the EPB
to depress the brake pedal.
engaged, a warning will sound
Move the shift lever into the P
and a message will appear.
Damage to the parking brake
(Park) position, press the EPB
switch, and press the Engine
may occur.
Start/Stop button to the OFF
•
Driving with the parking brake
position. Take the Smart Key
on can overheat the braking sys-
with you when exiting the
tem and cause premature wear
OLF054231N/OLF054232N
vehicle.
or damage to brake parts. Make
sure the EPB is released and the
Vehicles not fully engaged in
Release parking brake
P
(Park) with the parking
Parking Brake Warning Light is
• When you try to drive with the EPB
off before driving.
brake set are at risk for mov-
applied, a warning will sound and a
ing inadvertently and causing
message will appear.
injury to yourself or others.
• If the driver's seat belt is unfas-
•
NEVER allow anyone who is
tened and the engine hood or tail-
unfamiliar with the vehicle to
gate is opened, a warning will
touch the EPB switch. If the
sound and a message will appear.
EPB is released unintentional-
• When there is a problem with the
ly, serious injury may occur.
vehicle, a warning may sound and
•
Only release the EPB when
a message may appear.
you are seated inside the
If the situation occurs, depress the
vehicle with your foot firmly
brake pedal and release EPB by
on the brake pedal.
pressing the EPB switch.
5-46
■ Type A
■ Type B
■ Type A
■ Type B
i
Information
•
A clicking sound may be heard
while operating or releasing the
EPB. These conditions are normal
and indicate that the EPB is func-
tioning properly.
•
When leaving your keys with a
parking attendant or assistant,
make sure to inform him/her how to
operate the EPB.
OTLE055028/OLFH044408L
OLF054131N/OLF044411N
AUTO HOLD deactivating.
Parking brake automatically locked
Press brake pedal
If the EPB is applied while Auto Hold
5
When the conversion from Auto Hold
is activated, a warning will sound and
to EPB is not working properly a
a message will appear.
warning will sound and a message
will appear.
5-47
Driving your vehicle
EPB malfunction indicator
NOTICE
Emergency braking
(if equipped)
If there is a problem with the brake
•
If the EPB warning light is still
pedal while driving, emergency brak-
on, we recommend that the sys-
ing is possible by pulling up and
tem be checked by an author-
holding the EPB switch. Braking is
ized HYUNDAI dealer.
possible only while you are holding
•
If the parking brake warning
the EPB switch.
light does not illuminate or
blinks even though the EPB
WARNING
switch was pulled up, the EPB
may not be applied.
Do not operate the parking
•
If the parking brake warning
brake while the vehicle is mov-
light blinks when the EPB warn-
ing except in an emergency sit-
ing light is on, press the switch,
uation. It could damage the
OTL055017
and then pull it up. Repeat this
brake system and lead to a
If the EPB malfunction indicator
one more time. If the EPB warn-
severe accident.
remains on, comes on while driving,
ing does not go off, we recom-
or does not come on when the
mend that the system be
Engine Start/Stop button is changed
checked by an authorized
i Information
to the ON position, this indicates that
HYUNDAI dealer.
the EPB may have malfunctioned.
During emergency braking, the park-
ing brake warning light will illumi-
If this occurs, we recommend that
nate to indicate that the system is
the system be checked by an author-
operating.
ized HYUNDAI dealer.
The EPB malfunction indicator may
illuminate when the ESC indicator
comes on to indicate that the ESC is
not working properly, but it does not
indicate a malfunction of the EPB.
5-48
NOTICE
AUTO HOLD (if equipped)
To apply :
This feature keeps the brake applied
If you continuously notice a noise
when the shift lever is in D (Drive), R
or burning smell when the EPB is
White
(Reverse), N
(Neutral) or Sports
used for emergency braking, we
Mode with the feature enabled and
recommend that the system be
when the brake pedal has been
checked by an authorized HYUNDAI
depressed to stop the vehicle.
dealer.
When the EPB (Electronic Parking
Brake) does not release
If the EPB does not release normal-
ly, we recommend that you contact
OTL055018
an authorized HYUNDAI dealer by
5
1. With the driver's door, engine
loading the vehicle on a flatbed tow
hood and tailgate closed, fasten
truck and have the system checked.
the driver's seat belt or depress
the brake pedal and then press
the
[AUTO HOLD] switch. The
white AUTO HOLD indicator will
come on and the system will be in
the standby position.
5-49
Driving your vehicle
To release :
To cancel :
White
If you press the accelerator pedal
with the shift lever in R (Reverse), D
Light off
(Drive) or sports mode, the Auto
Hold will be released automatically
and the vehicle will start to move.
Green
The indicator changes from green to
white.
WARNING
OTL055019
When the AUTO HOLD is auto-
2. When you stop the vehicle com-
matically released by depress-
OTL055020
pletely by depressing the brake
ing the accelerator pedal, always
1. Depress the brake pedal.
pedal, the AUTO HOLD indicator
take a look around your vehicle.
changes from white to green.
2. Press the [AUTO HOLD] switch.
Slowly depress the accelerator
3. The vehicle will remain stationary
The AUTO HOLD indicator will turn
pedal for a smooth start.
even if you release the brake
off.
pedal.
4. If EPB is applied, Auto Hold will be
released.
5-50
(Continued)
i
Information
WARNING
In these cases, the brake warning
•
The Auto Hold does not operate
light comes on, the AUTO HOLD
To prevent, unexpected and sud-
when:
indicator changes from green to
den vehicle movement, ALWAYS
- The driver's seat belt is unfastened
white, and a warning sound and a
press your foot on the brake
and driver's door is opened
message will appear to inform you
pedal to cancel the Auto Hold
- The engine hood is opened
that EPB has been automatically
before you:
engaged. Before driving off again,
- The tailgate is opened
- Drive downhill.
press foot brake pedal, check the
- The shift lever is in P (Park)
- Drive the vehicle in R (Reverse).
surrounding area near your vehicle
- The EPB is applied
and release parking brake manually
- Park the vehicle.
•
For your safety, the Auto Hold auto-
with the EPB switch.
matically switches to EPB when:
•
If the AUTO HOLD indicator changes
- The driver's seat belt is unfastened
to yellow, the Auto Hold is not work-
5
and driver's door is opened
ing properly. We recommend that you
contact an authorized HYUNDAI
- The engine hood is opened with the
dealer.
shift lever is in D (Drive)
•
While operating Auto Hold, you may
- The tailgate is opened with the
hear mechanical noise. However, it is
shift lever is in R (Reverse)
normal operating noise.
- The vehicle stops for more than 10
minutes
- The vehicle stands on a steep slope
- The vehicle moves several times
(Continued)
5-51
Driving your vehicle
Warning messages
■ Type A
■ Type B
WARNING
■ Type A
■ Type B
• Press the accelerator pedal
slowly when you start the
vehicle.
• For your safety, cancel the
Auto Hold when you drive
downhill, back up the vehicle
or park the vehicle.
OTLE055028/OLFH044408L
NOTICE
AUTO HOLD deactivating.
OLF054131N/OLF044411N
If there is a malfunction with the
Press brake pedal
driver’s door, engine hood or
Parking brake automatically locked
When the conversion from Auto Hold
trunk open detection system, the
When the EPB is applied from Auto
to EPB is not working properly a
Auto Hold may not work properly.
Hold, a warning will sound and a
warning will sound and a message
We recommend that you contact
message will appear.
will appear.
an authorized HYUNDAI dealer.
NOTICE
When this message is displayed,
the Auto Hold and EPB may not
operate. For your safety, depress
the brake pedal.
5-52
■ Type A
■ Type B
Anti-lock Brake System (ABS)
WARNING
An Anti-Lock Braking System
(ABS) or an Electronic Stability
Control (ESC) system will not
prevent accidents due to
improper or dangerous driving
maneuvers. Even though vehi-
cle control is improved during
OLF054127N/OLF044407N
OLF054129N
emergency braking, always
maintain a safe distance
Press brake pedal to deactivate
AUTO HOLD conditions not met.
between you and objects ahead
AUTO HOLD
Close door, hood, trunk, and fasten
5
of you. Vehicle speeds should
seatbelt
If you did not apply the brake pedal
always be reduced during
when you release the Auto Hold by
When you press the [AUTO HOLD]
extreme road conditions. The
pressing the [AUTO HOLD] switch, a
switch, if the driver’s door, engine
braking distance for cars
warning will sound and a message
hood and tailgate are not closed or
equipped with ABS or ESC may
will appear.
the driver’s seat belt is unfastened, a
be longer than for those without
warning will sound and a message
these systems in the following
will appear on the LCD display. At
road conditions.
this moment, press the
[AUTO
• Drive your vehicle at reduced
HOLD] button after closing the dri-
speeds during the following
ver’s door, engine hood and tailgate
conditions:
and fastening the seat belt.
• Rough, gravel or snow-cov-
ered roads.
(Continued)
5-53
